The Studio V3 offers all of the features of the original Tube MP with versatile onboard presets to easily dial in a great tone.
V3 stands for Variable Valve Voicing, and refers to the sixteen presets in three overlapping groups: Neutral, Warm, and OPL. Each has a precisely voiced EQ curve, Warm presets add tube saturation, and OPL presets engage Output Protection Limiting for dynamic control of loud signals and big transients.
Each preset has a suggested application, but they all have a unique character, so any could be an inspiring match for your performance. Theres also a Flat preset for the classic sound of the original Tube MP.
Like the original, the Tube MP Studio V3 has XLR and 1/4 connections with variable gain and switchable boost, phantom power, and phase reversal.
Fast and flexible, the Tube MP Studio V3 is a mic preamp and instrument DI designed for maximum tone with minimum tweaking.
| Product Name | ART Tube MP Studio V3 Microphone Tube Preamplifier |
|---|---|
| Brand | ART |
| Condition | New |
| MPN | TUBEMPSTV3U |
| UPC | 840402049289 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- ART Tube MP Studio V3 Microphone Tube Preamplifier
- Universal Power Supply
- Provides Superior Preamplification for:
Microphones, Instruments and Line Level Sources - V3™ – Variable Valve Voicing
- OPL™ – Output Protection Limiting
- Hand Selected 12AX7A Provides 70dB of Gain Smooth,
Warm and Fat Sound Quality - Variable Input and Output Gain Controls
- Excellent as a Tube DI
- XLR and 1/4″ Inputs and Outputs
- +48 Volts of Phantom Power
- Phase Reversal Switch
- Portable, All Steel Construction
Connections |
|
|---|---|
| Inputs | XLR (Balanced), 1/4" TS |
| Outputs | XLR (Balanced), 1/4" TS |
Performance |
|
| Input Impedance | 2 kΩ (XLR), 840 kΩ (1/4") |
| Output Impedance | 600 Ω (XLR), 300 Ω (1/4") |
| Maximum Input Level | +14 dBu (XLR), +22 dBu (1/4") |
| Maximum Output Level | +14 dBu (XLR), +22 dBu (1/4") |
| Maximum Gain | 50 dB – 60 dB |
| Frequency Response | 10 Hz – 30 kHz, ±0.5 dB |
| Total Harmonic Distortion | <0.1% (typical) |
| Equivalent Input Noise | -129 dBu to -105 dBu |
| CMRR | >75 dB (typical @ 1 kHz) |
Power |
|
| Power Requirements | SA – 9 VAC @ 0.8 A (typical) Export units configured for country of destination |
Physical |
|
| Dimensions (W × D × H) | 5.0" × 5.5" × 2.0" (12.7 × 13.97 × 5.1 cm) |
| Weight | 1.5 lbs (0.68 kg) |
ART Tube MP Studio V3 Microphone Tube Preamplifier
The Studio V3 offers all of the features of the original Tube MP with versatile onboard presets to easily dial in a great tone.
V3 stands for Variable Valve Voicing, and refers to the sixteen presets in three overlapping groups: Neutral, Warm, and OPL. Each has a precisely voiced EQ curve, Warm presets add tube saturation, and OPL presets engage Output Protection Limiting for dynamic control of loud signals and big transients.
Each preset has a suggested application, but they all have a unique character, so any could be an inspiring match for your performance. Theres also a Flat preset for the classic sound of the original Tube MP.
Like the original, the Tube MP Studio V3 has XLR and 1/4 connections with variable gain and switchable boost, phantom power, and phase reversal.
Fast and flexible, the Tube MP Studio V3 is a mic preamp and instrument DI designed for maximum tone with minimum tweaking.
| Product Name | ART Tube MP Studio V3 Microphone Tube Preamplifier |
|---|---|
| Brand | ART |
| Condition | New |
| MPN | TUBEMPSTV3U |
| UPC | 840402049289 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- ART Tube MP Studio V3 Microphone Tube Preamplifier
- Universal Power Supply
- Provides Superior Preamplification for:
Microphones, Instruments and Line Level Sources - V3™ – Variable Valve Voicing
- OPL™ – Output Protection Limiting
- Hand Selected 12AX7A Provides 70dB of Gain Smooth,
Warm and Fat Sound Quality - Variable Input and Output Gain Controls
- Excellent as a Tube DI
- XLR and 1/4″ Inputs and Outputs
- +48 Volts of Phantom Power
- Phase Reversal Switch
- Portable, All Steel Construction
Connections |
|
|---|---|
| Inputs | XLR (Balanced), 1/4" TS |
| Outputs | XLR (Balanced), 1/4" TS |
Performance |
|
| Input Impedance | 2 kΩ (XLR), 840 kΩ (1/4") |
| Output Impedance | 600 Ω (XLR), 300 Ω (1/4") |
| Maximum Input Level | +14 dBu (XLR), +22 dBu (1/4") |
| Maximum Output Level | +14 dBu (XLR), +22 dBu (1/4") |
| Maximum Gain | 50 dB – 60 dB |
| Frequency Response | 10 Hz – 30 kHz, ±0.5 dB |
| Total Harmonic Distortion | <0.1% (typical) |
| Equivalent Input Noise | -129 dBu to -105 dBu |
| CMRR | >75 dB (typical @ 1 kHz) |
Power |
|
| Power Requirements | SA – 9 VAC @ 0.8 A (typical) Export units configured for country of destination |
Physical |
|
| Dimensions (W × D × H) | 5.0" × 5.5" × 2.0" (12.7 × 13.97 × 5.1 cm) |
| Weight | 1.5 lbs (0.68 kg) |
