ATC SCM1-15ASL Active 15 in SL Sub Downfiring
The SCM0.1/15 Pro is an active subwoofer with an integrated 1000 W power amplifier and a robust 15 woofer. The maximum continuous level for frequencies down to 20 Hz is 115 dB (1 m) with very little distortion. The SCM0.1/15 Pro can be used both to monitor the LFE channel in surround applications and to extend the low frequencies in systems with smaller main monitors such as the SCM20ASL Pro. A versatile control panel allows adjustment of gain, crossover frequency, frequency contour and phasing.
- Full “SL” spec 15˝/375mm bass driver.
- 450 watt continuous power/amplifier output
- Phase adjustment.
- Variable cut off frequency.
- Variable gain.
- Stereo inputs.
- 6 year warranty.
| Product Name | ATC SCM0.1/15ASL Active 15 in SL Sub Downfiring |
|---|---|
| Brand | ATC Loudspeakers |
| Condition | New |
| MPN | SCM15ASLPro |
| Shipping Option | Free Shipping to the Continental U.S. |
Driver: LF 375mm
Amplitude Linearity (±2dB): 30Hz-300Hz
Cut-off Frequency (-6dB, free-standing): 20Hz
Max. Continuous SPL (1 metre): 115dB
Input Connectors: Male XLR
Input Sensitivity: 1V
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 650W
Filters: Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction
Panel Indicators: Power On indicator
Dimensions (HxWxD): 624 x 580 x 580mm (24.6″ x 22.8″ x 22.8″)
Weight: 60kg (132lb)
ATC SCM0.1/15ASL Active 15 in SL Sub Downfiring
ATC SCM1-15ASL Active 15 in SL Sub Downfiring:
- Full “SL” spec 15˝/375mm bass driver.
- 450 watt continuous power/amplifier output
- Phase adjustment.
- Variable cut off frequency.
- Variable gain.
- Stereo inputs.
- 6 year warranty.
| Product Name | ATC SCM0.1/15ASL Active 15 in SL Sub Downfiring |
|---|---|
| Brand | ATC Loudspeakers |
| Condition | New |
| MPN | SCM15ASLPro |
| Shipping Option | Free Shipping to the Continental U.S. |
Driver: LF 375mm
Amplitude Linearity (±2dB): 30Hz-300Hz
Cut-off Frequency (-6dB, free-standing): 20Hz
Max. Continuous SPL (1 metre): 115dB
Input Connectors: Male XLR
Input Sensitivity: 1V
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 650W
Filters: Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction
Panel Indicators: Power On indicator
Dimensions (HxWxD): 624 x 580 x 580mm (24.6″ x 22.8″ x 22.8″)
Weight: 60kg (132lb)
