Aviom BOOM-1 Tactile Transducer Processor

Aviom BOOM-1 Tactile Transducer Processor

On order with the manufacturer!

View full details
  • Details
  • Tech Specs
  • Reviews

Now you can feel your monitor mix, too. BOOM-1 is designed to dramatically enhance a performer's personal mixing experience by adding powerful, optimally-processed low-frequency tactile information to any in-ear or headphone monitor mix.

Designed by the personal monitor experts, the BOOM System is easy to use and provides a natural low-frequency extension to your monitoring environment. The BOOM System products are compatible with all Aviom personal mixing systems and can easily be connected to any audio device that can provide a headphone or line-level output.

Made for musicians using in-ears

In-ear monitors provide a detailed and personal monitoring experience. Adding a well processed low-frequency tactile transducer (also known as a 'bass shaker') to a drum throne, keyboard seat, guitarist's stool, performance platform, or even to the floor of a stage, allows the body to feel bass frequencies, adding realism to the mix. The BOOM-1 Tactile Transducer Processor brings Aviom-optimized DSP to the tactile experience.

Being able to hearand feelyour mix can significantly improve the user experience when using in-ear monitors and/or headphones, providing powerful sound usually achieved only with high volume and large, high quality speaker cabinets.

Tactile transducers are especially beneficial to performers using electronic drum kits, as well as guitar and bass amp simulators. Why? Because playing an acoustic drum kit or an electric guitar or bass through an amp actually vibrates the floor and this vibration becomes part of the live performance experience. When you switch to an electronic drum kit or a modeled amp system without speaker cabinets, those natural vibrations are eliminated....Until now.

More Information
Product Name Aviom BOOM-1 Tactile Transducer Processor
Brand Aviom
Condition New
MPN BOOM-1
Shipping Option Free Shipping to the Continental U.S.
Headphone In (front & rear) 1/4-inch TRS stereo;
Tip: Audio Left; Ring: Audio Right; Sleeve: Ground
Headphone Thru (front & rear) 1/4-inch TRS stereo;
Tip: Audio Left; Ring: Audio Right; Sleeve: Ground
Line In XLR female,
Pin 2: Hot, Pin 3: Cold; Pin 1: Ground
Maximum Input Level 15.98 dBV
Input Impedance 9.5k Ohm
Line Out XLR balanced; mono; with Volume control
Maximum Output Level 12.55 dBV
Output Impedance 33.2 Ohms
Amplifier Output 4 Ohms - 210W
8 Ohms - 117W
Transducer Output 2-conductor locking speaker connector;

Power Supply Internal, universal switching type, IEC connector;
100-240 volts AC, 50/60Hz
Fuse 250VAC~ T3AL
Dimensions 19" (482.6 mm) wide x 8.62" (219.07 mm) deep;
2U, 3.5" (88.9 mm) high
Weight 6.0 lbs (2.72 kg)

Aviom BOOM-1 Tactile Transducer Processor

Details

Now you can feel your monitor mix, too. BOOM-1 is designed to dramatically enhance a performer's personal mixing experience by adding powerful, optimally-processed low-frequency tactile information to any in-ear or headphone monitor mix.

Designed by the personal monitor experts, the BOOM System is easy to use and provides a natural low-frequency extension to your monitoring environment. The BOOM System products are compatible with all Aviom personal mixing systems and can easily be connected to any audio device that can provide a headphone or line-level output.

Made for musicians using in-ears

In-ear monitors provide a detailed and personal monitoring experience. Adding a well processed low-frequency tactile transducer (also known as a 'bass shaker') to a drum throne, keyboard seat, guitarist's stool, performance platform, or even to the floor of a stage, allows the body to feel bass frequencies, adding realism to the mix. The BOOM-1 Tactile Transducer Processor brings Aviom-optimized DSP to the tactile experience.

Being able to hearand feelyour mix can significantly improve the user experience when using in-ear monitors and/or headphones, providing powerful sound usually achieved only with high volume and large, high quality speaker cabinets.

Tactile transducers are especially beneficial to performers using electronic drum kits, as well as guitar and bass amp simulators. Why? Because playing an acoustic drum kit or an electric guitar or bass through an amp actually vibrates the floor and this vibration becomes part of the live performance experience. When you switch to an electronic drum kit or a modeled amp system without speaker cabinets, those natural vibrations are eliminated....Until now.

More Information
Product Name Aviom BOOM-1 Tactile Transducer Processor
Brand Aviom
Condition New
MPN BOOM-1
Shipping Option Free Shipping to the Continental U.S.
Tech Specs
Headphone In (front & rear) 1/4-inch TRS stereo;
Tip: Audio Left; Ring: Audio Right; Sleeve: Ground
Headphone Thru (front & rear) 1/4-inch TRS stereo;
Tip: Audio Left; Ring: Audio Right; Sleeve: Ground
Line In XLR female,
Pin 2: Hot, Pin 3: Cold; Pin 1: Ground
Maximum Input Level 15.98 dBV
Input Impedance 9.5k Ohm
Line Out XLR balanced; mono; with Volume control
Maximum Output Level 12.55 dBV
Output Impedance 33.2 Ohms
Amplifier Output 4 Ohms - 210W
8 Ohms - 117W
Transducer Output 2-conductor locking speaker connector;

Power Supply Internal, universal switching type, IEC connector;
100-240 volts AC, 50/60Hz
Fuse 250VAC~ T3AL
Dimensions 19" (482.6 mm) wide x 8.62" (219.07 mm) deep;
2U, 3.5" (88.9 mm) high
Weight 6.0 lbs (2.72 kg)
