Since Behringer's first synth release in 2016, it has become more affordable than ever before to own and explore classic analog, digital, and hybrid digital synths. For the adventurous musician who desires a deeper dive into the unique and unlimited possibilities of modular architecture synthesizer systems, Behringer has you covered with a wide range of Euro-rack compatible solutions.
Behringer offers complete synthesizer systems like the massive System-55, which comes pre-assembled with a fantastic 38 discrete analog modules pre-assembled into 2 Eurorack-go cases--with room to grow. Behringer also offers a staggering array of voltage-controlled modules to create a completely personalized semi-modular system. You’ll discover VCOs, Filters, Envelope generators, Triggers, Amplifiers, Sequencers, power supplies, MIDI converters, and more. Thanks to Behringer’s collection of historically accurate analog components, the creative freedom of modular synthesis has never been more accessible or affordable.
Behringer’s new System 100 is a series of 11 feature-packed, super-affordable modules based on the classic System 100m, made famous by Tears for Fears, the Human League, Tangerine Dream, Aphex Twin, and more. All 11 of Behringer’s 100 series modules can be collectively joined in one Eurorack case to create a complete System-100 synth--or used individually to add functions and flavor to your growing semi-modular synth set-up.
The 110 VCO/VCF/VCA is a complete synth voice with a VCO, filter, and amplifier section in one module. Because basic signal flow is internally wired for immediate, easy use while maintaining modular flexibility-- Expect a genuine 80s-style sound character and fat analog-era sonics with easy operation. The VCO generates triangle, ramp, square waveforms, and PWM with manual modulation, a 5-octave range, externally routable audio output control, and two CV inputs. The Low pass filter section has slider controls for cutoff and resonance, and the amplifier has a manually adjustable gain control plus low and high audio outputs. Both filter and amplifier sections feature CV and audio inputs for essential modular connectivity.
- An authentic reproduction of the original "System 100M" circuitry in Eurorack format
- VCO with 3 selectable waveforms--triangle, ramp, and square with PWM and a 5-octave range
- VCF with cutoff, frequency, and resonance controls.
- VCA with gain control, 2 audio inputs, low/high outputs, and 2 CV inputs
- 17 controls and switches, plus multiple input and output signal routing options.
- Oscillator PWM with manual and external CV control
- 16HP Eurorack size
| Product Name | Behringer 110 VCO/VCF/VCA Eurorack Module |
|---|---|
| Brand | Behringer |
| MPN | 000-DVC00-00010 |
| UPC | 4033653031783 |
What's in the Box?
- Behringer 110 VCO/VCF/VCA Eurorack Module
- Amazing VCO/VCF/VCA module from the '80s
- Authentic reproduction of original "System 100M" circuitry
- Complete synth voice with internal patched signal flow for ease of use
- VCO features 3 selectable waveforms (triangle, ramp and square with PWM)
- VCO offers pitch control over a wide range plus 1 audio output and 2 CV inputs
- VCF features cutoff, frequency and resonance controls plus 2 audio inputs and 2 CV inputs
- Oscillator PWM with manual and external CV control
- VCA features gain control plus 2 audio inputs, 2 audio outputs (low/high) and 2 CV inputs
- 17 controls and switches give you real-time access to all important parameters
- Eurorack specs: 16 HP, 60 mA +12 V, 50 mA -12 V
Inputs |
|
|---|---|
| Pulse width mod | Type: 3.5 mm TS jack, DC coupled
Impedance: >70 kΩ, unbalanced Maximum input level: 0 V to +10 V, 4% per volt |
| Signal input | Type: Impedance: >50 kΩ, unbalanced
Max input level: +17 dBu @ unity gain |
| VCO mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, 1 V/oct |
| VCF mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, 1 V/oct |
| VCA mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, typically 1 V per 10 dB |
Outputs |
|
| VCO output | Type: 3.5 mm TS jack, DC coupled
Impedance: 1 kΩ, unbalanced Max output level: 10 V p-p Frequency range with no external CV: <10 Hz to 500 Hz Frequency range using external CV: <1 Hz to 30 kHz |
| VCA output | Type: 2 x 3.5 mm TS jacks, AC coupled
High impedance: 1 kΩ, unbalanced Low impedance: 3 kΩ, unbalanced High max output level: +18 dBu Low max output level: -2 dBu High output noise: <-60 dBu, 22 Hz -22 kHz Low output noise: <-80 dBu, 22 Hz -22 kHz |
Controls |
|
| Pulse width manual | 50% to min |
| Waveform | Triangle, sawtooth, pulse |
| Range | 32’, 16’, 8’, 4’, 2’ |
| Pitch | 2 octave range |
| Cutoff frequency | 20 Hz to 20 kHz |
| Resonance | Off to self oscillation |
| Sig in level | -∞ to unity gain |
| Mod in level | -∞ to unity gain |
| VCA initial gain | Power |
Power |
|
| Power supply | Eurorack |
| Current draw | 80 mA (+12 V), 50 mA (-12 V) |
Physical |
|
| Dimensions | 81 x 129 x 46 mm (3.2 x 5.1 x 1.8") |
| Rack units | 16 HP |
| Weight | 0.19 kg (0.42 lbs) |
Behringer 110 VCO/VCF/VCA Eurorack Module
Since Behringer's first synth release in 2016, it has become more affordable than ever before to own and explore classic analog, digital, and hybrid digital synths. For the adventurous musician who desires a deeper dive into the unique and unlimited possibilities of modular architecture synthesizer systems, Behringer has you covered with a wide range of Euro-rack compatible solutions.
Behringer offers complete synthesizer systems like the massive System-55, which comes pre-assembled with a fantastic 38 discrete analog modules pre-assembled into 2 Eurorack-go cases--with room to grow. Behringer also offers a staggering array of voltage-controlled modules to create a completely personalized semi-modular system. You’ll discover VCOs, Filters, Envelope generators, Triggers, Amplifiers, Sequencers, power supplies, MIDI converters, and more. Thanks to Behringer’s collection of historically accurate analog components, the creative freedom of modular synthesis has never been more accessible or affordable.
Behringer’s new System 100 is a series of 11 feature-packed, super-affordable modules based on the classic System 100m, made famous by Tears for Fears, the Human League, Tangerine Dream, Aphex Twin, and more. All 11 of Behringer’s 100 series modules can be collectively joined in one Eurorack case to create a complete System-100 synth--or used individually to add functions and flavor to your growing semi-modular synth set-up.
The 110 VCO/VCF/VCA is a complete synth voice with a VCO, filter, and amplifier section in one module. Because basic signal flow is internally wired for immediate, easy use while maintaining modular flexibility-- Expect a genuine 80s-style sound character and fat analog-era sonics with easy operation. The VCO generates triangle, ramp, square waveforms, and PWM with manual modulation, a 5-octave range, externally routable audio output control, and two CV inputs. The Low pass filter section has slider controls for cutoff and resonance, and the amplifier has a manually adjustable gain control plus low and high audio outputs. Both filter and amplifier sections feature CV and audio inputs for essential modular connectivity.
- An authentic reproduction of the original "System 100M" circuitry in Eurorack format
- VCO with 3 selectable waveforms--triangle, ramp, and square with PWM and a 5-octave range
- VCF with cutoff, frequency, and resonance controls.
- VCA with gain control, 2 audio inputs, low/high outputs, and 2 CV inputs
- 17 controls and switches, plus multiple input and output signal routing options.
- Oscillator PWM with manual and external CV control
- 16HP Eurorack size
| Product Name | Behringer 110 VCO/VCF/VCA Eurorack Module |
|---|---|
| Brand | Behringer |
| MPN | 000-DVC00-00010 |
| UPC | 4033653031783 |
What's in the Box?
Behringer 110 VCO/VCF/VCA Eurorack Module- Amazing VCO/VCF/VCA module from the '80s
- Authentic reproduction of original "System 100M" circuitry
- Complete synth voice with internal patched signal flow for ease of use
- VCO features 3 selectable waveforms (triangle, ramp and square with PWM)
- VCO offers pitch control over a wide range plus 1 audio output and 2 CV inputs
- VCF features cutoff, frequency and resonance controls plus 2 audio inputs and 2 CV inputs
- Oscillator PWM with manual and external CV control
- VCA features gain control plus 2 audio inputs, 2 audio outputs (low/high) and 2 CV inputs
- 17 controls and switches give you real-time access to all important parameters
- Eurorack specs: 16 HP, 60 mA +12 V, 50 mA -12 V
Inputs |
|
|---|---|
| Pulse width mod | Type: 3.5 mm TS jack, DC coupled
Impedance: >70 kΩ, unbalanced Maximum input level: 0 V to +10 V, 4% per volt |
| Signal input | Type: Impedance: >50 kΩ, unbalanced
Max input level: +17 dBu @ unity gain |
| VCO mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, 1 V/oct |
| VCF mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, 1 V/oct |
| VCA mod input | Type: 2 x 3.5 mm TS jacks, summed
Impedance: >50 kΩ, unbalanced CV range: 0 V to +10 V, typically 1 V per 10 dB |
Outputs |
|
| VCO output | Type: 3.5 mm TS jack, DC coupled
Impedance: 1 kΩ, unbalanced Max output level: 10 V p-p Frequency range with no external CV: <10 Hz to 500 Hz Frequency range using external CV: <1 Hz to 30 kHz |
| VCA output | Type: 2 x 3.5 mm TS jacks, AC coupled
High impedance: 1 kΩ, unbalanced Low impedance: 3 kΩ, unbalanced High max output level: +18 dBu Low max output level: -2 dBu High output noise: <-60 dBu, 22 Hz -22 kHz Low output noise: <-80 dBu, 22 Hz -22 kHz |
Controls |
|
| Pulse width manual | 50% to min |
| Waveform | Triangle, sawtooth, pulse |
| Range | 32’, 16’, 8’, 4’, 2’ |
| Pitch | 2 octave range |
| Cutoff frequency | 20 Hz to 20 kHz |
| Resonance | Off to self oscillation |
| Sig in level | -∞ to unity gain |
| Mod in level | -∞ to unity gain |
| VCA initial gain | Power |
Power |
|
| Power supply | Eurorack |
| Current draw | 80 mA (+12 V), 50 mA (-12 V) |
Physical |
|
| Dimensions | 81 x 129 x 46 mm (3.2 x 5.1 x 1.8") |
| Rack units | 16 HP |
| Weight | 0.19 kg (0.42 lbs) |
