Loved for its two distinct modes of dynamic control and legendary for its sweet and musical sound quality, the vintage Neve 609 diode-bridge compressor/limiter remains among the most highly desired pieces of studio hardware worldwide. However, due to the scarcity and high demand for vintage examples, the 609's performance character has been inaccessible to all but the most well-funded producers and studios.
In some of the most exciting Pro-Audio-related news of 2024, Behringer’s design engineers (including alums from Rubert Neve’s team ) announced the creation and availability of the 369 2-channel Stereo Compressor/Limiter. So much more than a digital interpretation or hardware-based look-alike, the 369 faithfully recaptures the performance character of the near-mythical stereo bus compressor in an affordable accessible package.
Outstanding in broadcasting and music production applications, the Behringer 369 boasts a completely discrete signal path with specially crafted MIDAS input/output transformers for vintage-accurate performance results. The control surface features independent limiter and compressor sections with dual mono-capabilities or linked stereo mode for a very flexible range of sonic possibilities. Each section has a detailed range of controllability with a 2-way toggle switch for fast/slow attack times and threshold/recovery time controls, plus ratio and makeup gain controls on each individually usable compressor.
Product Name | Behringer 369 Classic 2-Channel Precision Stereo Compressor and Limiter |
---|---|
Brand | Behringer |
MPN | 0817-ABK86-US1 |
Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- 369
- IEC power cable
- Quick Start Guide
- A broad selection of compression ratios: 1.5:1, 2:1, 3:1, 4:1, 6:1
- Compression recovery time from 100 to 1,500 milliseconds with 2 auto-release presets
- Limiter recovery time of 50 to 800 milliseconds with 2 auto-release presets
- Threshold: -20dB to +10dB
- Frequency Response: 20Hz-20kHz (±0.5dB)
- Positive click rotary dials
- 2 vintage VU style gain reduction meters
- Transformer-balanced inputs and outputs on XLR connectors
- Inputs (2) XLR
- Outputs (2) XLR
- Rugged 2U-sized rackmount chassis
- Power: Standard IEC AC cable
- Auto-ranging universal switch-mode power supply
Audio Inputs |
|
---|---|
Type | 2x XLR, transformer balanced |
Impedance | 10 kΩ default / 600 Ω internal option |
Max. input level | > +26 dBu |
Audio Outputs |
|
Type | 2x XLR, transformer balanced |
Impedance | < 75 Ω balanced |
Max. output level | > +26 dBu with 600Ω Load |
System Specifications |
|
Frequency response | 20 Hz to 20 kHz, ±0.5 dB |
Distortion (THD+N) | < 0.03%, 50 Hz - 20 kHz, +4 dBu, compressor & gate in, attack = slow |
Noise | -79 dBu, 22 Hz - 22 kHz unweighted, compressor & gate in, attack = slow |
Circuit | Discrete Class-A |
Limiter |
|
Threshold | 2x Rotary switches, +4 dBu to +15 dBu in 0.5 dBu steps |
Recovery | 2x Rotary switches, 50 ms, 100 ms, 200 ms, 800 ms, a1 100 ms – 2 s, a2 50 ms – 5 s |
Limit in/out | 2x Toggle switches |
Attack fast/slow | 2x Toggle switches, Fast = 2 ms. Slow = 4 ms |
Compressor |
|
Threshold | 2x Rotary switches, +4 dBu to +15 dBu in 0.5 dB steps |
Recovery | 2x Rotary switches, 100 ms, 400 ms, 800 ms, 1500 ms, a1 100 ms – 2 s, a2 50 ms – 5 s |
Gain | 2x Rotary switches, 0 dB to +20 dB in 2 dB steps |
Ratio | 2x Rotary switches, 1.5:1, 2:1, 3:1, 4:1, 5:1 |
Comp in/out | 2x Toggle switches |
Attack fast/slow | 2x Toggle switches, Fast = 3 ms. Slow = 6 ms |
Gain reduction meters | 2x Analogue meters, 0 dB to 20 dB |
Controls |
|
Bypass/In | 2x Toggle switches, true relay bypass |
Mono/stereo | Toggle switch, stereo mode links the sidechains together |
Internal/external | Toggle switch, internal = local switch control, external = remote control |
External control connector | 15 pin female D connector for remote control of bypass, mono/stereo, sidechain link |
Behringer 369 Classic 2-Channel Precision Stereo Compressor and Limiter
Loved for its two distinct modes of dynamic control and legendary for its sweet and musical sound quality, the vintage Neve 609 diode-bridge compressor/limiter remains among the most highly desired pieces of studio hardware worldwide. However, due to the scarcity and high demand for vintage examples, the 609's performance character has been inaccessible to all but the most well-funded producers and studios.
In some of the most exciting Pro-Audio-related news of 2024, Behringer’s design engineers (including alums from Rubert Neve’s team ) announced the creation and availability of the 369 2-channel Stereo Compressor/Limiter. So much more than a digital interpretation or hardware-based look-alike, the 369 faithfully recaptures the performance character of the near-mythical stereo bus compressor in an affordable accessible package.
Outstanding in broadcasting and music production applications, the Behringer 369 boasts a completely discrete signal path with specially crafted MIDAS input/output transformers for vintage-accurate performance results. The control surface features independent limiter and compressor sections with dual mono-capabilities or linked stereo mode for a very flexible range of sonic possibilities. Each section has a detailed range of controllability with a 2-way toggle switch for fast/slow attack times and threshold/recovery time controls, plus ratio and makeup gain controls on each individually usable compressor.
Product Name | Behringer 369 Classic 2-Channel Precision Stereo Compressor and Limiter |
---|---|
Brand | Behringer |
MPN | 0817-ABK86-US1 |
Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- 369
- IEC power cable
- Quick Start Guide
- A broad selection of compression ratios: 1.5:1, 2:1, 3:1, 4:1, 6:1
- Compression recovery time from 100 to 1,500 milliseconds with 2 auto-release presets
- Limiter recovery time of 50 to 800 milliseconds with 2 auto-release presets
- Threshold: -20dB to +10dB
- Frequency Response: 20Hz-20kHz (±0.5dB)
- Positive click rotary dials
- 2 vintage VU style gain reduction meters
- Transformer-balanced inputs and outputs on XLR connectors
- Inputs (2) XLR
- Outputs (2) XLR
- Rugged 2U-sized rackmount chassis
- Power: Standard IEC AC cable
- Auto-ranging universal switch-mode power supply
Audio Inputs |
|
---|---|
Type | 2x XLR, transformer balanced |
Impedance | 10 kΩ default / 600 Ω internal option |
Max. input level | > +26 dBu |
Audio Outputs |
|
Type | 2x XLR, transformer balanced |
Impedance | < 75 Ω balanced |
Max. output level | > +26 dBu with 600Ω Load |
System Specifications |
|
Frequency response | 20 Hz to 20 kHz, ±0.5 dB |
Distortion (THD+N) | < 0.03%, 50 Hz - 20 kHz, +4 dBu, compressor & gate in, attack = slow |
Noise | -79 dBu, 22 Hz - 22 kHz unweighted, compressor & gate in, attack = slow |
Circuit | Discrete Class-A |
Limiter |
|
Threshold | 2x Rotary switches, +4 dBu to +15 dBu in 0.5 dBu steps |
Recovery | 2x Rotary switches, 50 ms, 100 ms, 200 ms, 800 ms, a1 100 ms – 2 s, a2 50 ms – 5 s |
Limit in/out | 2x Toggle switches |
Attack fast/slow | 2x Toggle switches, Fast = 2 ms. Slow = 4 ms |
Compressor |
|
Threshold | 2x Rotary switches, +4 dBu to +15 dBu in 0.5 dB steps |
Recovery | 2x Rotary switches, 100 ms, 400 ms, 800 ms, 1500 ms, a1 100 ms – 2 s, a2 50 ms – 5 s |
Gain | 2x Rotary switches, 0 dB to +20 dB in 2 dB steps |
Ratio | 2x Rotary switches, 1.5:1, 2:1, 3:1, 4:1, 5:1 |
Comp in/out | 2x Toggle switches |
Attack fast/slow | 2x Toggle switches, Fast = 3 ms. Slow = 6 ms |
Gain reduction meters | 2x Analogue meters, 0 dB to 20 dB |
Controls |
|
Bypass/In | 2x Toggle switches, true relay bypass |
Mono/stereo | Toggle switch, stereo mode links the sidechains together |
Internal/external | Toggle switch, internal = local switch control, external = remote control |
External control connector | 15 pin female D connector for remote control of bypass, mono/stereo, sidechain link |
