AMP800
If you’re tracking more than one musician at a time, or if everyone in a group wants to listen to a playback, you need a monitor distribution system. The compact, flexible AMP800 can power up to 8 pairs of headphones and up to 2 different stereo mixes.
Altogether Now
The AMP800 features 4 totally independent stereo high-power amplifier sections, each with dual outputs. You can use the Phones Level control plus the accurate 6-digit LED output meter per channel for easy level monitoring. There are 2 balanced Stereo Main Inputs with independent Level and Balance controls for individual mixes, selectable for all 4 of the headphone amplifiers.
Link Up
If you need to accommodate more than 8 listeners, the convenient Link Out A enables cascading additional AMP800s. Long-term reliability is guaranteed thanks to high-quality potentiometers and illuminated switches, and our ultra low-noise audio operational amplifiers provide outstanding sonic performance.
| Product Name | Behringer AMP800 V2 Ultra-Compact 4-Channel Stereo Headphone Amplifier |
|---|---|
| Brand | Behringer |
| Condition | New |
| MPN | AMP800 V2 |
| UPC | 4033653071796 |
| Shipping Option | Free Shipping on orders over $94.72 |
What's in the Box?
- Behringer AMP800 V2 Ultra-Compact 4-Channel Stereo Headphone Amplifier
- Ultra-compact headphone amplifier system for studio and stage applications
- 4 independent stereo high-power amplifier sections
- Highest audio quality with virtually all types of headphones even at maximum volume
- Phones Level control plus accurate 6-segment LED output meter per channel for easy level monitoring
- 2 balanced stereo main inputs with independent Level and Balance controls for individual mixes, selectable for all 4 headphone amplifiers
- Accurate 6-segment LED main level meter for precise level indication of both line inputs
- 2 headphone outputs per channel (front and rear panel) allow a total of 8 headphones to be simultaneously connected
- Parallel Link Output allows cascading of several headphone amplifiers
- High-quality potentiometers and illuminated switches for long-term reliability
- All Mini Series models can be stacked on top of each other to create an ultra-compact signal processor solution
Input |
|
|---|---|
| Type | ¼" TRS connector, balanced |
| Impedance | approx. 20 kΩ, balanced / approx. 10 kΩ, unbalanced |
| CMRR | 40 dB typ. @ 1 kHz |
Phones Out |
|
| Type | ¼" TRS connector, stereo |
| Impedance | min. 100 Ω |
| Max. output level | +13 dBu @ 100 Ω load |
Link Out A |
|
| Type | ¼" TRS connector, balanced |
System Specifications |
|
| Frequency response | 10 Hz to 120 kHz, -3 dB |
| Dynamic range | 108 dB, 10 Hz to 22 kHz (100 Ω load) |
| Distortion | 0.007% typ. (100 Ω load) |
| Crosstalk | >80 dB @ 1 kHz |
| Signal-to-noise ratio | 10 Hz to 22 kHz >95 dB @ 0 dBu, a-weighted |
Amplifier |
|
| Max. output level | +21 dBm / 124 mW (100 Ω load) |
| Min. output impedance | 47 Ω |
Power Supply |
|
| Mains connection | external power supply, DC 12V/1A |
| Mains Voltage | USA/Canada - 120 V~, 60Hz U.K./Australia - 240 V~, 50Hz China - 220 V~, 50 Hz Europe - 230 V~, 50 Hz Japan - 100 V~, 50 - 60 Hz |
| Power consumption | 12 W |
Dimensions/Weight |
|
| Dimensions (H x W x D) | approx. 1.89 x 9.55 x 4.72" (approx. 48 x 242.6 x 120 mm) |
| Weight | approx. 1.7 lbs / 0.77 kg |
Behringer AMP800 V2 Ultra-Compact 4-Channel Stereo Headphone Amplifier
AMP800
If you’re tracking more than one musician at a time, or if everyone in a group wants to listen to a playback, you need a monitor distribution system. The compact, flexible AMP800 can power up to 8 pairs of headphones and up to 2 different stereo mixes.
Altogether Now
The AMP800 features 4 totally independent stereo high-power amplifier sections, each with dual outputs. You can use the Phones Level control plus the accurate 6-digit LED output meter per channel for easy level monitoring. There are 2 balanced Stereo Main Inputs with independent Level and Balance controls for individual mixes, selectable for all 4 of the headphone amplifiers.
Link Up
If you need to accommodate more than 8 listeners, the convenient Link Out A enables cascading additional AMP800s. Long-term reliability is guaranteed thanks to high-quality potentiometers and illuminated switches, and our ultra low-noise audio operational amplifiers provide outstanding sonic performance.
| Product Name | Behringer AMP800 V2 Ultra-Compact 4-Channel Stereo Headphone Amplifier |
|---|---|
| Brand | Behringer |
| Condition | New |
| MPN | AMP800 V2 |
| UPC | 4033653071796 |
| Shipping Option | Free Shipping on orders over $94.72 |
What's in the Box?
Behringer AMP800 V2 Ultra-Compact 4-Channel Stereo Headphone Amplifier- Ultra-compact headphone amplifier system for studio and stage applications
- 4 independent stereo high-power amplifier sections
- Highest audio quality with virtually all types of headphones even at maximum volume
- Phones Level control plus accurate 6-segment LED output meter per channel for easy level monitoring
- 2 balanced stereo main inputs with independent Level and Balance controls for individual mixes, selectable for all 4 headphone amplifiers
- Accurate 6-segment LED main level meter for precise level indication of both line inputs
- 2 headphone outputs per channel (front and rear panel) allow a total of 8 headphones to be simultaneously connected
- Parallel Link Output allows cascading of several headphone amplifiers
- High-quality potentiometers and illuminated switches for long-term reliability
- All Mini Series models can be stacked on top of each other to create an ultra-compact signal processor solution
Input |
|
|---|---|
| Type | ¼" TRS connector, balanced |
| Impedance | approx. 20 kΩ, balanced / approx. 10 kΩ, unbalanced |
| CMRR | 40 dB typ. @ 1 kHz |
Phones Out |
|
| Type | ¼" TRS connector, stereo |
| Impedance | min. 100 Ω |
| Max. output level | +13 dBu @ 100 Ω load |
Link Out A |
|
| Type | ¼" TRS connector, balanced |
System Specifications |
|
| Frequency response | 10 Hz to 120 kHz, -3 dB |
| Dynamic range | 108 dB, 10 Hz to 22 kHz (100 Ω load) |
| Distortion | 0.007% typ. (100 Ω load) |
| Crosstalk | >80 dB @ 1 kHz |
| Signal-to-noise ratio | 10 Hz to 22 kHz >95 dB @ 0 dBu, a-weighted |
Amplifier |
|
| Max. output level | +21 dBm / 124 mW (100 Ω load) |
| Min. output impedance | 47 Ω |
Power Supply |
|
| Mains connection | external power supply, DC 12V/1A |
| Mains Voltage | USA/Canada - 120 V~, 60Hz U.K./Australia - 240 V~, 50Hz China - 220 V~, 50 Hz Europe - 230 V~, 50 Hz Japan - 100 V~, 50 - 60 Hz |
| Power consumption | 12 W |
Dimensions/Weight |
|
| Dimensions (H x W x D) | approx. 1.89 x 9.55 x 4.72" (approx. 48 x 242.6 x 120 mm) |
| Weight | approx. 1.7 lbs / 0.77 kg |
