Made for Video. Ready for Anything.
FLOW 4V is built for modern video production.
Capture clean, multitrack audio on set.
Stay perfectly in sync with your camera.
Move faster from shoot to edit.
Film. Stream. Create content. Without compromise.
No-Clip Recording
Forget ruined takes. FLOW 4V captures everything from whispers to impact hits.
4 dual-gain mic preamps dual-stage A/D converters.
An extreme 142 dB dynamic range.
Quiet details stay clean. Loud moments virtually impossible to clip.
Multi-track Recording, Done Right
Record every source as its own track while simultaneously creating a finished stereo mix. FLOW 4V is a true 10-track multitrack recorder built for video workflows. Fast on set, flexible in post.
- Up to 8 isolated input tracks
- Dedicated stereo mix recorded simultaneously
- Mic, line, USB/Bluetooth sources captured independently
| Product Name | Behringer FLOW 4V Digital Audio Mixer |
|---|---|
| Brand | Behringer |
| Condition | New |
| MPN | FLOW4V |
| UPC | 787790575559 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Behringer FLOW 4V Digital Audio Mixer
- Ultra-low noise, high headroom field recorder and mixer with wireless remote control
- 4 Midas microphone preamps with phantom power and dual- stage A/D converters for 138 dB dynamic range 10 channels recording to SD cards and to the USB class- compliant interface with 32-bit float or 24-bit fixed point
- No analog gain setting required due to the dual-stage conversion, float recordings allow gain adjustment in post-processing
- Full-featured 8-channel mixer with level, pan, low-cut, tone, high-cut and dynamics
- Up to 8 channels of automixing with smooth gain-sharing algorithm
- Pre-record buffer for always capturing that "golden moment"
- Recordings to SD card are automatically copied to an attached USB stick after stopping — no risk for losing SD files
- StageConnect multi-channel uncompressed audio transmission at sub-millisecond latency using standard XLR/DMX cable
- Optional StageConnect FLOW 4VIO offers remote power, 4 additional microphone inputs, 2 headphone outputs
- SPMTE timecode can be generated internally for synchronizing other devices
- Aux Stereo Input, can also receive SMPTE clock to synchronize the internal clock
- Bluetooth audio can be received from mobile devices for Talkback or Playback
- Camera video CEC signal can be received via HDMI for triggering the audio recording
- Powered via StageConnect or via USB-C, power adaptor included
- 1/4-20 integrated thread and screw attaches to camera and tripods, with integrated Allen wrench
- FLOW 4V MIX app for iOS and Android offers remote control from mobile devices via Bluetooth LE
General Specifications |
|
|---|---|
| Frequency Range (±1 dB) | 5 Hz – 22 kHz |
| Dynamic Range (Inputs) | 140 dB (142 dB A-weighted) |
| Frame Rates | 29.98, 24, 25, 30, 50, 60 fps |
Mic Inputs |
|
| Type | 4 × XLR / 1/4" TRS combo jacks, balanced |
| EIN (20 Hz – 20 kHz) | -130 dBu (-132 dBu A-weighted) |
| Distortion (THD + N) |
0.007% @ -40 dBu in 0.0003% @ -20 dBu in |
| Crosstalk Rejection @ 1 kHz | -110 dB (adjacent channels) |
| Max Input Level |
XLR: +18 dBu TRS: +29.5 dBu |
| Input Impedance |
XLR: 9.5 kΩ balanced TRS: 30 kΩ balanced |
| Max Gain | +70 dB |
| Phantom Power | +48 V, switchable |
AUX In |
|
| Type | 1 × 1/8" TRS jack, stereo |
| Distortion (THD + N) | 0.008% @ +6 dBu in |
| Max Input Level | +24 dBu |
| Impedance | 10 kΩ |
Headset In / Out |
|
| Type | 1 × 1/8" TRRS jack, stereo + mic in |
| Impedance | 40 Ω |
| Max Input Level | +10 dBu |
| Max Output Level |
110 mW @ 30 Ω 110 mW @ 75 Ω 75 mW @ 300 Ω |
Stereo Out |
|
| Type | 1 × 1/8" TRS jack, stereo |
| Impedance | 100 Ω |
| Max Output Level | +4.6 dBu |
Phones Outputs |
|
| Type | See Headset |
| Max Output Level (30 Ω load) | See Headset |
| Distortion (THD + N) | See Headset |
USB Audio Interface |
|
| USB Type | USB 2.0 |
| Connector | USB Type-C |
| Sample Rate | 48 kHz |
| Bit Depth | 24-bit / 32-bit float |
| Channels at Host | 12 In / 2 Out |
HDMI |
|
| Type | Micro HDMI |
| CEC | Camera-controlled record start |
Bluetooth |
|
| Frequency Range | 2402 MHz – 2480 MHz |
| Channels | 79 |
| Version | Bluetooth 4.0 Dual Mode |
| Compatibility | A2DP 1.2 profile |
| Max Range | 12 m (without interference) |
| Max Output Power | 9.6 dBm |
| Antenna Gain | 1.84 dBi |
Power |
|
| Connector | USB-C |
| Power Supply | USB-C PD |
| Power Consumption | 10 W |
Dimensions / Weight |
|
| Dimensions (H × W × D) | 53 × 184 × 128 mm |
| Weight | 800 g |
Behringer FLOW 4V Digital Audio Mixer
Details
Made for Video. Ready for Anything.
FLOW 4V is built for modern video production.
Capture clean, multitrack audio on set.
Stay perfectly in sync with your camera.
Move faster from shoot to edit.
Film. Stream. Create content. Without compromise.
No-Clip Recording
Forget ruined takes. FLOW 4V captures everything from whispers to impact hits.
4 dual-gain mic preamps dual-stage A/D converters.
An extreme 142 dB dynamic range.
Quiet details stay clean. Loud moments virtually impossible to clip.
Multi-track Recording, Done Right
Record every source as its own track while simultaneously creating a finished stereo mix. FLOW 4V is a true 10-track multitrack recorder built for video workflows. Fast on set, flexible in post.
- Up to 8 isolated input tracks
- Dedicated stereo mix recorded simultaneously
- Mic, line, USB/Bluetooth sources captured independently
| Product Name | Behringer FLOW 4V Digital Audio Mixer |
|---|---|
| Condition | New |
| MPN | FLOW4V |
| UPC | 787790575559 |
What's in the Box?
Behringer FLOW 4V Digital Audio Mixer
Features
- Ultra-low noise, high headroom field recorder and mixer with wireless remote control
- 4 Midas microphone preamps with phantom power and dual- stage A/D converters for 138 dB dynamic range 10 channels recording to SD cards and to the USB class- compliant interface with 32-bit float or 24-bit fixed point
- No analog gain setting required due to the dual-stage conversion, float recordings allow gain adjustment in post-processing
- Full-featured 8-channel mixer with level, pan, low-cut, tone, high-cut and dynamics
- Up to 8 channels of automixing with smooth gain-sharing algorithm
- Pre-record buffer for always capturing that "golden moment"
- Recordings to SD card are automatically copied to an attached USB stick after stopping — no risk for losing SD files
- StageConnect multi-channel uncompressed audio transmission at sub-millisecond latency using standard XLR/DMX cable
- Optional StageConnect FLOW 4VIO offers remote power, 4 additional microphone inputs, 2 headphone outputs
- SPMTE timecode can be generated internally for synchronizing other devices
- Aux Stereo Input, can also receive SMPTE clock to synchronize the internal clock
- Bluetooth audio can be received from mobile devices for Talkback or Playback
- Camera video CEC signal can be received via HDMI for triggering the audio recording
- Powered via StageConnect or via USB-C, power adaptor included
- 1/4-20 integrated thread and screw attaches to camera and tripods, with integrated Allen wrench
- FLOW 4V MIX app for iOS and Android offers remote control from mobile devices via Bluetooth LE
Tech Specs
General Specifications |
|
|---|---|
| Frequency Range (±1 dB) | 5 Hz – 22 kHz |
| Dynamic Range (Inputs) | 140 dB (142 dB A-weighted) |
| Frame Rates | 29.98, 24, 25, 30, 50, 60 fps |
Mic Inputs |
|
| Type | 4 × XLR / 1/4" TRS combo jacks, balanced |
| EIN (20 Hz – 20 kHz) | -130 dBu (-132 dBu A-weighted) |
| Distortion (THD + N) |
0.007% @ -40 dBu in 0.0003% @ -20 dBu in |
| Crosstalk Rejection @ 1 kHz | -110 dB (adjacent channels) |
| Max Input Level |
XLR: +18 dBu TRS: +29.5 dBu |
| Input Impedance |
XLR: 9.5 kΩ balanced TRS: 30 kΩ balanced |
| Max Gain | +70 dB |
| Phantom Power | +48 V, switchable |
AUX In |
|
| Type | 1 × 1/8" TRS jack, stereo |
| Distortion (THD + N) | 0.008% @ +6 dBu in |
| Max Input Level | +24 dBu |
| Impedance | 10 kΩ |
Headset In / Out |
|
| Type | 1 × 1/8" TRRS jack, stereo + mic in |
| Impedance | 40 Ω |
| Max Input Level | +10 dBu |
| Max Output Level |
110 mW @ 30 Ω 110 mW @ 75 Ω 75 mW @ 300 Ω |
Stereo Out |
|
| Type | 1 × 1/8" TRS jack, stereo |
| Impedance | 100 Ω |
| Max Output Level | +4.6 dBu |
Phones Outputs |
|
| Type | See Headset |
| Max Output Level (30 Ω load) | See Headset |
| Distortion (THD + N) | See Headset |
USB Audio Interface |
|
| USB Type | USB 2.0 |
| Connector | USB Type-C |
| Sample Rate | 48 kHz |
| Bit Depth | 24-bit / 32-bit float |
| Channels at Host | 12 In / 2 Out |
HDMI |
|
| Type | Micro HDMI |
| CEC | Camera-controlled record start |
Bluetooth |
|
| Frequency Range | 2402 MHz – 2480 MHz |
| Channels | 79 |
| Version | Bluetooth 4.0 Dual Mode |
| Compatibility | A2DP 1.2 profile |
| Max Range | 12 m (without interference) |
| Max Output Power | 9.6 dBm |
| Antenna Gain | 1.84 dBi |
Power |
|
| Connector | USB-C |
| Power Supply | USB-C PD |
| Power Consumption | 10 W |
Dimensions / Weight |
|
| Dimensions (H × W × D) | 53 × 184 × 128 mm |
| Weight | 800 g |
