At introduction, the original MonoPoly’s outstanding analog capabilities were somewhat overlooked in the wake of the emerging digital era synths—although not before finding its way into the hands of Depeche Mode and the Chemical Brothers, to name just a few. Today’s enthusiasts have re-discovered the vintage “sleeper’ for all its charms and abilities. Crafted with meticulous attention to detail, Behringer’s MonoPoly is closely based on the short-lived 1982 classic, with some essential modern features, road-ready construction, and a very accessible price.
Equipped with four analog oscillators (each capable of four different waveforms), MonoPoly can produce chest-pounding bass lines and a highly present upper range that allows solos and hooks to slice through the densest of mixes. “Paraphonic” Mode (four VCOs into one ASDR) expands this very capable Mono-Synth into a four-voice powerhouse of pulsating pads and rich orchestral string sounds across the entire 6-octave range.
True to early 80s analog form, the Behringer MonoPoly is outfitted with a classic VCF, two LFOs, two envelopes, sync, cross modulation, portamento, 24db low pass filter, and a full-featured arpeggiator. The vintage-style wood-capped enclosure houses a semi-weighted velocity-sensitive key bed with 37 full-sized keys, plus a spring-loaded pitch bender and mod wheel. The control panel lays flat with the keys or can be tilted up for easy access to all 62 dials and switches, which will keep you happily tweaking and sculpting ‘till it sounds just right. On top of everything--Behringer’s MonoPoly is equipped with multiple inputs and outputs for control over filter cutoff, pitch, CV/Gate, and MIDI connectivity, bringing this classic effortlessly into the modern world.
Product Name | Behringer MonoPoly Analog 4-Voice Polyphonic Synthesizer |
---|---|
Brand | Behringer |
MPN | MONOPOLY |
UPC | 644216642205 |
Shipping Option | Free Shipping to the Continental U.S. |
- A faithfully recreated and gently modernized take on the 1982 Analog Classic
- Mono or 4-voice Paraphonic Mode
- Transpose, chord memory, unison, and unison/share mode
- 4 VCOs with 4 selectable waveforms (Triangle, Reverse Sawtooth, PWM, PW)
- 2 LFOs, 2 envelopes (filter and amp)
- 24dB lowpass filter
- Arpeggiator w/latch, playback order, and range
- Portamento
- 37 semi-weighted, full-sized, velocity-sensitive keys, pitch bender, and mod wheel
- MIDI in/out/thru
- USB (Type B)
- Output (1) 1/4-inch unbalanced
- Headphones (1) 1/4-inch TRS, stereo
- 12V DC 1000mA power supply (included)
Synthesizer Architecture |
|
---|---|
Modes | Chord memory, unison mono, unison share, poly |
Type | Analog |
Oscillators | 4 (32.7 Hz to 4.186 Hz) |
LFO | MG1: 0.1 Hz to 20 Hz
MG2: 0.1 Hz to 30 Hz |
VCF | Low pass filter, 24 dB/oct. slope |
Envelopes | VCA, VCF |
MIDI channels | 16 |
Connectivity |
|
MIDI in / out/ thru | 5-pin DIN |
USB (MIDI) | Type B |
Main output | 1 x 1/4" TS, unbalanced
Max. output level: +6 dBu Impedance: 700 Ω |
Headphones | 1 x 1/4" TRS, stereo
Max. output level: -2 dBu |
External control inputs | Arpeggiator Sync in, Portamento, VCF cutoff freq mod, VCO freq mod, Trigger in, CV in |
Internal control outputs | Trigger out, CV out, Switch |
General Controls |
|
Knobs | Output volume, Bend wheel intensity, MG 1 wheel intensity, Portamento, Master tune, Detune |
Switches | Output, Bend wheel, MG 1 wheel, Transpose |
LED (red) | Mg 1 frequency, Mg 2 frequency |
Modulation |
|
Knobs | MG 1 frequency, MG 1 waveform, MG 2 frequency, PWM intensity, PW intensity, X-mod, Freq mod |
Switches | PMW, Freq mod, Mode |
Arpeggiator |
|
Switches | Full/ 2 octave/ 1 octave, Up/ down/ up+down, Latch/ on/ off |
Switch (with LED) | Effects: on/ off |
Switches (with LED) | Key Assign Mode: Hold, Chord memory (mono), Unison (mono), Unison/share (poly), Poly |
Oscillator Bank |
|
Knobs | Tune (OSC 2, 3, and 4), Waveform, Octave, Level |
LED (red) | VCO 1, 2, 3, 4 on |
VCF Section |
|
Knobs | Cutoff frequency, Resonance, EG Intensity, Keyboard track |
VCF Envelope Generator |
|
Knobs | Attack time, Decay time, Sustain level, Release time |
VCA Envelope Generator |
|
Knobs | Attack time, Decay time, Sustain level, Release time |
Lower Right Section |
|
Knobs | Noise Level |
Switches | Trigger, Auto Damp |
Keyboard and Wheels |
|
Wheels | Pitch, MG 1 |
Keyboard | 37, semi-weighted, full-size keys with velocity |
USB |
|
Type | Class-compliant USB 2.0, type B |
Supported operating systems | Windows XP or higher, Mac OS X 10.6.8 or higher |
Power Requirements |
|
External power adaptor | 12 VDC 1000 mA |
Power consumption | 9 W max. |
Environmental |
|
Operating temperature range | 5°C – 40°C (41°F – 104°F) |
Physical |
|
Dimensions (H x W x D) | 90 x 648 x 361 mm (3.5 x 25.5 x 14.2") |
Weight | 10.3 kg (22.7 lbs) |
