The SX3242FX EURODESK mixer is designed to meet the needs of studio and live mixing applications, with a comprehensive set of features that combine sonic excellence and a full complement of mixing & sound modification tools.
This four-bus audio mixer features ultra-low noise, high-headroom XENYX microphone preamps. Mono input channels feature three-band, semi-parametric mid-range EQ with Neo-classic "British" response. Behringer 's stereo input channels provide precise four-band equalization. Each input has four aux sends with two sends switchable between pre/post fader, for a flexible mix of monitor and effects applications.
The EURODESK mixer's external signal processing racks can be largely eliminated, thanks to the two integrated effects processors and stereo 9-band graphic EQ. One-hundred 24-bit / 96kHz studio-quality effects presets can be called-up and assigned to one or both internal effects buses. Main or Monitor output EQ is set and fine-tuned with the intuitive FBQ Feedback Detection display.
When external processing is required, the SX3242FX provides extensive insert patch-points for input channels and main outputs. The Master section offers a wealth of features such as multiple aux and stereo returns, switchable SIP / PFL monitoring, Talkback, metering and more.
The mixer's internal auto-ranging power supply (100 240V), gold-plated XLR output connectors and rugged steel construction ensure that this console will travel anywhere to tackle any recording or mixing task with professional audio quality.
| Product Name | Behringer SX3242FX Eurodesk 32-Input 4-Bus Studio/Live Mixer |
|---|---|
| Brand | Behringer |
| Condition | New |
| MPN | SX3242FX |
| UPC | 705105732435 |
| Shipping Option | Free Shipping to the Continental U.S. |
- Premium ultra-low noise, high-headroom analog mixer
- 24 state-of-the-art XENYX Mic Preamps comparable to stand-alone boutique preamps
- Neo-classic "British" 3-band EQs with semi-parametric mid band for warm and musical sound
- 2 independent studio-grade 24-bit stereo FX processors with 99 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
- High-precision 9-band stereo graphic EQ allows precise frequency correction of monitor or main mixes
- Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies
- Peak LEDs, Mute, Main mix and subgroup routing switches, Solo and PFL functions on all channels
- 2 fully featured stereo input channels with 4-band EQ plus 2 additional stereo input channels with Level and pre-fader Aux controls
- Inserts on each mono channel and main mix for flexible connection of outboard equipment
- 4 Subgroup outputs and additional Mono output with sweepable Low Pass filter for subwoofer application
- 4 Aux sends per channel: 2 pre/post fader switchable for monitoring/FX applications, 2 post fader (for internal FX or as external send)
- Balanced Main mix outputs with 1/4" jack and gold-plated XLR connectors, separate Control room, Headphone and stereo Tape outputs
- Solo-In-Place and Pre-Fader-Listen functions plus full-featured Talkback section
- Standby switch mutes all channels during breaks while background music is provided via CD/Tape inputs
- Long-wearing 60 mm logarithmic-taper faders and sealed rotary controls
- Internal autorange power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
Mono Inputs |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Microphone inputs (XENYX Mic preamp) | XLR connector, electronically balanced, discrete input circuit | ||||||||
| Mic E.I.N. (20 Hz - 20 kHz) | @ 0 Ω source resistance: -134 dB / 135.7 dB A-weighted @ 50 Ω source resistance: -131 dB / 133.3 dB A-weighted @ 150 Ω source resistance: -129 dB / 130.5 dB A-weighted |
||||||||
Frequency Response |
|||||||||
| Gain range | +10 dB to +60 dB | ||||||||
| Max. input level | +12 dBu @ +10 dB GAIN | ||||||||
| Impedance | approx. 2.6 kΩ balanced | ||||||||
| Signal-to-noise ratio | 110 dB / 112 dB A-weighted (0 dBu In @ +22 dB GAIN) | ||||||||
| Distortion (THD + N) | 0.005 % / 0.004 % A-weighted | ||||||||
Line Input |
|||||||||
| Type | ¼" TRS jack, electronically balanced | ||||||||
| Impedance | approx. 20 kΩ balanced, approx. 10 kΩ unbalanced | ||||||||
| Gain range | -10 dB to +40 dB | ||||||||
| Max. input level | +22 dBu @ 0 dB GAIN | ||||||||
| Fade-Out Attenuation (Crosstalk Attenuation) | Main fader closed: 90 dB Channel muted: 84 dB Channel fader muted: 85 dB |
||||||||
Stereo Inputs |
|||||||||
| Type | 2 x ¼" TRS jack, balanced | ||||||||
| Impedance | approx. 20 kΩ balanced, approx. 10 kΩ unbalanced | ||||||||
| Gain range | -20 dB to +20 dB | ||||||||
| Max. input level | +22 dBu @ 0 dB GAIN | ||||||||
CD/Tape In |
|||||||||
| Type | RCA connector | ||||||||
| Impedance | approx. 10 kΩ | ||||||||
| Max. input level | +22 dBu | ||||||||
Equalizer |
|||||||||
| EQ Mono Channels |
|
||||||||
| EQ Stereo Channels |
|
||||||||
Main Outputs (XLR) |
|||||||||
| Type | XLR connector, electronically balanced | ||||||||
| Impedance | approx. 240 Ω balanced, approx. 120 Ω unbalanced | ||||||||
| Max. output level | +28 dBu | ||||||||
Main Outputs (¼") |
|||||||||
| Type | ¼" TRS jack, electronically balanced | ||||||||
| Impedance | approx. 240 Ω balanced, approx. 120 Ω unbalanced | ||||||||
| Max. output level | +28 dBu | ||||||||
Main Inserts |
|||||||||
| Type | ¼" TRS jack, unbalanced | ||||||||
| Max. input level | +22 dBu | ||||||||
Mono Output |
|||||||||
| Type | ¼" mono jack, unbalanced | ||||||||
| Impedance | approx. 120 Ω | ||||||||
| Max. output level | +22 dBu | ||||||||
Low pass |
|||||||||
| Type | variable | ||||||||
| Frequency Range | 30 Hz to 200 Hz | ||||||||
| Slope | 18 dB/oct. | ||||||||
Phones/CTRL Room Output |
|||||||||
| Type | ¼" TRS jack, unbalanced | ||||||||
| Max. output level | +19 dBu / 150 Ω (+25 dBm) | ||||||||
CD/Tape Out |
|||||||||
| Type | RCA connector | ||||||||
| Impedance | approx. 1 kΩ | ||||||||
| Max. output level | +22 dBu | ||||||||
DSP |
|||||||||
| Type | Texas Instruments | ||||||||
| Converter | 24-bit delta-sigma, 64/128-times oversampling | ||||||||
| Sampling rate | 46 kHz | ||||||||
Main Mix System Data (Noise) |
|||||||||
| Main mix @ -∞, channel fader @ -∞ | -100 dB / -102.5 dB A-weighted | ||||||||
| Main mix @ 0 dB, channel fader @ -∞ | -82 dB / -85 dB A-weighted | ||||||||
| Main mix @ 0 dB, channel fader @ 0 dB | -72 dB / -75 dB A-weighted | ||||||||
Power Supply |
|||||||||
| Power consumption | 50 W | ||||||||
| Fuse (100 - 240 V~, 50/60 Hz) | T 2,0 A H 250 V | ||||||||
| Mains connector | Standard IEC receptacle | ||||||||
Physical/Weight |
|||||||||
| Dimensions (H x W x D) | 100 x 896 x 410 mm (3.9 x 35.3 x 16.1") | ||||||||
| Weight (net) | 11.0 kg (24.3 lbs) | ||||||||
