Complete with all the legendary sounds, expanded “mod-shop” performance, and priced like it’s 1981 again. Based on the “little silver bass box” behind New-Wave, Chicago, Acid, Big Beat, and virtually all styles of House and EDM genres, the TD-3-MO is “all that” and more. Just like the celebrated but short live original, the Behringer TD-3-MO delivers powerful, hypnotic bass lines, unique filter effects, and a bone-simple control layout—for an experience that’s as much fun as it is essential.
To begin with, the TD-3-MO Bass Line features a pure analog signal path, authentic transistor-controlled wave-shaping circuitry, vintage-style VCO, VCF, VCA, and 16-step sequencer and arpeggiator. The legendary 4-pole “ladder-style” low-pass filter helps provide massive low-end sonics and features cut-off, resonance, envelope, decay, and accent control for that unique squelching, 303-inspired voice.
Aside from extraordinarily affordable pricing, Behringer’s collection of re-imagined analog essentials is also famous for including a few modern improvements without sacrificing authenticity. The TD-3 “MODIFIED” edition includes all the modern connectivity and hot-rodded sonics you’ve ever dreamed of:
A 16-note Poly Chain function lets you combine multiple synths for up to 16-voice polyphony. The expanded MIDI-CV controllable filter section provides independent slide time, three-mode Sweep Speed, Accent Sweep, Soft Attack, and overdrive controls. Add depth and power to the already massive bass sounds with an additional three-octave sub-oscillator and more. Now you can say, “Everyone Needs a TD-3 MO.”
Product Name | Behringer TD-3-MO-BK Analog Bass Line Synthesizer - Black |
---|---|
Brand | Behringer |
MPN | TD-3-MO-BK |
UPC | 644216666508 |
Shipping Option | Free Shipping to the Continental U.S. |
- A “Modded Out” revision of the Acid House bass sequencer classic
- Single oscillator with switchable sawtooth and square waveforms
- All-analog VCO, VCF, VCA signal path design
- (13) Key buttons
- Tempo, Track Pattern Group, Mode, and Volume control knobs
- Sawtooth/Pulse Waveforms with Cutoff and Resonance Controls
- (250) User Patterns
- 16-step, 7-track Sequencer:
- Poly Chain for up to 16-voice polyphony
- Programmable accents, slides, filter FM, sub-oscillator, overdrive
- Input (1) 1/8" TS
- Output ()1) 1/4", (1) 1/8" (filter out)
- Headphones: (1) 1/8"
- MIDI In, Out/Thru, and USB
- CV in/out, Gate in/out, Filter FM in, Filter CV in, Accent in/out, Slide in, Sync in
- USB (1) Type B9V DC power supply (included)
Synthesizer Architecture |
|
---|---|
Number of voices | Monophonic |
Type | Analog |
Oscillators | 1 |
Connectivity |
|
Power input | DC input connector |
Power switch | Push button on/off |
MIDI In/Thru | MIDI In and MIDI Thru, 5-pin DIN |
USB (MIDI) | USB 2.0, type B |
Outputs | Line output: 1/4" TRS, unbalanced, max. +8 dBu |
Output impedance | 1.5 kΩ |
Headphones | 3.5 mm TRS, max. 50 mW/32 Ω (1 KHz, 1% THD) |
Headphones output impedance | 15 Ω |
USB Type | Class compliant USB 2.0, type B |
Supported Operating Systems | Windows 7 or higher Mac OS X 10.6.8 or higher |
Inputs and Outputs (TS 3.5 mm) |
|
Inputs | Filter in: -6 V to +6 V Filter FM in: 0 V to +12 V Filter CV in: 0 V to +12 V Accent in: off: 0 V, on: +12 V Slide in: off: 0 V, on: +3.3 V Gate in: off: 0 V, on: +3.3 V CV in: +1 V to +5 V Sync in: more than 2.5 V |
Outputs | Accent out: off: 0 V, on: +6 V Gate out: off: 0 V, on: +12 V CV out: +1 V to +5 V (1 volt/oct) Filter out: -400 mV to +400 mV |
