The ZMX8210 can send audio media and public address announcements to three destinations from one centralized location. Ideal for houses of worship, office environments, clubs, restaurants, bars, or even the home, it’s easy enough for anyone to operate while packed with enough features to suit your unique environment. Featuring 8 channels of flexibility, the ZMX8210 can accommodate up to 6 Mic or line inputs with a -20 dB Pad and phantom plus 2 high headroom stereo/mono inputs for maximum flexibility and low nose operation. Channel one features a variable threshold (or ducking) control for clearly audible verbal announcements without awkwardly muting the background audio. The global-band EQ and low-cut ensure professional results and natural sounding fidelity from both sound sources. Rout your combined or solo signals (Left, Right, and Aux) right where you need them.
| Product Name | Behringer ZMX8210 V2 Rackmount Zone Mixer |
|---|---|
| Brand | Behringer |
| MPN | ZMX8210V2 |
| UPC | 653341312532 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Behringer ZMX8210 V2 Rackmount Zone Mixer
- 8-channel 3-bus rack-mountable zone mixer
- Mix music, microphones, or larger mixer outputs to the desired output in a specific area
- 6 Mic/Line inputs and bus-assign switches
- Individual Gain control, -20dB pad, +48V phantom power
- 4-band EQ and global highpass filter
- 2 selectable stereo inputs with Mono/Stereo switches and RCA connections
- 3 assignable outputs (Left, Right, and Aux) W/5-segment LED meters
- Variable Threshold on channel 1 for priority announcements
- Mic Preamps (6) Euroblock (mic/line) (2) Dual RCA Stereo
- Outputs (2) Euroblock
- Outputs (1) Euroblock remote master level
- Aux (1) Euroblock
- 1U space rack-mountable
Inputs 1 – 6 |
|
|---|---|
| Type | Euroblock connector, balanced |
| Impedance | 5 kΩ balanced, 2.5 kΩ unbalanced |
| Maximum input level | +12 dBu (with Pad) |
| Maximum gain | 40 dB |
| Pad | -20 dB |
| Crosstalk | -63 dB @ 1 kHz |
| Common-mode rejection ratio (CMRR) | > 70 dB @ 1 kHz, 22 Hz – 22 kHz |
| Equivalent input noise (EIN) | -116 dBu, A-weighted; terminated with 150 Ω |
Inputs 7 – 8 |
|
| Type | RCA connector, unbalanced |
| Impedance | 20 kΩ, unbalanced |
| Maximum input level | +10 dBu |
| Maximum gain | 13 dB |
Out L / Out R / Aux |
|
| Type | Euroblock connector, balanced |
| Impedance | 120 Ω balanced, 60 Ω unbalanced |
| Max. gain | 18 dB |
| Max. gain (input / output) | 58 dB (without Pad) |
| Maximum output level | +21 dBu |
| Crosstalk (output / output) | -63 dB @ 1 kHz |
| Noise (All level controls down) | -105 dBu, A-weighted |
| Signal-to-noise ratio | 87 dB @ 0 dB, A-weighted |
Bus Links |
|
| Type | Euroblock connector, unbalanced |
| Impedance | 2.7 kΩ |
| Maximum output level | +14 dBu |
Remote |
|
| Type | Euroblock connector |
| Volume control | 30 dB attenuation with 10 kΩ potentiometer (not included) 60 dB attenuation with 100 kΩ potentiometer (not included) |
| Channel select 7 / 8 | Push-button switch required (not included) |
Equalizer Section |
|
| Mic low cut | 100 Hz, 18 dB/oct. high-pass filter, Butterworth |
| Low | ±15 dB @ 70 Hz, shelving |
| Low mid | ±15 dB @ 300 Hz |
| High mid | ±15 dB @ 3 kHz |
| High | ±15 dB @ 10 kHz, shelving |
System Specifications |
|
| Frequency response | 20 Hz to 22 kHz, ±0.5 dB |
| Distortion (THD+N) | < 0.05 % |
Power supply, Voltage, Current Consumption |
|
| Switch mode power supply | Autorange, 100-240 V~ 50/60 Hz |
| Power consumption | 15 W |
| Main connection | Standard IEC receptacle |
Dimensions / Weight |
|
| Dimensions (H x W x D) | 44 x 483 x 153 mm (1.7 x 19.0 x 6.0") |
| Weight | 1.7 kg (3.7 lbs) |
