Boss VB-2W Waza Craft Vibrato Pedal

Boss VB-2W Waza Craft Vibrato Pedal

$208.00
$208.00
Sale Sold out

+ Free Shipping

Blink Image Blink Image

Out of Stock

View full details
  • Details
  • Features
  • Tech Specs
  • Reviews

Boss VB-2W Vibrato

Ahead of its time when it debuted in 1982, the VB-2 Vibrato has been rediscovered by modern players looking to create unique guitar textures with stompbox effects. Thanks to its expressive, one-of-a-kind sound, this rare pedal has gone on to become one of the most valuable BOSS effects in the vintage market. Now, the progressive spirit of the VB-2 has been reborn as the Waza Craft VB-2W. Using all-analog circuitry, the VB-2W authentically reproduces the true pitch-shifted vibrato of the original pedal, and also adds an innovative new vibrato mode and real-time control function for enhanced expression.

More Information
Product Name Boss VB-2W Waza Craft Vibrato Pedal
Brand Boss
Condition New
MPN VB-2W
UPC 761294508657
Shipping Option Free Shipping to the Continental U.S.
  • Premium edition Waza Craft pedal delivers the ultimate BOSS tone experience
  • Custom mode features a totally new vibrato sound with unique filter wave
  • Standard mode provides a true reproduction of the vintage VB-2 Vibrato sound
  • All-analog circuit with BBD (bucket brigade) vibrato line
  • Control the effect depth in real time with an optional expression pedal
  • Rise Time knob to control the initial onset of the vibrato effect
  • Unlatch mode activates the effect only while pressing the pedal, ideal for adding vibrato to specific notes and chords
  • Bypass mode takes the BBD out of the signal path to eliminate latency when the effect is off
  • BOSS five-year warranty
Modes
3 modes
LATCH
UNLATCH
BYPASS
Nominal Input Level
-20 dBu
Input Impedance
1 M ohm
Nominal Output Level
-20 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Bypass
Buffered bypass
Controls
Pedal switch
Standard/Custom switch
RATE knob
DEPTH knob
RISE TIME knob
MODE knob
Indicator
CHECK indicator (Serves also as battery check indicator)
Connectors
INPUT jack
OUTPUT jack
DEPTH jack
DC IN jack
Power Supply
Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately)
Current Draw
35 mA
Expected battery life under continuous use (These figures will vary depending on the actual conditions of use.)
Alkaline: Approx. 22 hours
Carbon: Approx. 4 hours
Accessories
Owner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61)
Options (sold separately)
AC adaptor: PSA series
Expression Pedal: FV-500H, FV-500L, Roland EV-5
Size and Weight
Width
73 mm
2-7/8 inches
Depth
129 mm
5-1/8 inches
Height
59 mm
2-3/8 inches
Weight (including battery)
450 g
1 lb
* 0 dBu = 0.775 Vrms

Boss VB-2W Waza Craft Vibrato Pedal
Details

Boss VB-2W Vibrato

Ahead of its time when it debuted in 1982, the VB-2 Vibrato has been rediscovered by modern players looking to create unique guitar textures with stompbox effects. Thanks to its expressive, one-of-a-kind sound, this rare pedal has gone on to become one of the most valuable BOSS effects in the vintage market. Now, the progressive spirit of the VB-2 has been reborn as the Waza Craft VB-2W. Using all-analog circuitry, the VB-2W authentically reproduces the true pitch-shifted vibrato of the original pedal, and also adds an innovative new vibrato mode and real-time control function for enhanced expression.

More Information
Product Name Boss VB-2W Waza Craft Vibrato Pedal
Brand Boss
Condition New
MPN VB-2W
UPC 761294508657
Shipping Option Free Shipping to the Continental U.S.
Features
  • Premium edition Waza Craft pedal delivers the ultimate BOSS tone experience
  • Custom mode features a totally new vibrato sound with unique filter wave
  • Standard mode provides a true reproduction of the vintage VB-2 Vibrato sound
  • All-analog circuit with BBD (bucket brigade) vibrato line
  • Control the effect depth in real time with an optional expression pedal
  • Rise Time knob to control the initial onset of the vibrato effect
  • Unlatch mode activates the effect only while pressing the pedal, ideal for adding vibrato to specific notes and chords
  • Bypass mode takes the BBD out of the signal path to eliminate latency when the effect is off
  • BOSS five-year warranty
Tech Specs
Modes
3 modes
LATCH
UNLATCH
BYPASS
Nominal Input Level
-20 dBu
Input Impedance
1 M ohm
Nominal Output Level
-20 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Bypass
Buffered bypass
Controls
Pedal switch
Standard/Custom switch
RATE knob
DEPTH knob
RISE TIME knob
MODE knob
Indicator
CHECK indicator (Serves also as battery check indicator)
Connectors
INPUT jack
OUTPUT jack
DEPTH jack
DC IN jack
Power Supply
Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately)
Current Draw
35 mA
Expected battery life under continuous use (These figures will vary depending on the actual conditions of use.)
Alkaline: Approx. 22 hours
Carbon: Approx. 4 hours
Accessories
Owner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61)
Options (sold separately)
AC adaptor: PSA series
Expression Pedal: FV-500H, FV-500L, Roland EV-5
Size and Weight
Width
73 mm
2-7/8 inches
Depth
129 mm
5-1/8 inches
Height
59 mm
2-3/8 inches
Weight (including battery)
450 g
1 lb
* 0 dBu = 0.775 Vrms
