Featuring a sculpted shredder's cut heel and scalloped lower back bout for comfortable and unencumbered upper fret access, the Dinky® alder body is paired with a graphite-reinforced bolt-on caramelized maple neck for rock-solid stability. The baked neck has a silky-smooth hand-rubbed satin urethane finish on the back for sublime playability, Luminlay® side dots to guide your way along the fretboard on dark stages and a heel-mount truss rod adjustment wheel for quick and painless neck relief tweaks. Designed for high-speed playing, its 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 22 jumbo frets, pearloid dot inlays and Graph Tech® TUSQ® XL nut.
Routed for an SSS pickup configuration, this axe combines a Seymour Duncan® Custom Hot Rails® Strat® SHR-1B humbucking bridge pickup, Seymour Duncan Custom Flat Strat SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup for plenty of glassy, vintage-style timbre with classic Strat chime.
The Pro-Mod DK22 SSS 2PT CM hosts other premium modern features including a five-way blade pickup switch, Stratocaster®-style skirt knobs for the volume (500K EVH® Bourns® low friction potentiometer) and no-load tone controls, Gotoh® Custom 510 tremolo bridge, die-cast tuners and more.
Designed with head-turning style, this model comes in Electric Blue with matte parchment pickup bobbins and parchment knobs.
| Product Name | Charvel Pro-Mod DK22 SSS 2PT CM Electric Guitar - Electric Blue |
|---|---|
| Brand | Charvel |
| Condition | Pre-Owned |
| MPN | 2969026527 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Charvel Pro-Mod DK22 SSS 2PT CM Electric Guitar - Electric Blue
- Gig Bag
- 25.5" scale length
- Alder Dinky® body with scalloped lower back bout
- Sculpted shredder's cut heel
- Bolt-on caramelized maple neck with graphite reinforcement and hand-rubbed satin urethane on the back
- 12"-16" compound radius caramelized fingerboard with rolled edges, 22 jumbo frets and 4mm pearloid dots
- Luminlay® side dots
- Heel-mount truss rod adjustment wheel
- Routed for an SSS pickup configuration with a direct mount Seymour Duncan Custom Hot Rails® Strat SHR-1B humbucking bridge, Seymour Duncan Custom Flat Strat SSL-6 Single-Coil middle and Seymour Duncan Custom Flat Strat SSL-6 RWRP Single-Coil neck pickups
- Five-way blade switch, volume control (500K EVH® Bourns® low friction potentiometer) and no-load tone control
- Stratocaster®-style skirt knobs
- Gotoh® Custom 510 tremolo bridge
- Graph Tech® TUSQ® XL nut
- Charvel-branded sealed die-cast locking tuners and standard strap buttons
- Electric Blue with chrome hardware; features parchment controls and matte parchment pickup bobbins
| Neck | |
|---|---|
| Headstock | Licensed Fender® Stratocaster® |
| Neck Material | Caramelized Maple |
| Neck Finish | Hand-Rubbed Satin Urethane |
| Neck Shape | Speed Neck with Rolled Fingerboard Edges |
| Neck Construction | Bolt-On with Graphite Reinforcement |
| Fingerboard Radius | 12"-16" Compound Radius (304.8 mm to 406.4 mm) |
| Fingerboard Material | Caramelized Maple |
| Position Inlays | 4mm Pearloid Dot |
| Number of Frets | 22 |
| Truss Rod | Dual-Action with Wheel |
| Truss Rod Nut | Heel-Mount Truss Rod Adjustment Wheel |
| String Nut | Graph Tech TUSQ XL |
| Nut Width | 1.6875" (42.86 mm) |
| Nut Material | Graph Tech TUSQ XL |
| Fret Size | Jumbo |
| Scale Length | 25.5" (647.7 mm) |
| Body | |
| Body | Alder |
| Body Finish | Satin |
| Body Shape | Dinky® |
| Body Style | Solid Body |
| Body Material | Alder |
| Hardware | |
| Bridge | Gotoh® Custom 510 Tremolo |
| Pickguard | None |
| Pickup Covers | Flat Parchment |
| Control Knobs | Stratocaster®-Style Skirt |
| Switch Tip | Parchment |
| Hardware Finish | Chrome |
| Tuning Machines | Charvel®-Branded Die-Cast Locking |
| String Trees | Fender® Standard String Guide |
| Strings | Nickel Plated Steel (.009-.042 Gauges) |
| Tremolo Arm | Gotoh® |
| Neck Plate | None - 4-Bolt Sculpted Heel |
| Strap Buttons | Standard |
| Electronics | |
| Bridge Pickup | Seymour Duncan® Custom Hot Rails® Strat® SHR-1B |
| Middle Pickup | Custom Seymour Duncan® Flat Strat® SSL-6 Single-Coil |
| Neck Pickup | Custom Seymour Duncan® Flat Strat® SSL-6 RWRP Single-Coil |
| Pickup Configuration | SSS |
| Controls | Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone |
| Switching | 5-Position Blade: Position 1: Full Bridge Pickup Position 2: Bridge Inner Coil and Middle Pickup Position 3: Bridge Outer Coil and Neck Pickup Position 4: Middle and Neck Pickup Position 5: Full Neck Pickup |
Charvel Pro-Mod DK22 SSS 2PT CM Electric Guitar - Electric Blue
Featuring a sculpted shredder's cut heel and scalloped lower back bout for comfortable and unencumbered upper fret access, the Dinky® alder body is paired with a graphite-reinforced bolt-on caramelized maple neck for rock-solid stability. The baked neck has a silky-smooth hand-rubbed satin urethane finish on the back for sublime playability, Luminlay® side dots to guide your way along the fretboard on dark stages and a heel-mount truss rod adjustment wheel for quick and painless neck relief tweaks. Designed for high-speed playing, its 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 22 jumbo frets, pearloid dot inlays and Graph Tech® TUSQ® XL nut.
Routed for an SSS pickup configuration, this axe combines a Seymour Duncan® Custom Hot Rails® Strat® SHR-1B humbucking bridge pickup, Seymour Duncan Custom Flat Strat SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup for plenty of glassy, vintage-style timbre with classic Strat chime.
The Pro-Mod DK22 SSS 2PT CM hosts other premium modern features including a five-way blade pickup switch, Stratocaster®-style skirt knobs for the volume (500K EVH® Bourns® low friction potentiometer) and no-load tone controls, Gotoh® Custom 510 tremolo bridge, die-cast tuners and more.
Designed with head-turning style, this model comes in Electric Blue with matte parchment pickup bobbins and parchment knobs.
| Product Name | Charvel Pro-Mod DK22 SSS 2PT CM Electric Guitar - Electric Blue |
|---|---|
| Brand | Charvel |
| Condition | Pre-Owned |
| MPN | 2969026527 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Charvel Pro-Mod DK22 SSS 2PT CM Electric Guitar - Electric Blue
- Gig Bag
- 25.5" scale length
- Alder Dinky® body with scalloped lower back bout
- Sculpted shredder's cut heel
- Bolt-on caramelized maple neck with graphite reinforcement and hand-rubbed satin urethane on the back
- 12"-16" compound radius caramelized fingerboard with rolled edges, 22 jumbo frets and 4mm pearloid dots
- Luminlay® side dots
- Heel-mount truss rod adjustment wheel
- Routed for an SSS pickup configuration with a direct mount Seymour Duncan Custom Hot Rails® Strat SHR-1B humbucking bridge, Seymour Duncan Custom Flat Strat SSL-6 Single-Coil middle and Seymour Duncan Custom Flat Strat SSL-6 RWRP Single-Coil neck pickups
- Five-way blade switch, volume control (500K EVH® Bourns® low friction potentiometer) and no-load tone control
- Stratocaster®-style skirt knobs
- Gotoh® Custom 510 tremolo bridge
- Graph Tech® TUSQ® XL nut
- Charvel-branded sealed die-cast locking tuners and standard strap buttons
- Electric Blue with chrome hardware; features parchment controls and matte parchment pickup bobbins
| Neck | |
|---|---|
| Headstock | Licensed Fender® Stratocaster® |
| Neck Material | Caramelized Maple |
| Neck Finish | Hand-Rubbed Satin Urethane |
| Neck Shape | Speed Neck with Rolled Fingerboard Edges |
| Neck Construction | Bolt-On with Graphite Reinforcement |
| Fingerboard Radius | 12"-16" Compound Radius (304.8 mm to 406.4 mm) |
| Fingerboard Material | Caramelized Maple |
| Position Inlays | 4mm Pearloid Dot |
| Number of Frets | 22 |
| Truss Rod | Dual-Action with Wheel |
| Truss Rod Nut | Heel-Mount Truss Rod Adjustment Wheel |
| String Nut | Graph Tech TUSQ XL |
| Nut Width | 1.6875" (42.86 mm) |
| Nut Material | Graph Tech TUSQ XL |
| Fret Size | Jumbo |
| Scale Length | 25.5" (647.7 mm) |
| Body | |
| Body | Alder |
| Body Finish | Satin |
| Body Shape | Dinky® |
| Body Style | Solid Body |
| Body Material | Alder |
| Hardware | |
| Bridge | Gotoh® Custom 510 Tremolo |
| Pickguard | None |
| Pickup Covers | Flat Parchment |
| Control Knobs | Stratocaster®-Style Skirt |
| Switch Tip | Parchment |
| Hardware Finish | Chrome |
| Tuning Machines | Charvel®-Branded Die-Cast Locking |
| String Trees | Fender® Standard String Guide |
| Strings | Nickel Plated Steel (.009-.042 Gauges) |
| Tremolo Arm | Gotoh® |
| Neck Plate | None - 4-Bolt Sculpted Heel |
| Strap Buttons | Standard |
| Electronics | |
| Bridge Pickup | Seymour Duncan® Custom Hot Rails® Strat® SHR-1B |
| Middle Pickup | Custom Seymour Duncan® Flat Strat® SSL-6 Single-Coil |
| Neck Pickup | Custom Seymour Duncan® Flat Strat® SSL-6 RWRP Single-Coil |
| Pickup Configuration | SSS |
| Controls | Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone |
| Switching | 5-Position Blade: Position 1: Full Bridge Pickup Position 2: Bridge Inner Coil and Middle Pickup Position 3: Bridge Outer Coil and Neck Pickup Position 4: Middle and Neck Pickup Position 5: Full Neck Pickup |
