The DirectOut Technologies EXBOX.UMA USB to ADAT MADI Interface is an all in one interface that is small, compact and perfect for every studio. This interface allows you to connect between ADAT, MADI and whatever software you desire without any other gear in the way that could potentially effect your signal. The EXBOX.UMA can act as an integrated mixer with eight stereo busses that offer the possibility to create monitor mixes free of latency from all input sources (128 physical inputs). Each mixing bus may be routed to a physical output and can be used as input source for another mixing bus. All physical inputs/outputs (ADAT, MADI, USB) and mixing busses are organized by an integrated 144 x 128 routing matrix. The USB line transmits up to 32 audio channels in both directions for simultaneous recording and playback from or with your recording system.
Product Name | DirectOut Technologies EXBOX.UMA USB to ADAT MADI Interface |
---|---|
Brand | DirectOut Technologies |
Condition | New |
MPN | EXBOX.UMA |
Shipping Option | Free Shipping to the Continental U.S. |
- It's a 32 channel USB audio device with four ADAT ports and an optical MADI port.
- Compact and Handy, this interface allows for a straight-forward connection between ADAT, MADI and your preferred recording software.
- Comes with ASIO and WDM drivers for Windows® and supports Core Audio under OS X®.
- Eight stereo busses offers the possibilty to create latency-free monitor mixes from all input sources (128 physical inputs).
- Software level meter bridge is available to monitor all inputs and mixing busses.
- MADI port (I/O): 1 x SC-Socket multi-mode
- ADAT ports (I/O): 8 x TOSLINK (S/MUX), Alesis specification
- MADI formats: 48k Frame, 96k Frame,
- 56/64 channel, S/MUX
- Sample rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
- USB Port (I/O): 32 audio channels (@1 FS) and remote control
- USB 2.0
- USB audio driver
- Support: Windows® XP, Vista, 7, 8 (32 bit / 64 bit) - ASIO & WDM
- OS X® (10.4.11 to 10.9.1) - Core Audio
- MIDI: virtual via USB
- Power supply: External, 2 x Hirose (9-24 V)
- Dimensions: Width 140 mm
- Height: 42 mm
- Depth: 146 mm
DirectOut Technologies EXBOX.UMA USB to ADAT MADI Interface
The DirectOut Technologies EXBOX.UMA USB to ADAT MADI Interface is an all in one interface that is small, compact and perfect for every studio. This interface allows you to connect between ADAT, MADI and whatever software you desire without any other gear in the way that could potentially effect your signal. The EXBOX.UMA can act as an integrated mixer with eight stereo busses that offer the possibility to create monitor mixes free of latency from all input sources (128 physical inputs). Each mixing bus may be routed to a physical output and can be used as input source for another mixing bus. All physical inputs/outputs (ADAT, MADI, USB) and mixing busses are organized by an integrated 144 x 128 routing matrix. The USB line transmits up to 32 audio channels in both directions for simultaneous recording and playback from or with your recording system.
Product Name | DirectOut Technologies EXBOX.UMA USB to ADAT MADI Interface |
---|---|
Brand | DirectOut Technologies |
Condition | New |
MPN | EXBOX.UMA |
Shipping Option | Free Shipping to the Continental U.S. |
- It's a 32 channel USB audio device with four ADAT ports and an optical MADI port.
- Compact and Handy, this interface allows for a straight-forward connection between ADAT, MADI and your preferred recording software.
- Comes with ASIO and WDM drivers for Windows® and supports Core Audio under OS X®.
- Eight stereo busses offers the possibilty to create latency-free monitor mixes from all input sources (128 physical inputs).
- Software level meter bridge is available to monitor all inputs and mixing busses.
- MADI port (I/O): 1 x SC-Socket multi-mode
- ADAT ports (I/O): 8 x TOSLINK (S/MUX), Alesis specification
- MADI formats: 48k Frame, 96k Frame,
- 56/64 channel, S/MUX
- Sample rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
- USB Port (I/O): 32 audio channels (@1 FS) and remote control
- USB 2.0
- USB audio driver
- Support: Windows® XP, Vista, 7, 8 (32 bit / 64 bit) - ASIO & WDM
- OS X® (10.4.11 to 10.9.1) - Core Audio
- MIDI: virtual via USB
- Power supply: External, 2 x Hirose (9-24 V)
- Dimensions: Width 140 mm
- Height: 42 mm
- Depth: 146 mm
