EarthQuaker Devices Aurelius Tri-Voice Chorus Pedal

EarthQuaker Devices Aurelius Tri-Voice Chorus Pedal

Limited quantities available!

View full details
  • Details
  • Tech Specs
  • Reviews

This compact, beautifully cased wonder is a three-voice chorus with six programmable presets and expression control. Inspired by the 1970s CE-1 Chorus Ensemble pedal, this digital unit has been tirelessly tweaked and fine-tuned to give you an all-encompassing chorus and vibrato experience like nothing else.

  • Three-voice chorus with the ability to save and recall six presets:

    • Chorus/Vibrato Mode: a familiar traditional chorus type effect that leans towards vibrato with a triangle LFO modulating a short delay line

    • Chorus/Flanger Mode: a blend of chorus and flanger. It has more warmth and slower rates than Vibrato Mode and uses a sine wave LFO to modulate the delay line.

    • Rotary Mode: a rotary chorus effect modeled after the sound of a Leslie speaker cabinet

  • User-assignable expression control

  • Two global operating modes which are indicated by the color of the Save/Recall switch: Green = Live Mode / Red = Preset Mode

  • Inspired by the 1970s CE-1 Chorus Ensemble pedal

  • True bypass

  • Silent relay-based switching with Flexi-Switch® Technology

More Information
Product Name EarthQuaker Devices Aurelius Tri-Voice Chorus Pedal
Shipping Option Free Shipping to the Continental U.S.
Dimensions:: 4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs
Current Draw 75 mA
Input Impedance: 500 kΩ
Output Impedance: 100 Ω
TRS expression pedal wiring: Tip: Wiper

Ring: +3.3V

Sleeve: Ground

Flexi-Switch® Technology:

This device features Flexi-Switch® Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching.

  • For standard latching operation, tap the footswitch once to activate the effect and then tap again to bypass.
  • For momentary operation, hold the footswitch down for as long as you’d like to use the effect. Once you release the switch the effect will be bypassed.

Since the switching is relay based, it requires power to pass signal.

Power: This device takes a standard 9 volt DC power supply with a 2.1mm negative center barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!

EarthQuaker Devices Aurelius Tri-Voice Chorus Pedal

Details

This compact, beautifully cased wonder is a three-voice chorus with six programmable presets and expression control. Inspired by the 1970s CE-1 Chorus Ensemble pedal, this digital unit has been tirelessly tweaked and fine-tuned to give you an all-encompassing chorus and vibrato experience like nothing else.

  • Three-voice chorus with the ability to save and recall six presets:

    • Chorus/Vibrato Mode: a familiar traditional chorus type effect that leans towards vibrato with a triangle LFO modulating a short delay line

    • Chorus/Flanger Mode: a blend of chorus and flanger. It has more warmth and slower rates than Vibrato Mode and uses a sine wave LFO to modulate the delay line.

    • Rotary Mode: a rotary chorus effect modeled after the sound of a Leslie speaker cabinet

  • User-assignable expression control

  • Two global operating modes which are indicated by the color of the Save/Recall switch: Green = Live Mode / Red = Preset Mode

  • Inspired by the 1970s CE-1 Chorus Ensemble pedal

  • True bypass

  • Silent relay-based switching with Flexi-Switch® Technology

More Information
Product Name EarthQuaker Devices Aurelius Tri-Voice Chorus Pedal
Shipping Option Free Shipping to the Continental U.S.
Tech Specs
Dimensions:: 4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs
Current Draw 75 mA
Input Impedance: 500 kΩ
Output Impedance: 100 Ω
TRS expression pedal wiring: Tip: Wiper

Ring: +3.3V

Sleeve: Ground

Flexi-Switch® Technology:

This device features Flexi-Switch® Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching.

  • For standard latching operation, tap the footswitch once to activate the effect and then tap again to bypass.
  • For momentary operation, hold the footswitch down for as long as you’d like to use the effect. Once you release the switch the effect will be bypassed.

Since the switching is relay based, it requires power to pass signal.

Power: This device takes a standard 9 volt DC power supply with a 2.1mm negative center barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!
