Elektron Machinedrum SPS-1 MKII Drum Machine

Elektron Machinedrum SPS-1 MKII Drum Machine

Out of Stock

View full details Liquid error (sections/main-product line 888): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features
  • Tech Specs

*Please note  -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.

The Elektron Machinedrum SPS-1 MKII is a powerful hardware drum machine, synthesizer and sequencer for producing stunning grooves and drum patterns, and is ideally suited for producers, musicians, DJs, remixers and beat-makers the world over. The integrated Machinedrum employs 4 synthesis methods that include TRX, P-I, EFM and E12 synthesis methods. Each synthesis method is devised to create various tonal, character and style variants such as vintage drum machines, organic percussion textures, acoustic drum feel, and wild effects manipulation.

Machinedrum's powerful sequencer features a total of 16 tracks and 32 songs with step sequencing and realtime sequencing modes. More than a source for drum programming, Machinedrum's powerful synth engine allows for intricate synth editing and preset synth sounds for adding baselines, top-lines and more.

Its sequencer may be used to sequence external MIDI gear, allowing it to function as your studio's master hardware sequencer. There are a variety of expressive effects assigned to the tracks and master sections, allowing for wild and expressive sound manipulation, as well as the ability to apply effects to external hardware.

More Information
Product Name Elektron Machinedrum SPS-1 MKII Drum Machine
Brand Elektron
Condition Pre-Owned
MPN MACHINEDRUM SPS-1 MKII
UPC 7350049243467
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • Elektron Machinedrum SPS-1 MKII Drum Machine
  • Power supply
  • 16 Track Sequencer
  • 4 MD Synthesis Methods
  • 28 Patterns & 64 Step Patterns
  • 32 Songs
  • 16 LFOs
  • 5 Individual Track Effects
  • Internal Flex RAM - 80MB Per Project
  • Resolution: 24-bit / 44.1kHz

Sequencer

Tracks 16 tracks
Patterns 128 x 64 step patterns
Songs 32 songs
Songs (+Drive) 4096 songs (+Drive models only)
Features Supports swing, slide and accent; 64 possible parameter locks on each pattern step; Full realtime control; Full MIDI support; 384 MIDI controllable (MIDI CC) parameters

Sound Generation

Synth Engines 4 MD Synths
Machines 46 individual audio generating machines
Track Effects 5 effects on each track
Master Effects 4 stereo master effects
Synthesis 16 part synthesis
Kits 64 kits
Kits (+Drive) 8192 kits (+Drive models only)

Effects

Track Effects List Amplitude modulation; 1-Band EQ; Resonant 24dB lp/bp/hp filter; Sample rate reduction; Distortion
Master Effects List Rhythm Echo delay; Gatebox reverb; Hi/Lo-shelf + parametric EQ; Dynamix processor

Audio Output

Main Output Level +15dBu
Assignable Outputs Level +10dBu
Output Impedance 100 Ω unbalanced
S/N Ratio 100dBFS (20Hz - 20kHz)

Audio Inputs

Input Level +7dBu maximum
Input Impedance 9 kΩ SNR inputs: 98dBFS (20Hz - 20kHz)

Connections

MIDI MIDI In/Out/Thru
Audio Outputs 6x 1/4" impedance balanced audio out jacks
Audio Inputs 2x 1/4" audio in jacks
Headphones 1x 1/4" stereo headphone jack

Hardware

Display 128x64 pixel backlit LCD
MIDI MIDI In/Out/Thru
System Advanced dual DSP system
Converters 44.1kHz, 24-bit D/A and A/D converters
OS Flash-EEPROM upgradable OS

Construction

Chassis Sturdy steel chassis

Power Supply

Power Consumption Unit power consumption: 10W typical, 18W maximum
Recommended Power Supply 6 VDC, 3A
PSU-2 Specs Input voltage range: 100-240V (43-60Hz); Input connector: IEC320-C8 (2 prong); In-rush current: 50A maximum; Output voltage: 5.7-6.3 VDC; Output current: 3.5A maximum; Output connector: 5.5 x 2.5mm DC plug, power at center.

Dimensions

Size 13.4 x 6.92 x 2.4" (340 x 176 x 63mm)

Weight

Weight 6.17lb (2.8kg)

Elektron Machinedrum SPS-1 MKII Drum Machine

Details

*Please note  -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.

The Elektron Machinedrum SPS-1 MKII is a powerful hardware drum machine, synthesizer and sequencer for producing stunning grooves and drum patterns, and is ideally suited for producers, musicians, DJs, remixers and beat-makers the world over. The integrated Machinedrum employs 4 synthesis methods that include TRX, P-I, EFM and E12 synthesis methods. Each synthesis method is devised to create various tonal, character and style variants such as vintage drum machines, organic percussion textures, acoustic drum feel, and wild effects manipulation.

Machinedrum's powerful sequencer features a total of 16 tracks and 32 songs with step sequencing and realtime sequencing modes. More than a source for drum programming, Machinedrum's powerful synth engine allows for intricate synth editing and preset synth sounds for adding baselines, top-lines and more.

Its sequencer may be used to sequence external MIDI gear, allowing it to function as your studio's master hardware sequencer. There are a variety of expressive effects assigned to the tracks and master sections, allowing for wild and expressive sound manipulation, as well as the ability to apply effects to external hardware.

More Information
Product Name Elektron Machinedrum SPS-1 MKII Drum Machine
Brand Elektron
Condition Pre-Owned
MPN MACHINEDRUM SPS-1 MKII
UPC 7350049243467

What's in the Box?

  • Elektron Machinedrum SPS-1 MKII Drum Machine
  • Power supply
Features
  • 16 Track Sequencer
  • 4 MD Synthesis Methods
  • 28 Patterns & 64 Step Patterns
  • 32 Songs
  • 16 LFOs
  • 5 Individual Track Effects
  • Internal Flex RAM - 80MB Per Project
  • Resolution: 24-bit / 44.1kHz
Tech Specs

Sequencer

Tracks 16 tracks
Patterns 128 x 64 step patterns
Songs 32 songs
Songs (+Drive) 4096 songs (+Drive models only)
Features Supports swing, slide and accent; 64 possible parameter locks on each pattern step; Full realtime control; Full MIDI support; 384 MIDI controllable (MIDI CC) parameters

Sound Generation

Synth Engines 4 MD Synths
Machines 46 individual audio generating machines
Track Effects 5 effects on each track
Master Effects 4 stereo master effects
Synthesis 16 part synthesis
Kits 64 kits
Kits (+Drive) 8192 kits (+Drive models only)

Effects

Track Effects List Amplitude modulation; 1-Band EQ; Resonant 24dB lp/bp/hp filter; Sample rate reduction; Distortion
Master Effects List Rhythm Echo delay; Gatebox reverb; Hi/Lo-shelf + parametric EQ; Dynamix processor

Audio Output

Main Output Level +15dBu
Assignable Outputs Level +10dBu
Output Impedance 100 Ω unbalanced
S/N Ratio 100dBFS (20Hz - 20kHz)

Audio Inputs

Input Level +7dBu maximum
Input Impedance 9 kΩ SNR inputs: 98dBFS (20Hz - 20kHz)

Connections

MIDI MIDI In/Out/Thru
Audio Outputs 6x 1/4" impedance balanced audio out jacks
Audio Inputs 2x 1/4" audio in jacks
Headphones 1x 1/4" stereo headphone jack

Hardware

Display 128x64 pixel backlit LCD
MIDI MIDI In/Out/Thru
System Advanced dual DSP system
Converters 44.1kHz, 24-bit D/A and A/D converters
OS Flash-EEPROM upgradable OS

Construction

Chassis Sturdy steel chassis

Power Supply

Power Consumption Unit power consumption: 10W typical, 18W maximum
Recommended Power Supply 6 VDC, 3A
PSU-2 Specs Input voltage range: 100-240V (43-60Hz); Input connector: IEC320-C8 (2 prong); In-rush current: 50A maximum; Output voltage: 5.7-6.3 VDC; Output current: 3.5A maximum; Output connector: 5.5 x 2.5mm DC plug, power at center.

Dimensions

Size 13.4 x 6.92 x 2.4" (340 x 176 x 63mm)

Weight

Weight 6.17lb (2.8kg)
