The EVH 5150lll 100S Half Stack Limited Edition 100 watt Head is an exact replication of Eddie's head while on his latest tour. Same custom modifications and identical in every way. The 100 watt head has a single input, 3 channels (clean, crunch and lead)and channel two has increased gain for better sustain and improved low frequency definition. Each Channel comes with their own controls (volume, gain, presence, low, mid, and high) and they all have a rear panel resonance control know that can dial and fine tune that low end response you are looking for. The head uses 8 JJ ECC83 Preamp tubes, 4 Wing C 6L6 power tubes, and switchable output impedance that can be set to 4, 8 or 16 ohms.
| Product Name | EVH 5150III® 100S 100-Watt Amp Head |
|---|---|
| Brand | EVH |
| Condition | New |
| MPN | 2250250000 |
| UPC | 885978474646 |
| Shipping Option | Free Shipping to the Continental U.S. |
- Comes in a special black "Stealth" aesthetic
- 100 watts
- Single input, 3 channels (clean, crunch and lead)
- Channel two has increased gain for better sustain and improved low frequency definition
- rear panel resonance control that fine tunes the low end response.
- 8 JJ ECC83 Preamp tubes and 4 Wing C 6L6 Power tubes
- 4-Button Footswitch Included
- Chicken-Head Style Pointer Knobs
General |
|
| Model Number | 2250250000 |
| Series | EVH® 5150III® Heads |
| Color | Black |
| Amplifier Type | Tube |
| Height | 11" (27.94 cm) |
| Width | 30" (76.2 cm) |
| Depth | 12" (30.5 cm) |
| Weight | 55 lbs. (24.95 kg) |
Electronics |
|
| Controls | Gain, Low, Mid, High, Volume, Channel Select, Presence and Resonance for Each Channel |
| Channels | Three - (Clean, Crunch, and Lead) |
| Voltage | 120V (Also Available in 100V, 110V, 220V, 230V, 240V) |
| Wattage | 100 Watts |
| Effects Loop | 1/4" (Send/Return) |
| Inputs | One - 1/4" |
| Line Out | One - 1/4" |
| Speaker Jack | Two - 1/4" Parallel |
| Rectifier | Solid State |
| Total Impedance | 4, 8, or 16 ohms |
| Power Cable | IEC |
Construction |
|
| Grill Cloth/Material | Perforated Steel Front and Rear Panel |
| Amplifier Covering | Black Textured Vinyl |
| Cabinet Material | White Birch |
Tubes |
|
| Preamp Tubes | 8 x JJ ECC83S (12AX7) |
| Power Tubes | 4 x Shuguang 6L6 Matched |
Hardware |
|
| Control Knobs | Black Chicken-Head Style Pointer |
| Handle | Molded Plastic Strap with Nickel-Plated Caps (1 Top & 2 Sides) |
| Control Panel | Gain, Low, Mid, High, Volume, Channel Select, Presence and Resonance for Each Channel |
| Front Panel | Black |
| Rear Control Panel | Power, Standby, Bias Adjust, Resonance For All Three Channels, Load Impedance |
Accessories |
|
| Footswitch | 4-Button Footswitch Included |
| Footswitch Connection Type | 7-Pin DIN |
| Recommended Cover | Optional P/N 0073406000 |
| Included Accessories | 5-Foot Speaker Cable |
EVH 5150III® 100S 100-Watt Amp Head
The EVH 5150lll 100S Half Stack Limited Edition 100 watt Head is an exact replication of Eddie's head while on his latest tour. Same custom modifications and identical in every way. The 100 watt head has a single input, 3 channels (clean, crunch and lead)and channel two has increased gain for better sustain and improved low frequency definition. Each Channel comes with their own controls (volume, gain, presence, low, mid, and high) and they all have a rear panel resonance control know that can dial and fine tune that low end response you are looking for. The head uses 8 JJ ECC83 Preamp tubes, 4 Wing C 6L6 power tubes, and switchable output impedance that can be set to 4, 8 or 16 ohms.
| Product Name | EVH 5150III® 100S 100-Watt Amp Head |
|---|---|
| Brand | EVH |
| Condition | New |
| MPN | 2250250000 |
| UPC | 885978474646 |
| Shipping Option | Free Shipping to the Continental U.S. |
- Comes in a special black "Stealth" aesthetic
- 100 watts
- Single input, 3 channels (clean, crunch and lead)
- Channel two has increased gain for better sustain and improved low frequency definition
- rear panel resonance control that fine tunes the low end response.
- 8 JJ ECC83 Preamp tubes and 4 Wing C 6L6 Power tubes
- 4-Button Footswitch Included
- Chicken-Head Style Pointer Knobs
General |
|
| Model Number | 2250250000 |
| Series | EVH® 5150III® Heads |
| Color | Black |
| Amplifier Type | Tube |
| Height | 11" (27.94 cm) |
| Width | 30" (76.2 cm) |
| Depth | 12" (30.5 cm) |
| Weight | 55 lbs. (24.95 kg) |
Electronics |
|
| Controls | Gain, Low, Mid, High, Volume, Channel Select, Presence and Resonance for Each Channel |
| Channels | Three - (Clean, Crunch, and Lead) |
| Voltage | 120V (Also Available in 100V, 110V, 220V, 230V, 240V) |
| Wattage | 100 Watts |
| Effects Loop | 1/4" (Send/Return) |
| Inputs | One - 1/4" |
| Line Out | One - 1/4" |
| Speaker Jack | Two - 1/4" Parallel |
| Rectifier | Solid State |
| Total Impedance | 4, 8, or 16 ohms |
| Power Cable | IEC |
Construction |
|
| Grill Cloth/Material | Perforated Steel Front and Rear Panel |
| Amplifier Covering | Black Textured Vinyl |
| Cabinet Material | White Birch |
Tubes |
|
| Preamp Tubes | 8 x JJ ECC83S (12AX7) |
| Power Tubes | 4 x Shuguang 6L6 Matched |
Hardware |
|
| Control Knobs | Black Chicken-Head Style Pointer |
| Handle | Molded Plastic Strap with Nickel-Plated Caps (1 Top & 2 Sides) |
| Control Panel | Gain, Low, Mid, High, Volume, Channel Select, Presence and Resonance for Each Channel |
| Front Panel | Black |
| Rear Control Panel | Power, Standby, Bias Adjust, Resonance For All Three Channels, Load Impedance |
Accessories |
|
| Footswitch | 4-Button Footswitch Included |
| Footswitch Connection Type | 7-Pin DIN |
| Recommended Cover | Optional P/N 0073406000 |
| Included Accessories | 5-Foot Speaker Cable |
