EVH Wolfgang Special Electric Guitar - Ebony Fingerboard, Caution Yellow

EVH Wolfgang Special Electric Guitar - Ebony Fingerboard, Caution Yellow

Limited quantities available!

View full details Liquid error (sections/main-product line 888): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features
  • Tech Specs

The Wolfgang Special features a basswood body with an arched top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius ebony fingerboard, (baked maple on Gloss Black), has 22 jumbo frets and pearloid dot inlays (black on Gloss Black). Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck. A pair of flagship custom-designed EVH® Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns® low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting. EVH Wolfgang / Striped Series Gig Bag Included!

More Information
Product Name EVH Wolfgang Special Electric Guitar - Ebony Fingerboard, Caution Yellow
Brand EVH
Condition New
MPN 5107701304
UPC 197955146508
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • EVH Wolfgang Special Electric Guitar, Baked Maple Neck, Ebony Fingerboard, Caution Yellow
  • Striped Series Gig Bag
  • 25.5" scale length
  • Basswood body with arched top
  • Graphite-reinforced bolt-on quartersawn baked maple neck
  • Neck is carved and rolled to Eddie Van Halen's specifications with a hand-rubbed satin urethane finish on the back
  • 12"-16" compound radius ebony fingerboard, baked maple on Gloss Black),with 22 jumbo frets and pearloid dot inlays (black on Gloss Black)
  • Convenient heel-mount truss rod adjustment spoke wheel
  • Direct mount EVH® Wolfgang® Alnico 2 bridge and neck humbucking pickups
  • EVH-branded Floyd Rose® locking trem and R2 locking nut
  • EVH D-Tuna®
  • Three-way toggle switch, EVH volume control (500K EVH Bourns® Low Friction Pot) with treble bleed circuit and tone control (250K EVH Bourns® High Friction Pot)

Neck

Headstock EVH® Wolfgang®
Neck Material Quartersawn Baked Maple
Neck Finish Hand-Rubbed Satin Urethane
Neck Shape Wolfgang® Backshape
Neck Construction Bolt-On with Graphite Reinforcement
Neck Thickness .805" (20.45 mm) at 3rd & .890" (22.61 mm) at 12th Fret
Fingerboard Radius 12"-16" (304.8 mm – 406.4 mm)
Fingerboard Material Ebony
Position Inlays Pearloid Dot
Side Dots Pearloid
Number of Frets 22
Truss Rod EVH®-Branded with Wheel
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
String Nut Floyd Rose® R2 Locking
Nut Width 1.625" (41.3 mm)
Nut Material Floyd Rose® R2 Locking
Fret Size Jumbo
Scale Length 25.5" (648 mm)

Body

Body Basswood
Body Finish Gloss Urethane
Body Shape Wolfgang®
Body Binding 1-Ply Cream
Body Material Basswood

Hardware

Bridge EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
Tremolo Block Brass
Pickup Covers Black
Control Knobs Black Knurled with White Indicator
Switch Tip Black
Hardware Finish Black
Tuning Machines EVH®-Branded Gotoh®
String Trees Floyd Rose® Retainer Bar
Strings EVH® Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm Floyd Rose® 1000 Series Locking
Strap Buttons Oversized

Electronics

Bridge Pickup Direct Mount EVH® Wolfgang® Humbucking
Neck Pickup Direct Mount EVH® Wolfgang® Humbucking
Pickup Configuration HH
Controls Volume (500K EVH® Bourns® Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
Switching 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

EVH Wolfgang Special Electric Guitar - Ebony Fingerboard, Caution Yellow

Details

The Wolfgang Special features a basswood body with an arched top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius ebony fingerboard, (baked maple on Gloss Black), has 22 jumbo frets and pearloid dot inlays (black on Gloss Black). Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck. A pair of flagship custom-designed EVH® Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns® low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting. EVH Wolfgang / Striped Series Gig Bag Included!

More Information
Product Name EVH Wolfgang Special Electric Guitar - Ebony Fingerboard, Caution Yellow
Brand EVH
Condition New
MPN 5107701304
UPC 197955146508

What's in the Box?

  • EVH Wolfgang Special Electric Guitar, Baked Maple Neck, Ebony Fingerboard, Caution Yellow
  • Striped Series Gig Bag
Features
  • 25.5" scale length
  • Basswood body with arched top
  • Graphite-reinforced bolt-on quartersawn baked maple neck
  • Neck is carved and rolled to Eddie Van Halen's specifications with a hand-rubbed satin urethane finish on the back
  • 12"-16" compound radius ebony fingerboard, baked maple on Gloss Black),with 22 jumbo frets and pearloid dot inlays (black on Gloss Black)
  • Convenient heel-mount truss rod adjustment spoke wheel
  • Direct mount EVH® Wolfgang® Alnico 2 bridge and neck humbucking pickups
  • EVH-branded Floyd Rose® locking trem and R2 locking nut
  • EVH D-Tuna®
  • Three-way toggle switch, EVH volume control (500K EVH Bourns® Low Friction Pot) with treble bleed circuit and tone control (250K EVH Bourns® High Friction Pot)
Tech Specs

Neck

Headstock EVH® Wolfgang®
Neck Material Quartersawn Baked Maple
Neck Finish Hand-Rubbed Satin Urethane
Neck Shape Wolfgang® Backshape
Neck Construction Bolt-On with Graphite Reinforcement
Neck Thickness .805" (20.45 mm) at 3rd & .890" (22.61 mm) at 12th Fret
Fingerboard Radius 12"-16" (304.8 mm – 406.4 mm)
Fingerboard Material Ebony
Position Inlays Pearloid Dot
Side Dots Pearloid
Number of Frets 22
Truss Rod EVH®-Branded with Wheel
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
String Nut Floyd Rose® R2 Locking
Nut Width 1.625" (41.3 mm)
Nut Material Floyd Rose® R2 Locking
Fret Size Jumbo
Scale Length 25.5" (648 mm)

Body

Body Basswood
Body Finish Gloss Urethane
Body Shape Wolfgang®
Body Binding 1-Ply Cream
Body Material Basswood

Hardware

Bridge EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
Tremolo Block Brass
Pickup Covers Black
Control Knobs Black Knurled with White Indicator
Switch Tip Black
Hardware Finish Black
Tuning Machines EVH®-Branded Gotoh®
String Trees Floyd Rose® Retainer Bar
Strings EVH® Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm Floyd Rose® 1000 Series Locking
Strap Buttons Oversized

Electronics

Bridge Pickup Direct Mount EVH® Wolfgang® Humbucking
Neck Pickup Direct Mount EVH® Wolfgang® Humbucking
Pickup Configuration HH
Controls Volume (500K EVH® Bourns® Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
Switching 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
