EVH Wolfgang Special QM Electric Guitar -Baked Maple Fingerboard, Tiger Eye Glow

EVH Wolfgang Special QM Electric Guitar -Baked Maple Fingerboard, Tiger Eye Glow

Limited quantities available!

View full details
  • Details
  • Features
  • Tech Specs
  • Reviews

Road-tested in arenas around the world, the Wolfgang® Special is a purebred music-making machine, designed with stunning style, giant sound and high-speed playability.

The Wolfgang Special QM features a basswood body with an arched quilt maple top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius baked maple fingerboard has 22 jumbo frets and black dot inlays. Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck.

A pair of flagship custom-designed EVH® Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns® low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting.

More Information
Product Name EVH Wolfgang Special QM Electric Guitar -Baked Maple Fingerboard, Tiger Eye Glow
Brand EVH
MPN 5107701580
UPC 885978085347

What's in the Box?

  • EVH Wolfgang Special QM Electric Guitar - Baked Maple Fingerboard, Tiger Eye Glow
  • 25.5" scale length
  • Basswood body with arched quilt maple top
  • Graphite-reinforced bolt-on quartersawn baked maple neck
  • Neck is carved and rolled to Eddie Van Halen's specifications with a hand-rubbed satin urethane finish on the back
  • 12"-16" compound radius baked maple fingerboard with 22 jumbo frets and black dot inlays
  • Convenient heel-mount truss rod adjustment spoke wheel
  • Direct mount EVH® Wolfgang® Alnico 2 bridge and neck humbucking pickups
  • EVH-branded Floyd Rose® locking trem and R2 locking nut
  • EVH D-Tuna®
  • Three-way toggle switch, EVH volume control (500K EVH Bourns® Low Friction Pot) with treble bleed circuit and tone control (250K EVH Bourns® High Friction Pot)

EVH Wolfgang Special QM Electric Guitar -Baked Maple Fingerboard, Tiger Eye Glow

Details

Road-tested in arenas around the world, the Wolfgang® Special is a purebred music-making machine, designed with stunning style, giant sound and high-speed playability.

The Wolfgang Special QM features a basswood body with an arched quilt maple top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius baked maple fingerboard has 22 jumbo frets and black dot inlays. Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck.

A pair of flagship custom-designed EVH® Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns® low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting.

General

Series Wolfgang® Special
Orientation Right-Hand
Color Tiger Eye Glow
Country Of Origin MX

Neck

Headstock EVH® Wolfgang®
Neck Material Quartersawn Baked Maple
Neck Finish Hand-Rubbed Satin Urethane
Neck Shape Wolfgang® Backshape
Neck Construction Bolt-On with Graphite Reinforcement
Neck Thickness .805" at 3rd & .890" at 12th Fret
Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material Baked Maple
Position Inlays Black Dot
Side Dots Black
Number of Frets 22
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
String Nut Floyd Rose® R2 Locking
Nut Width 1.625" (41.3 mm)
Nut Material Floyd Rose® R2 Locking

Body

Body Basswood
Body Finish Gloss Polyester
Body Shape Wolfgang®
Body Binding 1-Ply Cream
Body Material Basswood

Hardware

Bridge EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
Tremolo Block Brass
Control Knobs Black Knurled with White Indicator
Switch Tip Black
Hardware Finish Chrome
Tuning Machines EVH®-Branded Gotoh®
String Trees Floyd Rose® Retainer Bar
Strings EVH® Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm Floyd Rose® 1000 Series Locking
Strap Buttons Oversized

Electronics

Bridge Pickup Direct Mount EVH® Wolfgang® Humbucking
Neck Pickup Direct Mount EVH® Wolfgang® Humbucking
Pickup Configuration HH
Controls Volume (500K EVH® Bourns® Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
Switching 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

Measurements

Dimensions 4.60x15.30x42.00 IN
Shipping Weight 10.25 LB
Fret Size Jumbo
Scale Length 25.5" (64.77 cm)
Shipping Length 42.00 IN
Shipping Height 4.60 IN
More Information
Product Name EVH Wolfgang Special QM Electric Guitar -Baked Maple Fingerboard, Tiger Eye Glow
Brand EVH
MPN 5107701580
UPC 885978085347

What's in the Box?

EVH Wolfgang Special QM Electric Guitar - Baked Maple Fingerboard, Tiger Eye Glow
Features
  • 25.5" scale length
  • Basswood body with arched quilt maple top
  • Graphite-reinforced bolt-on quartersawn baked maple neck
  • Neck is carved and rolled to Eddie Van Halen's specifications with a hand-rubbed satin urethane finish on the back
  • 12"-16" compound radius baked maple fingerboard with 22 jumbo frets and black dot inlays
  • Convenient heel-mount truss rod adjustment spoke wheel
  • Direct mount EVH® Wolfgang® Alnico 2 bridge and neck humbucking pickups
  • EVH-branded Floyd Rose® locking trem and R2 locking nut
  • EVH D-Tuna®
  • Three-way toggle switch, EVH volume control (500K EVH Bourns® Low Friction Pot) with treble bleed circuit and tone control (250K EVH Bourns® High Friction Pot)
Tech Specs
Reviews

General

Series Wolfgang® Special
Orientation Right-Hand
Color Tiger Eye Glow
Country Of Origin MX

Neck

Headstock EVH® Wolfgang®
Neck Material Quartersawn Baked Maple
Neck Finish Hand-Rubbed Satin Urethane
Neck Shape Wolfgang® Backshape
Neck Construction Bolt-On with Graphite Reinforcement
Neck Thickness .805" at 3rd & .890" at 12th Fret
Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material Baked Maple
Position Inlays Black Dot
Side Dots Black
Number of Frets 22
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
String Nut Floyd Rose® R2 Locking
Nut Width 1.625" (41.3 mm)
Nut Material Floyd Rose® R2 Locking

Body

Body Basswood
Body Finish Gloss Polyester
Body Shape Wolfgang®
Body Binding 1-Ply Cream
Body Material Basswood

Hardware

Bridge EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
Tremolo Block Brass
Control Knobs Black Knurled with White Indicator
Switch Tip Black
Hardware Finish Chrome
Tuning Machines EVH®-Branded Gotoh®
String Trees Floyd Rose® Retainer Bar
Strings EVH® Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm Floyd Rose® 1000 Series Locking
Strap Buttons Oversized

Electronics

Bridge Pickup Direct Mount EVH® Wolfgang® Humbucking
Neck Pickup Direct Mount EVH® Wolfgang® Humbucking
Pickup Configuration HH
Controls Volume (500K EVH® Bourns® Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
Switching 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

Measurements

Dimensions 4.60x15.30x42.00 IN
Shipping Weight 10.25 LB
Fret Size Jumbo
Scale Length 25.5" (64.77 cm)
Shipping Length 42.00 IN
Shipping Height 4.60 IN
