*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
Pulsar MkII
Pulsar is our bread and butter studio monitor; the most versatile performer in our range. Like all our speakers, its singular purpose is to provide you with the most accurate, effortless, reliable insight possible.
Custom SEAS Extreme Series Subwoofer
Low distortion, long stroke design and rigid aluminum diaphragms provide immense bass precision and reach.
Coaxial Midrange/Tweeter
Bleeding edge Composite Sound Metamodal TeXtreme diaphragms: ultralight, ultra-stiff carbon fabrics with optimized fiber geometries to actively control and suppress resonances.
Mathematically optimal midrange waveguide shape, underhung surround, and optimized point source acoustic center alignment provides superb off-axis response.
State of the art, super low distortion neodymium motor design.
Electronics
Flagship AKM Velvet Sound AK4493/AK5572 based conversion leaves no sonic footprint.
Hypex Ncore amplifiers provide gobs of squeaky clean, efficient power.
5th gen SHARC+ DSP hardware can crunch many, many numbers at once.
| Product Name | Ex Machina Soundworks Pulsar MKII 3-way 8-inch Active Studio Monitors - Pair |
|---|---|
| Brand | Ex Machina Soundworks |
| Condition | Pre-Owned |
| MPN | PULSARMKII |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Ex Machina Soundworks Pulsar MKII 3-way 8-inch Active Studio Monitors - Pair
- Frequency Response (30cm cal position)
- Impulse Response
- Phase Response
- THD Ratio (94db at cal position)
- THD Ratio Power Average
- Horizontal Polar
- Vertical Polar
- Coaxial Angle vs Frequency
Performance |
|
|---|---|
| Linear Frequency Response | ±1 dB, 35 Hz – 30 kHz (measured at 30 cm cal position) |
| Low Frequency Cutoff | -6 dB at 28 Hz |
| Linear Phase Response | ±15°, 20 Hz – 30 kHz |
| Maximum Continuous SPL @ 1 m | 110 dB, 104 dB @ 50 Hz |
| THD+N | <0.5% (94 dB @ cal position), Power Average 100 Hz – 30 kHz |
| Coverage Angle | 90° Conical |
Driver Complement |
|
| Midrange / Tweeter | 176 mm (7") Midrange, 25 mm (1") Tweeter, Custom SEAS / Ex Machina / Composite Sound Metamodal TX™ Mid/High Coaxial |
| Subwoofer | 221 mm (9") Custom Aluminum SEAS Extreme Series Architecture Subwoofer |
Crossovers |
|
| Sub / Mid Crossover | 200 Hz, Digital 8th Order, Phase Corrected |
| Mid / Tweeter Crossover | 2 kHz, Digital 8th Order, Phase Corrected |
Amplifier Complement |
|
| Subwoofer Amplifier | Hypex NC252MP – 250 W RMS |
| Midrange Amplifier | Hypex NC252MP – 100 W RMS, Voltage Limited |
| Tweeter Amplifier | Hypex NC100HF – 50 W RMS, Voltage Limited |
DSP / Conversion |
|
| A/D Chipsets | AKM AK5572EN |
| D/A Chipsets | AKM AK4493EQ |
| DSP | 5th Gen SHARC+ AD21565 |
Input |
|
| Input Sensitivity | 2 Vrms to Full Scale |
Physical |
|
| Dimensions | 483 mm H × 289 mm W × 345 mm D (19" × 11.3" × 13.6") |
| Weight | 23 kg (51 lbs) |
