EVH 5150III 50W EL34 1x12 Combo Amp - Black

EVH 5150III 50W EL34 1x12 Combo Amp - Black

Limited quantities available!

View full details
  • Details
  • Tech Specs
  • Reviews

The EVH® 5150III® 50W EL34 1x12 Combo delivers signature harmonic overtones with increased dynamic compression and saturation to evoke a more modern "British" sound, all with the sustain and versatility expected from an amp bearing Eddie Van Halen's name.

Designed with flexible and independent dual-concentric controls that allow for gain and volume level matching, this 50-watt tube combo amp boasts three channels for any playing style - sparkly cleans, tight crunch or soulful leads.

Delivering a full-spectrum of tone, channel one features pristine cleans and compressed tone, channel two kicks in with overdrive and heavy gain and channel three oozes with liquid distortion. Channels one and two each have dual concentric gain/volume controls, with shared EQ (low, mid, high). Channel three has its own gain, volume and EQ (low, mid, high) controls. All three channels also have global presence, resonance and reverb controls.

Loaded with a 12" custom special designed EVH Celestion® speaker to enhance sound and style, this combo amp also has seven JJ ECC83 (12AX7) preamp tubes, two JJ EL34 power tubes and front-panel adjustable power output from 50 watts down to one watt.

Other premium features include an ultra-high-gain preamp design custom-voiced for maximum output, single instrument input, rear-panel selectable output impedance (4, 8 or 16 ohms) with a pair of parallel speaker outputs, rear-panel MIDI input and preamp output, rear-panel effects loop and headphone jack (mutes power amp), and a four-button footswitch that controls reverb plus all three channels for easy onstage switching.

The black cabinet is constructed out of birch with special internal baffling for tight and increased bass response. Sporting a slick black and gold striped motif on the control panel, this combo is finished off with black vintage-style chicken knobs, red LED jewel indicator, molded black plastic top handle and pop-out casters. A high-quality fitted cover is available as an EVH accessory.

More Information
Product Name EVH 5150III 50W EL34 1x12 Combo Amp - Black
Brand EVH
MPN 2255010000
UPC 885978184439
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • EVH 5150III 50W EL34 1x12 Combo Amp - Black
  • Fitted Cover
  • 4-Button Footswitch

Electronics

Controls Ch. 1: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 2: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 3: Independent Gain & Volume w/Shared Low, Mid & High; Also Power Level; Reverb; Global Presence; Rear Panel Global Resonance
Control Panel Ch. 1: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 2: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 3: Independent Gain & Volume w/Shared Low, Mid & High; Also Power Level; Reverb; Global Presence; Rear Panel Global Resonance
Inputs One - 1/4", MIDI (rear)
Headphone Jack 1/4" Stereo
Line Out One - 1/4"
Channels Three - (Clean, Crunch and Lead)
Effects Reverb
Effects Loop 1/4" (Send/Return)
Connectivity MIDI
Connection Type 1/4"
Voltage 120V (Also Available in 100V, 110V, 220V, 230V, 240V)
Wattage 50 Watts

Hardware

Control Knobs Black Chicken-Head Style Pointer
Amplifier Covering Black Textured Vinyl
Cabinet Material 7-Ply 3/4" Birch Maple
Grille Cloth Woven Front Panel with Large EVH® Logo and Perforated Back Panel
Handle Spring-Loaded Side (2) and Molded Plastic Top (1)
Casters Included
Speaker Jack Two - 1/4" Parallel
Front Panel Gold Anodized

Speakers

Speakers One - 12" Celestion® EVH® G12H 30W Anniversary Series
Speaker Wattage 30 Watts
Total Impedance 4, 8, or 16 ohms

Tubes

Power Tubes 2 x JJ EL34 Apex Matched
Preamp Tubes 7 x JJ ECC83S (12AX7)
Rectifier Solid State

EVH 5150III 50W EL34 1x12 Combo Amp - Black

Details

The EVH® 5150III® 50W EL34 1x12 Combo delivers signature harmonic overtones with increased dynamic compression and saturation to evoke a more modern "British" sound, all with the sustain and versatility expected from an amp bearing Eddie Van Halen's name.

Designed with flexible and independent dual-concentric controls that allow for gain and volume level matching, this 50-watt tube combo amp boasts three channels for any playing style - sparkly cleans, tight crunch or soulful leads.

Delivering a full-spectrum of tone, channel one features pristine cleans and compressed tone, channel two kicks in with overdrive and heavy gain and channel three oozes with liquid distortion. Channels one and two each have dual concentric gain/volume controls, with shared EQ (low, mid, high). Channel three has its own gain, volume and EQ (low, mid, high) controls. All three channels also have global presence, resonance and reverb controls.

Loaded with a 12" custom special designed EVH Celestion® speaker to enhance sound and style, this combo amp also has seven JJ ECC83 (12AX7) preamp tubes, two JJ EL34 power tubes and front-panel adjustable power output from 50 watts down to one watt.

Other premium features include an ultra-high-gain preamp design custom-voiced for maximum output, single instrument input, rear-panel selectable output impedance (4, 8 or 16 ohms) with a pair of parallel speaker outputs, rear-panel MIDI input and preamp output, rear-panel effects loop and headphone jack (mutes power amp), and a four-button footswitch that controls reverb plus all three channels for easy onstage switching.

The black cabinet is constructed out of birch with special internal baffling for tight and increased bass response. Sporting a slick black and gold striped motif on the control panel, this combo is finished off with black vintage-style chicken knobs, red LED jewel indicator, molded black plastic top handle and pop-out casters. A high-quality fitted cover is available as an EVH accessory.

More Information
Product Name EVH 5150III 50W EL34 1x12 Combo Amp - Black
Brand EVH
MPN 2255010000
UPC 885978184439
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • EVH 5150III 50W EL34 1x12 Combo Amp - Black
  • Fitted Cover
  • 4-Button Footswitch
Tech Specs

Electronics

Controls Ch. 1: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 2: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 3: Independent Gain & Volume w/Shared Low, Mid & High; Also Power Level; Reverb; Global Presence; Rear Panel Global Resonance
Control Panel Ch. 1: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 2: Independent Gain & Volume w/Shared Low, Mid & High; Ch. 3: Independent Gain & Volume w/Shared Low, Mid & High; Also Power Level; Reverb; Global Presence; Rear Panel Global Resonance
Inputs One - 1/4", MIDI (rear)
Headphone Jack 1/4" Stereo
Line Out One - 1/4"
Channels Three - (Clean, Crunch and Lead)
Effects Reverb
Effects Loop 1/4" (Send/Return)
Connectivity MIDI
Connection Type 1/4"
Voltage 120V (Also Available in 100V, 110V, 220V, 230V, 240V)
Wattage 50 Watts

Hardware

Control Knobs Black Chicken-Head Style Pointer
Amplifier Covering Black Textured Vinyl
Cabinet Material 7-Ply 3/4" Birch Maple
Grille Cloth Woven Front Panel with Large EVH® Logo and Perforated Back Panel
Handle Spring-Loaded Side (2) and Molded Plastic Top (1)
Casters Included
Speaker Jack Two - 1/4" Parallel
Front Panel Gold Anodized

Speakers

Speakers One - 12" Celestion® EVH® G12H 30W Anniversary Series
Speaker Wattage 30 Watts
Total Impedance 4, 8, or 16 ohms

Tubes

Power Tubes 2 x JJ EL34 Apex Matched
Preamp Tubes 7 x JJ ECC83S (12AX7)
Rectifier Solid State
