Golden Age Project PRE573 Plus MKII 500-Series Mic Pre

Golden Age Project PRE573 Plus MKII 500-Series Mic Pre

$399.00
$399.00
Sale Sold out

+ Free Shipping

Blink Image Blink Image

On order with the manufacturer!
View full details
  • Details
  • Features
  • Reviews

The PRE-573 Plus has a dedicated insert connector at the back allowing it to interface with other GAP 500 modules. The insert can be activated by removing a jumper connector at the back of the module.

There is a second jumper at the back of the module that selects 600 ohm termination on the output. The standard mode is termination on, since it gives the flattest response when the PRE-573 Plus is used with modern line inputs that typically has an input impedance of 10 kohm or more. The user can chose to remove the jumper and deactivate the termination resistor, this will increase the level above 10 kHz and create a peak in the response for an even more pronounced  “Air” effect.

The output is transformer balanced and fully floating and can drive a 600 ohm load up to level of about 28 dBu.

More Information
Product Name Golden Age Project PRE573 Plus MKII 500-Series Mic Pre
Brand Golden Age Project
Condition New
MPN PRE573MK2PLUS
UPC 7123244654266
Shipping Option Free Shipping to the Continental U.S.
  • *UPGRADED Carnhill Transformers!
  • The PRE-573 is a one width module that has the sound and the features that made the PRE-73 so successful and a few additional ones.
  • Circuit uses the preamp and output section from the classic 1073-module, adapted to work in the api rack format.
  • Total gain range from -15 to +80 dB. The 10 – 70 dB range is handled by a turn switch  and there is a separate toggle switch to select an additional 5 or 10 dB gain.
  • Input can be configured to accept line level signals by another switch, the gain is then lowered by about 25 dB and the input impedance increased to about 15k ohm.
  • input impedance of the mic input mode can be switched between 1200 and 300 ohm.
  • Phantom power and phase reverse is also selectable by front panel switches.
  • New Feature: active DI-input with a high input impedance of about 1.5 M ohm
  • The output signal from the active DI circuit passes through the input transformer for some extra character.
  • The DI-input is extremely flexible since it can be changed to a purely passive one via a front panel switch- The DI input is then exactly the same as in the PRE-73 Mk2 where the signal is feed directly into the second gain stage, bypassing the transformer and with an input impedance of about 100 kohm.
  • New feature: switchable AIR mode that  adds a small boost above 10 kHz that peaks at 2 dB at about 35 kHz.
  • Simple but effective signal and overload indicator is offered by a single LED that starts glowing red at about +4 dBu and then increases its intensity up to the maximum output level.

Golden Age Project PRE573 Plus MKII 500-Series Mic Pre
Details

The PRE-573 Plus has a dedicated insert connector at the back allowing it to interface with other GAP 500 modules. The insert can be activated by removing a jumper connector at the back of the module.

There is a second jumper at the back of the module that selects 600 ohm termination on the output. The standard mode is termination on, since it gives the flattest response when the PRE-573 Plus is used with modern line inputs that typically has an input impedance of 10 kohm or more. The user can chose to remove the jumper and deactivate the termination resistor, this will increase the level above 10 kHz and create a peak in the response for an even more pronounced  “Air” effect.

The output is transformer balanced and fully floating and can drive a 600 ohm load up to level of about 28 dBu.

More Information
Product Name Golden Age Project PRE573 Plus MKII 500-Series Mic Pre
Brand Golden Age Project
Condition New
MPN PRE573MK2PLUS
UPC 7123244654266
Shipping Option Free Shipping to the Continental U.S.
Features
  • *UPGRADED Carnhill Transformers!
  • The PRE-573 is a one width module that has the sound and the features that made the PRE-73 so successful and a few additional ones.
  • Circuit uses the preamp and output section from the classic 1073-module, adapted to work in the api rack format.
  • Total gain range from -15 to +80 dB. The 10 – 70 dB range is handled by a turn switch  and there is a separate toggle switch to select an additional 5 or 10 dB gain.
  • Input can be configured to accept line level signals by another switch, the gain is then lowered by about 25 dB and the input impedance increased to about 15k ohm.
  • input impedance of the mic input mode can be switched between 1200 and 300 ohm.
  • Phantom power and phase reverse is also selectable by front panel switches.
  • New Feature: active DI-input with a high input impedance of about 1.5 M ohm
  • The output signal from the active DI circuit passes through the input transformer for some extra character.
  • The DI-input is extremely flexible since it can be changed to a purely passive one via a front panel switch- The DI input is then exactly the same as in the PRE-73 Mk2 where the signal is feed directly into the second gain stage, bypassing the transformer and with an input impedance of about 100 kohm.
  • New feature: switchable AIR mode that  adds a small boost above 10 kHz that peaks at 2 dB at about 35 kHz.
  • Simple but effective signal and overload indicator is offered by a single LED that starts glowing red at about +4 dBu and then increases its intensity up to the maximum output level.
