The Ibanez PA230E is a distinctive and meticulously crafted acoustic-electric guitar, designed to provide a rich tonal experience with modern playability and aesthetic appeal. Here are the key features and details about this guitar:

Body and Construction

The PA230E boasts an asymmetrical jumbo body shape, designed to deliver a balanced and resonant sound. The body is constructed with a solid cedar top, which provides a warm, rich tone with excellent projection. The back and sides are made of okoume, contributing to the guitar's overall warmth and clarity. This combination of woods makes the PA230E ideal for a variety of musical styles, from fingerpicking to strumming.

Bracing and Design

The guitar features a modified X-M bracing pattern, which enhances the structural integrity of the top while allowing it to vibrate freely. This results in improved sustain and a more dynamic response. The wooden top board purfling and specially designed wooden rosette around the soundhole add to the guitar's aesthetic charm, giving it a handcrafted appearance.

Neck and Fretboard

The neck of the PA230E is constructed from a five-piece combination of PAAfrican mahogany and Pau Ferro, providing stability and strength. The Macassar ebony fretboard offers a smooth playing surface and is adorned with acrylic and abalone block inlays. With a total of 20 medium frets, players have ample range to explore their musical ideas.

Bridge and Hardware

The Macassar ebony bridge is designed for top loading, which makes string changes quick and easy. Both the nut and saddle are made from unbleached oil-impregnated bone, which enhances the guitar's sustain and tuning stability. Chrome die-cast tuners with an 18:1 gear ratio ensure precise and reliable tuning.

Electronics

The Ibanez PA230E is equipped with the Ibanez AP11 magnetic pickup and a contact pickup, allowing for a versatile range of amplified tones. The custom electronics include controls for volume on both the magnetic and contact pickups, offering players fine-tuned control over their sound. The dual outputs (Mono Out / Stereo Out) provide additional flexibility for various performance and recording setups.

Playability

The PA230E is strung with D'Addario® XTAPB1356 strings, known for their durability and consistent performance. The factory tuning of EADGBE ensures that the guitar is ready to play right out of the box. With a string gauge of .013/.017/.026/.035/.045/.056 and a string space of 11.4mm, the guitar provides a comfortable playing experience for both beginners and experienced players.

Overall, the Ibanez PA230E is a high-quality acoustic-electric guitar that combines traditional craftsmanship with modern features. Its unique construction, premium materials, and versatile electronics make it a standout choice for musicians seeking a reliable and expressive instrument. Whether on stage, in the studio, or at home, the PA230E offers a rich, dynamic sound that can adapt to any playing style.
