32Ci
Step into the footsteps of music icons and experience the unparalleled quality of Harrison 32C preamps – the very ones that have left an indelible mark on some of the most iconic albums in history. From Michael Jackson’s award-winning ‘Thriller’ & ‘Bad’ albums to Paul Simon’s groundbreaking ‘Graceland,’ these preamps have graced recordings by AC/DC, Genesis, Janet Jackson, ELO, Led Zeppelin, and more.
Now, you have the opportunity to elevate your music to the next level with the Harrison/iCON 32Ci – a 12 In / 12 Out USB Interface that encapsulates the essence of the original 32C console. Crafted with world-class precision and inspired by the legendary console, the 32Ci comes packed with an array of features that ensure studio-grade performance.
Join the ranks of musical legends and make your mark with the 32Ci.
It’s time to let your talent shine like never before!
32Ci preamp
Renowned for their warm and transparent sound, the Harrison 32C preamps are a true gem in the recording world. Experience the exceptional clarity they
provide, delivering a clean and detailed signal with minimal noise – perfect for a wide array of recording needs. Equipped with high-quality transformers, these preamps infuse your recordings with a rich, musical character, adding depth and warmth to every track. The 32C preamps boast a broad frequency response, capturing subtle nuances and dynamic ranges with stunning precision.
32Ci filter
The 32 Series consoles revolutionized the industry with their innovative high-pass and low-pass filters, designed to tackle unwanted rumble and hiss in your sources. With ‘dual log’ potentiometers, these unique filters offer an exceptionally wide sweep range, allowing you to overlap them effectively and eliminate the passband altogether. Mixing engineers, including the acclaimed Bruce Swedien, harnessed this capability to optimize their mixes, seamlessly blending multiple instruments without interference.
Discover the “Bump” button, meticulously recreated to emulate the original filter’s slight resonance. Experience an added punch in the low-end, just above the filter’s cutoff frequency. Use this feature strategically to retain vocal presence while expertly filtering out any unwanted rumble captured by the microphone.
Preamp gain : 70dB
With 70dB of gain, these preamps handle high input levels without
distortion, making them the ideal choice for recording powerful
sources like drums and electric guitars.
Product Name | Icon Pro Audio Harrison 32ci Audio Interface |
---|---|
Brand | Icon |
What's in the Box?
- Icon Pro Audio Harrison 32ci Audio Interface
- Two 32C console grade analog mic preamps and console grade 32C filters, (as used by Michael Jackson, Paul Simon, Genesis, AC/DC on the original 32C console)
- 32C Mic/Instrument preamps complimented by individual gain control & phantom power
- ‘Bump’ control for retaining presence, while cutting low frequencies as featured on later modifications to the original 32C analog desk
- Pad switch for 20dB signal attenuation
- 24-Bit 192KHz 2 mic-In/2 inst-In + ADAT connectivity = 12 In x 12 Out capability
- 4×4 analog I/O full duplex simultaneous recording and playback
- High end studio grade AD/DA providing a super high dynamic range of 129 dB
- Supports Mac/PC connectivity simultaneously with Smart Devices
- Live sessions possible with audio signal processing via ProDriver virtual plug-in rack
- Compatible with iOS and Android Digital I/O jack (Type C) & Analog I/O jack (3.5mm
- stereo TRS) for direct connection with SmartPhones, tablets and other devices
- Four analog outputs on 1/4” TRS jacks
- 2x MIDI IN/OUT 5 pin DIN connectors
- Monitor volume control knob
- ‘Alternate’ button for switching between different monitoring set ups
- Extremely well built and robust switch gear and surfaces
- Two headphone outputs with individual volume controls
- Flexible channel routing via the ProDriver software control panel
- ICON Pro Audio developed ultra low latency ProDriverTM driver included
- ICON Pro Audio’s innovative and user friendly plug-in hosting rack software built-in with ProDriverTM(Windows and Mac)
- ARM-M7/500MHz processing power and technology for super fast and extremely stable signal processing – two instances of the chip are used, one for the USB connection and one for mobile devices via the independent Type-C connector at the rear
- +4/-10 button for inputs 3+4
- Supports Direct Sound, WDM and ASIO 2.0
- Loop Back function is possible with ProDriver TM for both Mac and Windows platforms
- Class-compliant with MacOS 10.15 or above & Windows 10 or above
- +12 V DC power supply
- Rugged, high quality construction
Name | Spec |
ADC | |
Dynamic Range: | 125dB, A-weighted |
Signal-to-Noise Ratio: | -125dB, A-weighted |
THD+N Ratio: | -117dB, -1dBFS |
DAC | |
Dynamic Range: | 129dB, A-weighted |
Signal-to-Noise Ratio: | -129dB, A-weighted |
THD+N Ratio: | -120dB, 0dBFS |
Mic1/2 Inputs (XLR, Balanced) | |
Frequency Response: | 20Hz to 20kHz (+/-0.1dB) |
Minimum voltage gain 0dB (fader @ unity, -20dB pad) | |
Maximum voltage gain 70dB (fader @ unity, no pad) | |
Nominal input level -16dBu through -66dBu (fader @ unity, no pad, @ +4dBu output) | |
Maximum input level +18dBu (fader @ unity, -20dB pad) | |
Expected source impedance 150 to 200 Ohms | |
Actual load impedance 1200 Ohms | |
Instrument 1/2 Inputs (6.35mm TS, Unbalanced) | |
Frequency Response: | 20Hz to 20kHz (+/-0.1dB) |
Input Impedance: | 1M Ohms, typical |
Maximum input level +18dBu (fader @ unity, -20dB pad) | |
Line Inputs 3/4 (6.35mm TRS, Balanced) | |
Frequency Response: | 20Hz to 20kHz (+/-0.1dB) Maximum level +24dBu |
Nominal input level +4dBu | |
Expected source impedance 1000 Ohms or less Actual load impedance 10 kOhms | |
Line Outputs 1/2 (6.35mm TRS, Balanced) | |
Frequency Response: | 20Hz to 20kHz (+/-0.1dB); Maximum level +24dBu |
Nominal input level +4dBu | |
Minimum load impedance 600 Ohms | |
Headphone Outputs: (Stereo, Unbalanced) | |
Frequency Response: | 20Hz to 20kHz (+/-1dB) |
Load Impedance: | 16 to 600 Ohms |
Maximum Output Level: | +21dBu, no load; +21dBu, 600Ohms (11.4Vrms) |
+20dBu, 100 Ohms (10Vrms) | |
+14.6dBu, 32 Ohms (5.4Vrms) | |
+8.6dBu, 16 Ohms (2.7Vrms) |
