Djent forefather and speed demon Misha Mansoor has gained widespread acclaim as the mastermind behind the axe-centric progressive metal band Periphery. He’s known to impress the most discerning of metal fans with his steadfast, fleet-fingered technique, and his personally designed collection of Jackson signature Juggernaut instruments is sure to set any shredder’s tone ablaze.
The Pro Series Signature Misha Mansoor Juggernaut HT7 offers a 26.5”-scale length, basswood body, one-piece caramelized bolt-on maple neck with graphite reinforcement for rock-solid stability, wrap-around heel and oiled back finish for greater playing comfort. Enjoy blazing fast leads with a 20” flat radius caramelized maple fingerboard featuring rolled edges, 24 jumbo frets and offset dot inlays. Luminous side-dots will guide your way even on the darkest of stages, while the heel-mount truss rod adjustment wheel allows for convenient neck relief tweaks.
Not willing to sacrifice tone, Mansoor spent considerable time working with Jackson to develop killer-sounding Jackson uncovered direct mount MM1 pickups, which can be shaped with a five-way blade switch, single volume control and single tone control with push/pull select feature.
Available in Neon Orange or Blue Sky Burst with a matching Jackson 4x3 AT-1 headstock, this sig axe also features a Jackson HT7 string-through-body hardtail bridge, die-cast locking tuners and black hardware.
| Product Name | Jackson Pro Series Misha Mansoor Juggernaut HT7 Electrical Guitar, Blue Sky Burst |
|---|---|
| Brand | Jackson |
| Condition | New |
| MPN | 2914007596 |
| UPC | 885978056873 |
| Shipping Option | Free Shipping to the Continental U.S. |
BODY |
|
|---|---|
| BODY MATERIAL | Basswood |
| BODY FINISH | Gloss |
| BODY SHAPE | Juggernaut |
NECK |
|
| NUMBER OF STRINGS | 7 |
| NECK MATERIAL | Caramelized Maple |
| NECK CONSTRUCTION | Bolt-On with Graphite Reinforcement and Scarf Joint |
| NECK BINDING | None - Rolled Fingerboard Edges |
| NECK FINISH | Oiled |
| SCALE LENGTH | 26.5" (673 mm) |
| FINGERBOARD MATERIAL | Caramelized Maple |
| FINGERBOARD RADIUS | 20" (508 mm) |
| NUMBER OF FRETS | 24 |
| FRET SIZE | Jumbo |
| NUT MATERIAL | Black Plastic |
| NUT WIDTH | 1.75" (44.45 mm) |
| POSITION INLAYS | Offset White Dot |
| TRUSS ROD | Dual-Action with Wheel |
| TRUSS ROD NUT | Heel-Mount Truss Rod Adjustment Wheel |
ELECTRONICS |
|
| BRIDGE PICKUP | Jackson® Uncovered MM1 |
| NECK PICKUP | Jackson® Uncovered MM1 |
| CONTROLS | Volume, Tone (with Push/Pull Select Feature) |
| SWITCHING | 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Two Inside Single Coils, Position 3. Both Full Humbucking Pickups, Position 4. Outer Neck Single Coil, Position 5. Full Neck Pickup |
| CONFIGURATION | HH |
HARDWARE |
|
| BRIDGE | Jackson® HT7 String-Through-Body Hardtail |
| HARDWARE FINISH | Black |
| TUNING MACHINES | Jackson® Sealed Die-Cast Locking |
| CONTROL KNOBS | Dome-Style |
| SWITCH TIP | Black |
| NECK PLATE | 4-Bolt (recessed screws) |
Djent forefather and speed demon Misha Mansoor has gained widespread acclaim as the mastermind behind the axe-centric progressive metal band Periphery. He’s known to impress the most discerning of metal fans with his steadfast, fleet-fingered technique, and his personally designed collection of Jackson signature Juggernaut instruments is sure to set any shredder’s tone ablaze.
The Pro Series Signature Misha Mansoor Juggernaut HT7 offers a 26.5”-scale length, basswood body, one-piece caramelized bolt-on maple neck with graphite reinforcement for rock-solid stability, wrap-around heel and oiled back finish for greater playing comfort. Enjoy blazing fast leads with a 20” flat radius caramelized maple fingerboard featuring rolled edges, 24 jumbo frets and offset dot inlays. Luminous side-dots will guide your way even on the darkest of stages, while the heel-mount truss rod adjustment wheel allows for convenient neck relief tweaks.
Not willing to sacrifice tone, Mansoor spent considerable time working with Jackson to develop killer-sounding Jackson uncovered direct mount MM1 pickups, which can be shaped with a five-way blade switch, single volume control and single tone control with push/pull select feature.
Available in Neon Orange or Blue Sky Burst with a matching Jackson 4x3 AT-1 headstock, this sig axe also features a Jackson HT7 string-through-body hardtail bridge, die-cast locking tuners and black hardware.
| Product Name | Jackson Pro Series Misha Mansoor Juggernaut HT7 Electrical Guitar, Blue Sky Burst |
|---|---|
| Brand | Jackson |
| Condition | New |
| MPN | 2914007596 |
| UPC | 885978056873 |
| Shipping Option | Free Shipping to the Continental U.S. |
BODY |
|
|---|---|
| BODY MATERIAL | Basswood |
| BODY FINISH | Gloss |
| BODY SHAPE | Juggernaut |
NECK |
|
| NUMBER OF STRINGS | 7 |
| NECK MATERIAL | Caramelized Maple |
| NECK CONSTRUCTION | Bolt-On with Graphite Reinforcement and Scarf Joint |
| NECK BINDING | None - Rolled Fingerboard Edges |
| NECK FINISH | Oiled |
| SCALE LENGTH | 26.5" (673 mm) |
| FINGERBOARD MATERIAL | Caramelized Maple |
| FINGERBOARD RADIUS | 20" (508 mm) |
| NUMBER OF FRETS | 24 |
| FRET SIZE | Jumbo |
| NUT MATERIAL | Black Plastic |
| NUT WIDTH | 1.75" (44.45 mm) |
| POSITION INLAYS | Offset White Dot |
| TRUSS ROD | Dual-Action with Wheel |
| TRUSS ROD NUT | Heel-Mount Truss Rod Adjustment Wheel |
ELECTRONICS |
|
| BRIDGE PICKUP | Jackson® Uncovered MM1 |
| NECK PICKUP | Jackson® Uncovered MM1 |
| CONTROLS | Volume, Tone (with Push/Pull Select Feature) |
| SWITCHING | 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Two Inside Single Coils, Position 3. Both Full Humbucking Pickups, Position 4. Outer Neck Single Coil, Position 5. Full Neck Pickup |
| CONFIGURATION | HH |
HARDWARE |
|
| BRIDGE | Jackson® HT7 String-Through-Body Hardtail |
| HARDWARE FINISH | Black |
| TUNING MACHINES | Jackson® Sealed Die-Cast Locking |
| CONTROL KNOBS | Dome-Style |
| SWITCH TIP | Black |
| NECK PLATE | 4-Bolt (recessed screws) |
