JBL JRX212 12" Two-Way Sound Reinforcement Loudspeaker System

JBL JRX212 12" Two-Way Sound Reinforcement Loudspeaker System

On order with the manufacturer!

View full details
  • Details
  • Tech Specs
  • Reviews

The JRX212 is a portable, 12-inch, two-way speaker system designed specifically for live performance stage monitoring applications. The JRX200 series delivers the performance and prestige that JBL is known for at an affordable price point. To meet these conflicting design goals, they looked at every element of the speaker system design.

JBL kept everything that makes a speaker perform and sound its best and we eliminated things that don't. With performance, value and popular price points, they are going to be building a lot of JRX200 speakers. This means we can apply efficient, high-volume production methods and purchase materials at the lowest cost. That's how JRX200 delivers unprecedented value.

  • 12" low-frequency driver with a 2.5"-diameter edgewound ribbon voice coil
  • 1" polymer-diaphragm compression driver
  • Progressive Transition high-frequency waveguide provides superior coverage control
  • Advanced network topology design shapes frequency response
  • High-voltage capacitors and inductors with massive cores and heavy-gauge wire
  • Rugged, acoustically superior enclosure is constructed from 3/4" MDF
  • Attractive 18-gauge hexagon perforated, steel grille protects components
  • Dual-angle pole-mount socket lets speaker tilt for more uniform audience coverage
More Information
Product Name JBL JRX212 12" Two-Way Sound Reinforcement Loudspeaker System
Brand JBL
Condition New
MPN JRX212
UPC 050036904490
Shipping Option Free Shipping to the Continental U.S.
Parameter Specification
Power Rating (Continuous/Peak) 250 W / 1000 W
Frequency Range (-10 dB) 60 Hz - 20 kHz
Frequency Response (±3 dB) 80 Hz - 18 kHz
Sensitivity (@1m) 98 dB SPL (1w/1m)
Nominal Impedance 8 ohms
Recommended Amplifier Power 250 W to 500 W into 8 ohms
Maximum SPL (peak) 128 dB
Nominal Dispersion 90° x 50°
Crossover Frequency 2.1 kHz
Dimensions (H x W x D) 584 mm x 399 mm x 325 mm (23 in x 15.7 in x 12.8 in)
Weight 19.5 kg (43 lb)
High Frequency Driver JBL 2414H-C 1" exit compression driver mounted on Progressive Transition Waveguide
Low Frequency Driver JBL M112-8
Input Connectors Neutrik Speakon NL-4 (x1); .25 in TS phone jack (x1); parallel
Grille 18-gauge, powder-coated steel
Mounting & Suspension 36 mm, dual-angle pole-mount socket

JBL JRX212 12" Two-Way Sound Reinforcement Loudspeaker System

Details

The JRX212 is a portable, 12-inch, two-way speaker system designed specifically for live performance stage monitoring applications. The JRX200 series delivers the performance and prestige that JBL is known for at an affordable price point. To meet these conflicting design goals, they looked at every element of the speaker system design.

JBL kept everything that makes a speaker perform and sound its best and we eliminated things that don't. With performance, value and popular price points, they are going to be building a lot of JRX200 speakers. This means we can apply efficient, high-volume production methods and purchase materials at the lowest cost. That's how JRX200 delivers unprecedented value.

  • 12" low-frequency driver with a 2.5"-diameter edgewound ribbon voice coil
  • 1" polymer-diaphragm compression driver
  • Progressive Transition high-frequency waveguide provides superior coverage control
  • Advanced network topology design shapes frequency response
  • High-voltage capacitors and inductors with massive cores and heavy-gauge wire
  • Rugged, acoustically superior enclosure is constructed from 3/4" MDF
  • Attractive 18-gauge hexagon perforated, steel grille protects components
  • Dual-angle pole-mount socket lets speaker tilt for more uniform audience coverage
More Information
Product Name JBL JRX212 12" Two-Way Sound Reinforcement Loudspeaker System
Brand JBL
Condition New
MPN JRX212
UPC 050036904490
Shipping Option Free Shipping to the Continental U.S.
Tech Specs
Parameter Specification
Power Rating (Continuous/Peak) 250 W / 1000 W
Frequency Range (-10 dB) 60 Hz - 20 kHz
Frequency Response (±3 dB) 80 Hz - 18 kHz
Sensitivity (@1m) 98 dB SPL (1w/1m)
Nominal Impedance 8 ohms
Recommended Amplifier Power 250 W to 500 W into 8 ohms
Maximum SPL (peak) 128 dB
Nominal Dispersion 90° x 50°
Crossover Frequency 2.1 kHz
Dimensions (H x W x D) 584 mm x 399 mm x 325 mm (23 in x 15.7 in x 12.8 in)
Weight 19.5 kg (43 lb)
High Frequency Driver JBL 2414H-C 1" exit compression driver mounted on Progressive Transition Waveguide
Low Frequency Driver JBL M112-8
Input Connectors Neutrik Speakon NL-4 (x1); .25 in TS phone jack (x1); parallel
Grille 18-gauge, powder-coated steel
Mounting & Suspension 36 mm, dual-angle pole-mount socket
