The BLACKBOX RECORDER with Lightpipe i/o enables audio capture via a digital mixing console supporting Lightpipe (TOSlink) inputs and outputs. This BBR model can also interface directly with any of the high quality A-D converters that incorporate Lightpipe outputs.
Three 8-channel Lightpipe inputs can be connected from the mixer and three Lightpipe outputs can return the signals back to the mixer. All other BlackBox Recorder features remain unchanged and the full analogue i/o capability of the standard BBR1 is still available for situations where the Lightpipe interface is not suitable.
Note: Due to limitations in the Lightpipe format, use of this option restricts 24-track recording to single speed sample rates (44.1kHz and 48kHz). At double sample rates the unit employs the SMUX2 protocol reducing the i/o count to 12 channels. However, the full 24/24/96kHz facility is still available in the analogue domain.
| Product Name | JoeCo BBR1A BLACKBOX RECORDER Rackmount Multi-Track Recorder (Lightpipe) |
|---|---|
| Brand | JoeCo |
| Condition | New |
| MPN | BBR1-A |
| Shipping Option | Free Shipping on orders over $94.72 |
JoeCo BBR1A BLACKBOX RECORDER Rackmount Multi-Track Recorder (Lightpipe)
Details
The BLACKBOX RECORDER with Lightpipe i/o enables audio capture via a digital mixing console supporting Lightpipe (TOSlink) inputs and outputs. This BBR model can also interface directly with any of the high quality A-D converters that incorporate Lightpipe outputs.
Three 8-channel Lightpipe inputs can be connected from the mixer and three Lightpipe outputs can return the signals back to the mixer. All other BlackBox Recorder features remain unchanged and the full analogue i/o capability of the standard BBR1 is still available for situations where the Lightpipe interface is not suitable.
Note: Due to limitations in the Lightpipe format, use of this option restricts 24-track recording to single speed sample rates (44.1kHz and 48kHz). At double sample rates the unit employs the SMUX2 protocol reducing the i/o count to 12 channels. However, the full 24/24/96kHz facility is still available in the analogue domain.
| Product Name | JoeCo BBR1A BLACKBOX RECORDER Rackmount Multi-Track Recorder (Lightpipe) |
|---|---|
| Brand | JoeCo |
| Condition | New |
| MPN | BBR1-A |
| Shipping Option | Free Shipping on orders over $94.72 |
