JZ Microphones Vintage 47 Microphone

JZ Microphones Vintage 47 Microphone

$799.00
$799.00
Sale Sold out

+ Free Shipping

On order with the manufacturer!
JZ Microphones V47 Vintage 47 Microphone. U 47 is still considered to be one of the finest microphones ever made, therefore JZ Microphones brought to life several great ideas of improvements to add and implement into own JZ Vintage 47 series microphones.
View full details Liquid error (sections/main-product line 888): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features



JZ Microphones V47 Vintage 47 Microphone



U 47 is still considered to be one of the finest microphones ever made, therefore JZ Microphones brought to life several great ideas of improvements to add and implement into own JZ Vintage 47 series microphones.

The heart of Vintage 47 microphone is Golden Drop 47 Capsule (GDC47) and equiped with innovative inner shock-mounting system and adjustable swivel mount, Vintage 47 microphone has perfect functionality and legendary U 47 feel at amazing price point and availability for a handcrafted and tested microphone.

Vintage 47

Transducer type electrostatic
Operating principal pressure gradient
Diaphragms active diameter 25 mm
Frequency range 20 Hz to 20 kHz
Polar pattern cardioid
Output impedance 50 ohms
Rated load impedance 1000 ohms
Suggested load impedance > 500 ohms
Sensitivity at 1000 Hz into 1000 ohms load 22 mV/Pa
S/N Ratio CCIR 468-3 weighted 76 dB
S/N Ratio DIN/IEC 651 A-weighted 87 db-A
Equivalent noise level DIN/IEC A-weighted 6 dB-A
Maximum SPL for 0.5% THD at 1000 ohm load 134 dB
Dynamic range of the microphone preamplifier 128 db
Phantom powering voltage on pins 2 & 3 of XLR +48 V (+/-4 V)
Current consumption < 2 mA
Output connector 3-pin XLR male, gold plated contacts
Signal polarity positive toward pressure on a diaphragm produces positive polarity voltage on XLR pin #2 relatively to pin #3
More Information
Product Name JZ Microphones Vintage 47 Microphone
Brand JZ Microphones
Condition New
MPN V47
UPC 4751008670677
Shipping Option Free Shipping to the Continental U.S.
  • Large diaphragm 1" (25mm) Golden Drop Capsule - Cardioid
  • Extra-low self-noise level - 6 dB (A)
  • Maximum Sound Pressure Level (SPL) - 134 dB
  • Class A discrete electronics, components
  • Gold plated output contacts
  • Handcrafted in Latvia, EU
  • 5 Year Warranty

JZ Microphones Vintage 47 Microphone
Details

CLASSY WARM SOUND THAT WE ALL LOVE

The soul of many classic recordings we all love so much are the legendary microphones that shaped the sonic characteristics of the golden age of music.

The natural warmth and seemingly effortless precision of the recording achieved back in the day inspired JZ Microphones to re-imagine the beautifully sounding microphone, giving it the benefits of today’s available technology.

The unique capsule technology and discrete Class-A electronics allow for extra low self-noise and exceptional ability to withstand very loud sound sources, giving you true confidence in any recording situation.

VINTAGE 47

V47 is a premium class large diaphragm condenser microphone, equipped with a smart built-in shock-mount and ready to offer that classic vintage vibe, loved throughout decades,

More Information
Product Name JZ Microphones Vintage 47 Microphone
Brand JZ Microphones
Condition New
MPN V47
UPC 4751008670677
Shipping Option Free Shipping to the Continental U.S.
Features
  • Large diaphragm 1" (25mm) Golden Drop Capsule - Cardioid
  • Extra-low self-noise level - 6 dB (A)
  • Maximum Sound Pressure Level (SPL) - 134 dB
  • Class A discrete electronics, components
  • Gold plated output contacts
  • Handcrafted in Latvia, EU
  • 5 Year Warranty
