The Omega is a standard-mount cartridge for true high-fidelity sound reproduction.
It's a perfect match for standard USB turntables, fits a wide range of modern and vintage turntables. Omega uses a standard elliptical diamond and is a very reliable cartridge with a characteristic for Ortofon accurate sound.
| Product Name | Ortofon Omega Elliptical Headshell Mounted Cartridge with Stylus |
|---|---|
| Brand | Ortofon |
| Condition | New |
| MPN | OMEGA1e |
| UPC | 5705796010107 |
| Shipping Option | Free Shipping on orders over $94.72 |
- Output voltage at 1000 Hz, 5cm/sec - 4 mV
- Channel balance at 1 kHz - 2 dB
- Channel separation at 1 kHz - 22 dB
- Channel separation at 15 kHz - 15 dB
- Frequency response - 20-21.000 Hz
- Stylus type - Elliptical
- Stylus tip radius - r/R 8/18 µm
- Tracking force range - 1,5-2,0 g (15-20 mN)
- Tracking force, recommended - 1,75 g (17,5 mN)
- Tracking angle - 20°
- Internal impedance, DC resistance - 750 Ohm
- Internal inductance - 450 mH
- Recommended load resistanc - 47 kOhm
- Cartridge weight - 5 g (additional weight incl.)
Ortofon Omega Elliptical Headshell Mounted Cartridge with Stylus
Details
The Omega is a standard-mount cartridge for true high-fidelity sound reproduction.
It's a perfect match for standard USB turntables, fits a wide range of modern and vintage turntables. Omega uses a standard elliptical diamond and is a very reliable cartridge with a characteristic for Ortofon accurate sound.
| Product Name | Ortofon Omega Elliptical Headshell Mounted Cartridge with Stylus |
|---|---|
| Brand | Ortofon |
| Condition | New |
| MPN | OMEGA1e |
| UPC | 5705796010107 |
| Shipping Option | Free Shipping on orders over $94.72 |
Tech Specs
- Output voltage at 1000 Hz, 5cm/sec - 4 mV
- Channel balance at 1 kHz - 2 dB
- Channel separation at 1 kHz - 22 dB
- Channel separation at 15 kHz - 15 dB
- Frequency response - 20-21.000 Hz
- Stylus type - Elliptical
- Stylus tip radius - r/R 8/18 µm
- Tracking force range - 1,5-2,0 g (15-20 mN)
- Tracking force, recommended - 1,75 g (17,5 mN)
- Tracking angle - 20°
- Internal impedance, DC resistance - 750 Ohm
- Internal inductance - 450 mH
- Recommended load resistanc - 47 kOhm
- Cartridge weight - 5 g (additional weight incl.)
