Pultec EQP-1A3 Program Equalizer, Silver Faceplate

Pultec EQP-1A3 Program Equalizer, Silver Faceplate

On order with the manufacturer!

View full details
  • Details
  • Tech Specs
  • Reviews

The 2U (3.5″ tall) EQP-1A3 is a condensed version of the 3U (5.25″ high) EQP-1A.  In 1971, after 10 years of EQP-1A production and due to customer demand, Gene and Ollie rearranged controls and components to reduce the height of the popular equalizer.  As indicated on the original EQP-1A3 product brochures “SAME PARTS, SAME SPECS”.

The EQP-1A3 was the first product in the Pultec line that we brought back into production and has continued to be very popular.  New York City’s Power Station had 24 of them in each control room!  We now make them both, so you can take your pick.  But be assured, they both have all that Pultec mojo that you are seeking.

More Information
Product Name Pultec EQP-1A3 Program Equalizer, Silver Faceplate
Brand Pultec
Condition New
MPN EQP1A3
  • 20, 30, 60, 100 CPS (Hz) shelf boost, 0 – 13.5 dB
  • 20, 30, 60, 100 CPS shelf attenuate, 0 – 17.5 dB
  • 3, 4, 5, 8, 10, 12, 16 KCS (kHz) peak boost, 0 – 18 dB
  • 5, 10, 20 kcs shelf attenuate, 0 – 16 dB
  • Input Impedance: ~600 Ohms
  • Output Impedance: ~50 Ohms
  • Noise: 92 dB below +10 dBm
  • Distortion: ≤ 0.15% at +10 dBm into 600 Ohms
  • Amplifier: Flat, 20 CPS to 20 KCS, +/- 0.5 dB
  • Tubes: 1 ea 12AU7, 12AX7, 6X4
  • Units in box: 1

Pultec EQP-1A3 Program Equalizer, Silver Faceplate

Details

The 2U (3.5″ tall) EQP-1A3 is a condensed version of the 3U (5.25″ high) EQP-1A.  In 1971, after 10 years of EQP-1A production and due to customer demand, Gene and Ollie rearranged controls and components to reduce the height of the popular equalizer.  As indicated on the original EQP-1A3 product brochures “SAME PARTS, SAME SPECS”.

The EQP-1A3 was the first product in the Pultec line that we brought back into production and has continued to be very popular.  New York City’s Power Station had 24 of them in each control room!  We now make them both, so you can take your pick.  But be assured, they both have all that Pultec mojo that you are seeking.

More Information
Product Name Pultec EQP-1A3 Program Equalizer, Silver Faceplate
Brand Pultec
Condition New
MPN EQP1A3
Tech Specs
  • 20, 30, 60, 100 CPS (Hz) shelf boost, 0 – 13.5 dB
  • 20, 30, 60, 100 CPS shelf attenuate, 0 – 17.5 dB
  • 3, 4, 5, 8, 10, 12, 16 KCS (kHz) peak boost, 0 – 18 dB
  • 5, 10, 20 kcs shelf attenuate, 0 – 16 dB
  • Input Impedance: ~600 Ohms
  • Output Impedance: ~50 Ohms
  • Noise: 92 dB below +10 dBm
  • Distortion: ≤ 0.15% at +10 dBm into 600 Ohms
  • Amplifier: Flat, 20 CPS to 20 KCS, +/- 0.5 dB
  • Tubes: 1 ea 12AU7, 12AX7, 6X4
  • Units in box: 1
