The E18SW is a high-performance direct radiation subwoofer with a single, 800W, 18-inch, aluminum frame woofer. It’s designed to produce crushing low-end for live performance with kick-drum and bass in the PA or for high-level, high-energy dance music. A threaded, M20 pole socket and speaker pole are provided for sub/satellite use with any of the E Series two-way models. For portable applications it includes attachment points for four optional casters. The subwoofer’s 4-ohm impedance means that a single woofer can be optimally powered by a less expensive amplifier.
- High output, professional quality sound with 800 W continuous power
- E Series Entertainment System - Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
- Rugged tour-grade textured paint
- Foam-lined perforated steel grill
- E18SW includes speaker pole
| Product Name | QSC E18SW 800W Passive Subwoofer |
|---|---|
| Brand | QSC |
| Condition | New |
| MPN | E18SW |
| UPC | 684284067517 |
| Shipping Option | Free Shipping to the Continental U.S. |
- High output, professional quality sound with 800 W continuous power
- E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
- E Series Entertainment System DSP Tunings are now available for PLD, CXD and GXD processing amplifiers
- Rugged tour-grade textured paint
- Foam-lined perforated steel grill
- E18SW includes speaker pole
- Configuration: 1 x 18-inch, subwoofer, non-powered
- Frequency Range (-6 dB): 37Hz to 230Hz
- Power capacity: continuous/peak: 800 W / 3200 W
- Sensitivity: 98dB, 1W@1m
- Coverage Angle: N/A
- Ouput (peak SPL @ 1 m): 133dB
- Drivers (LF): 457 mm (18-inch) driver with 102 mm (4-inch) voice coil
- Drivers (HF): N/A
- Nominal Impedance: 4Ω
- Cross-Over: Recommended 80-120Hz LPF
- Input Connectors: 2 x NL4, 1 x barrier strip
- Enclosure: Rectangular, plywood, black texture paint finish. Four side-mounted handles. Rear panels provision for optional casters. Perforated, powder-coated steel grille with foam lining.
- Mounting and Suspension: M20 threaded pole-mount socket; 24" (610 mm) pole included.
- Net Weight: 43 kg / 95 lbs
- Dimensions (WxHxD): 23.2x24.2x23.8in
