Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive

Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive

On order with the manufacturer!

View full details Liquid error (sections/main-product line 888): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features
  • Tech Specs

The Radial Bassbone is a power-packed bass preamp that combines on-stage efficiency, amazing tonal control and superb audio performance making it the ideal front end for both live and studio recording.Designed as a bass command center, the Bassbone lets you connect two basses and seamlessly toggle between them using a footswitch. Each channel is equipped with a separate level control to balance the two instruments. This is augmented with a unique EQ that enables you to adjust the tone for each instrument to match with your bass amp. In fact, the EQ is so powerful that you can toggle between channels to emulate switching from a P-Bass to a Rickey using the same bass! For added stage control, a second footswitch engages a power booster for soloing. This works double duty to turn on an effects loop.The Bassbone's highly acclaimed audio circuit features full sized discrete electronics for optimal signal flow to deliver the sound of your bass to your amp with minimal distortion or artifact. Outputs include a 1/4" instrument output for the stage amp, separate always-on tuner out, and a built-in Radial direct box to feed the PA or recording system.

  • Two-channel bass preamp for 1 or 2 bassesBuilt-in Radial direct box with low-Z balanced outCombination power boost and effects loopPowerful EQ and contour control for each bass
More Information
Product Name Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive
Brand Radial Engineering
Condition New
MPN R8007072
UPC 676101041169
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive
  • Power Adapter
  • Toggle between any two basses with ease
  • Individual EQ controls for each input
  • Headphone output for silent practice
  • PZB booster and piezo input for upright bass
  • Built-in Radial DI with balanced output for the PA
Audio circuit type: Discrete class-A FET input with low noise ICs.
Frequency response: 20Hz ~ 18kHz
Dynamic range: 85dB
Gain: Unity gain device
Clip Level: +10dBu at XLR
Total harmonic distortion: 0.05% @ -15dBu
Intermodulation Distortion: 0.2% @ -20dBu
Input Impedance: CH-A: 220K/10M CH-B Variable from 22K to 1.8M
Output Impedance: 300 Ohms at XLR
Equivalent Input Noise: -92dBu at XLR
Noise Floor: -100dB
Maximum Input: +7 dBu
Input Connectors: 1/4"
Output Connectors: 1/4", XLR, 3.5mm
Construction: 14-gauge steel
Size (L x W x D): 8" x 4.2" x 2" (203 x107 x 48mm)
Weight: 2.55lb (1157 grams)
Shipping size (L x W x D): 10.75" x 5"x 2.75" (273 x 127 x 70mm)
Shipping weight: 2.8lb (1270 grams)
Power: +15VDC/400mA adapter included
Conditions: For use in dry locations only between 5°C and 40°C

Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive

Details

The Bassbone OD allows you to connect two bass guitars and sculpt the tone of each one individually, as each input has its own level and EQ controls. The EQ settings have been specifically tailored for use with basses, and include a high pass filter to roll off excessive low end, along with a selectable center frequency for the Mid EQ boost/cut. Input A features a PZB booster designed for use with upright basses that employ a piezo transducer, while Input B includes a Drag Control impedance correction circuit that adjusts the load presented to magnetic pickups for a more natural tone. Following the input and EQ section, the Bassbone OD allows both instruments to share your effects pedals with an EFX Loop, which then feeds a powerful on-board overdrive.

More Information
Product Name Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive
Brand Radial Engineering
Condition New
MPN R8007072
UPC 676101041169
Shipping Option Free Shipping to the Continental U.S.

What's in the Box?

  • Radial Engineering Bassbone OD Bass Dual Channel Preamp Pedal w/ Overdrive
  • Power Adapter
Features
  • Toggle between any two basses with ease
  • Individual EQ controls for each input
  • Headphone output for silent practice
  • PZB booster and piezo input for upright bass
  • Built-in Radial DI with balanced output for the PA
Tech Specs
Audio circuit type: Discrete class-A FET input with low noise ICs.
Frequency response: 20Hz ~ 18kHz
Dynamic range: 85dB
Gain: Unity gain device
Clip Level: +10dBu at XLR
Total harmonic distortion: 0.05% @ -15dBu
Intermodulation Distortion: 0.2% @ -20dBu
Input Impedance: CH-A: 220K/10M CH-B Variable from 22K to 1.8M
Output Impedance: 300 Ohms at XLR
Equivalent Input Noise: -92dBu at XLR
Noise Floor: -100dB
Maximum Input: +7 dBu
Input Connectors: 1/4"
Output Connectors: 1/4", XLR, 3.5mm
Construction: 14-gauge steel
Size (L x W x D): 8" x 4.2" x 2" (203 x107 x 48mm)
Weight: 2.55lb (1157 grams)
Shipping size (L x W x D): 10.75" x 5"x 2.75" (273 x 127 x 70mm)
Shipping weight: 2.8lb (1270 grams)
Power: +15VDC/400mA adapter included
Conditions: For use in dry locations only between 5°C and 40°C
