Designed primarily for live concerts and stage shows where backing tracks are used for orchestration, vocals and sound effects, SW8 employs an adjustable gate to detect a machine malfunction and automatically switch to a second backup machine to deliver a seamless performance. The SW8 will monitor any continuous audio signal such as SMPTE on the main playback system, and should the signal drop it will automatically switch to the backup. Switching can also be performed manually on the front panel, or by using a footswitch such as the Radial JR2. For larger systems beyond 8 channels, multiple SW8s may be linked together.
| Product Name | Radial SW8-Channel Line Level Auto Switcher |
|---|---|
| Brand | Radial Engineering |
| MPN | SW8 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Radial SW8-Channel Line Level Auto Switcher
- Power Supply
| Audio Circuit Type | Passive signal path with active relay switching |
| Transformer | Eclipse ET-DB2 |
| Channels | 8 |
| Frequency Response | 20 Hz – 20 kHz |
| Dynamic Range | >120 dB |
| Gain | -20 dB |
| Total Harmonic Distortion | 0.002% |
| Intermodulation Distortion | >0.002% |
| Phase Deviation | -2° @ 20 Hz |
| Input Impedance | 140k Ohms, balanced |
| Output Impedance | 150 Ohms, balanced |
| CMRR | -112 dB at 50/60 Hz |
| Equivalent Input Noise | -95 dBu |
| Noise Floor | -115 dBu |
| Maximum Input | 26 dBu |
| Features | Input pad, Ground lift, Remote Footswitch |
| Input Connectors | 1/4" TRS, D-sub |
| Output Connectors | XLR, D-sub |
| Extras | Contact Alarm Input, JR-2 XLR |
| Construction | 14-gauge steel chassis & outer shell |
| Dimensions (L × W × H) | 17.5" x 6" x 1.75" (44.5 cm x 15.25 cm x 4.5 cm) |
| Weight | 9.2 lb (4.2 kg) |
| Power | Two +15VDC / 400mA power supplies included |
| Operating Conditions | Dry location use, 5°C to 40°C (41°F to 104°F) |
