Active speakers for live sound reinforcement and stage monitoring as well as distributed sound systems for clubs, music venues and corporate events. ART 312-A MK4 is the optimum choice for live sound situations where an exceptional full range, outstanding bass reproduction and accurate high frequency delivery are required.
The ART Series is the beating heart of RCF. These multiple purpose active speakers represent the finest examples of audio design in a rugged composite cabinet, now in black. The MK4 Series is equipped with a new generation of 2-way Class-D fan-less amplifiers, high-powered woofers and the latest compression driver technology, plus a redesigned front grille. The ART concept offers the best audio choice for a multitude of live sound applications in a plug‘n’go device.Just connect your microphone, your mixer or your audio device to the speaker and turn up the volume: there are no complex menus, no knobs to understand.
| Product Name | RCF ART-312A-MK4 Active 800W 2-Way 12" w/1" HF Comp. Loudspeaker |
|---|---|
| Brand | RCF |
| Condition | New |
| MPN | ART-312A-MK4 |
| UPC | 709951947975 |
| Shipping Option | Free Shipping to the Continental U.S. |
- 128 dB Max SPL
- 800 WATT 2-way peak power
- DSP Processing with FiRPHASE
- 12" woofer, high power 2.5" voice coil
- 1" HF driver, mylar dome, 1.5" voice coil
ACOUSTICAL SPECIFICATIONS
- Frequency Response -3 dB:50Hz ÷20000Hz
- Max SPL:128dB
- Horizontal coverage angle:90°
- Vertical coverage angle:60°
- Compression Driver:1", 1.5" v.c.
- Woofer:12", 2.5" v.c.
INPUT/OUTPUT SECTION
- Input signal:bal / unbal
- Input connectors:XRL, Jack
- Output connectors:XLR
- Input sensitivity:-2 dBu/+4 dBu
- Mic. Input Sensitivity:-32
PROCESSOR SECTION
- Crossover frequencies:1800Hz
- Protections:Thermal, RMS
- Limiter:Soft Limiter
- Controls:Volume, Boost, Mic/Line
AMPLIFIER SPECIFICATIONS
- Total power:800W PEAK
- High frequencies:200W PEAK
- Low frequencies:600W PEAK
- Total power:400W RMS
- High frequencies:100W RMS
- Low frequencies:300W RMS
- Cooling:Convection
- Connections:VDE
CABINET
- Cabinet Material:Composite PP
- Hardware:4xM10 flying p.
- Handles:2 side, 1 top
- Pole Mount/Cap:Yes
- Grille:Steel
- Colour:Black
PHYSICAL SPECIFICATIONS
- Height:680 / 26.77mm/inch
- Width:405 / 15.94mm/inch
- Depth:345 / 13.58mm/inch
- Net Weight:16.8 / 37.04kg/lbs
