EVOX J11 is an active, three-way portable column system designed for maximum clarity and power in a compact format. A 1.75” compression driver coupled with a 120° × 40° True Resistive Waveguide ensures wide, consistent coverage, while 12 x 3” full-range transducers and a high-power 12” woofer in a bass-reflex enclosure deliver articulate mids and deep, controlled lows. Driven by a 3500W onboard dual-channel Class-D amplifier, EVOX J11 delivers an impressive 132 dB Max SPL output. Part of the EVOX J Series, it incorporates RCF’s tour-grade technology into a sleek, unobtrusive package that delivers crystal-clear vocals, natural musical response, and effortless deployment for bands, DJs, and live performers.
| Product Name | RCF EVOX J11 Active 12" 3-Way 3500W Portable Line Array PA System - White |
|---|---|
| Brand | RCF |
| Condition | New |
| MPN | EVOX-J11-W |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- RCF EVOX J11 Active 12" 3-Way 3500W Portable Line Array PA System - White
- Power Cable
- Top Speaker Padded Carrying Bag
- 132 dB Max SPL
- 3500 W Class-D Amplifier - Built-In DSP
- 1.75” Neo Compression Driver - 120° X 40° True Resistive Waveguide
- 12 × 3” Full-Range Neo Transducers
- 12” High-Power Woofer
- Enhanced Coverage And Clarity
- Composite Cabinet With Aluminum Stand Mount
- Sleek, Road-Ready Design
- Top Speaker Padded Carrying Bag Included
Acoustical Specifications |
|
|---|---|
| Frequency Response | 37 Hz – 20,000 Hz |
| Max SPL @ 1m | 132 dB |
| Horizontal Coverage Angle | 120° |
| Vertical Coverage Angle | 40° |
Transducers |
|
| Compression Driver | 1 × 0.75" (19.05 mm) neo, 1.75" (44.45 mm) v.c |
| Fullrange | 12 × 3.0" (76.2 mm) neo, 1.0" (25.4 mm) v.c |
| Woofer | 1 × 12" (304.8 mm), 2.5" (63.5 mm) v.c |
Input / Output Section |
|
| Input Signal | Balanced / Unbalanced |
| Input Connectors | Combo XLR / Jack |
| Output Connectors | XLR |
| Input Sensitivity | +4 dBu |
Processor Section |
|
| Crossover Frequencies | 160 Hz / 1800 Hz |
| Protections | Thermal, RMS |
| Limiter | Soft Limiter |
| Controls | Volume, Presets: LINEAR / LIVE, CLUB, VOICE |
Power Section |
|
| Total Power | 3500 W Peak |
| High Frequencies | 1500 W Peak |
| Low Frequencies | 2000 W Peak |
| Cooling | Convection |
| Connections | Powercon TRUE1 TOP IN / OUT |
Compliance |
|
| Standard Compliance | CE Compliant |
Physical Specifications |
|
| Cabinet / Case Material | PP Composite |
| Handles | 1 Top |
| Pole Mount / Cap | Quick-fit socket |
| Grille | Steel |
| Color | Black, White (RAL 9003) |
Size / Weight |
|
| Height | 2080 mm (81.89") |
| Width | 350 mm (13.78") |
| Depth | 563 mm (22.17") |
| Weight | 29 kg (63.93 lbs) |
Shipping Information |
|
| Package Height | 676 mm (26.61") |
| Package Width | 451 mm (17.76") |
| Package Depth | 581 mm (22.87") |
| Package Weight | 35 kg (77.16 lbs) |
