RCF F10-XR 10-Channel Mixer w/ FX and Recording
RCF F10-XR 10-Channel Mixer w/ FX and Recording
+ Free Shipping
![Blink Image](https://cdn.shopify.com/s/files/1/0750/9049/3723/files/blink-2020-sq-scaled.png?v=1695807695")
Limited quantities available!
Couldn't load pickup availability
- Details
- Features
- Tech Specs
- Reviews
RCF’s next generation F Series mixers builds on the rich analog legacy found in the professional E Series, featuring high quality sound in four formats from 6 to 16 channels. A powerful tool for the musician and the sound enthusiast, entirely conceived and designed by the RCF R&D team. Housed in a sturdy metal chassis, each mixer features a full balanced audio path from input to output and the unique PRO DSP FX: 16 professional effects such as Reverbs (Halls, Rooms, Plates, Spring), Delays (Mono, Stereo and Multitap), Chorus, Flangers and Echoes. The models F-10XR, F-12XR, and F-16XR, include an USB audio interface, for stereo recording on computer-based DAW and 2-channel playback.
| Product Name | RCF F10-XR 10-Channel Mixer w/ FX and Recording |
|---|---|
| Brand | RCF |
| Condition | New |
| MPN | 17140089 |
| UPC | 8024530016142 |
| Shipping Option | Free Shipping to the Continental U.S. |
- 4 Mic preamp inputs, 2 mono line inputs
- 4 Stereo line inputs
- PRO DSP FX onboard with 16 presets
- Stereo recording and playback via USB port
- 2 single control compressors
- Balanced main output +28 dB (Stereo XLR + TRS)
- 1 aux/FX (post)
- Sturdy metal chassis
- External universal power supply
- Designed and engineered in Italy
Auxiliary Sends
- FX POST: 1
Compressors
- RCF COMPRESSORS: n° 2 Single Control compressors on channels 1&2
Electrical Specifications
- POWER CONSUMPTION (W): 18 W
- VOLTAGE REQUIREMENTS: 100 V - 240 V
- THD+N, 20DB GAIN, 0DBU OUT (% A-WEIGHTED): <0,02
- POWER SUPPLY: External
- FREQUENCY RESPONSE: 20 Hz ÷ 20 kHz
EQ
- DESCRIPTION: High:+/-15 dB @ 10 kHz Shelving Mid:+/-15 dB @ 1,250 kHz Bell Low:+/-15 dB @ 100 Hz Shelving
- INPUT CHANNELS EQ: 2 Shelving / 1 Generic
Inputs
- GAIN RANGE: 0 dB ÷ -50 dB
- MIC INPUTS IMPEDANCE (KOHM): 14 kohm
- LINE INPUT IMPEDANCE (KOHM): 21 kohm
- MIC: 4
- STEREO LINE: 4
- STEREO LINE INPUT IMPEDANCE: 15 kohm
- GAIN SELECTION: 20 dB ÷ -30 dB
- LINE: 2
- LOW CUT: 80 Hz
- PHANTOM POWER +48V: Yes
- STEREO LINE GAIN SELECTION: 20 dB ÷ -30 dB
Internal Effects
- SEND EFFECTS: 1
Other Features
- FOOTSWITCH: Yes
Outputs
- AUX OUTPUT: 1
- FX SEND: 1
- PHONES: 1
- CONTROL ROOM: Yes
- MAIN MIX: 1
Outputs Specifications
- AUX OUT LEVEL (DBU): 28 dBu
- PHONES OUT IMPEDANCE (OHM): 150 ohm
- MAIN OUT LEVEL (DBU): 28 dBu
Physical Specifications
- CABINET/CASE MATERIAL: Metal
- COLOR: Black
USB Audio
- PLAY TRK: 2
- SUPPORTED SAMPLE RATE (KHZ): 44.1, 48.0
- REC TRK: 2
- TYPE: B
RCF F10-XR 10-Channel Mixer w/ FX and Recording
RCF’s next generation F Series mixers builds on the rich analog legacy found in the professional E Series, featuring high quality sound in four formats from 6 to 16 channels. A powerful tool for the musician and the sound enthusiast, entirely conceived and designed by the RCF R&D team. Housed in a sturdy metal chassis, each mixer features a full balanced audio path from input to output and the unique PRO DSP FX: 16 professional effects such as Reverbs (Halls, Rooms, Plates, Spring), Delays (Mono, Stereo and Multitap), Chorus, Flangers and Echoes. The models F-10XR, F-12XR, and F-16XR, include an USB audio interface, for stereo recording on computer-based DAW and 2-channel playback.
| Product Name | RCF F10-XR 10-Channel Mixer w/ FX and Recording |
|---|---|
| Brand | RCF |
| Condition | New |
| MPN | 17140089 |
| UPC | 8024530016142 |
| Shipping Option | Free Shipping to the Continental U.S. |
- 4 Mic preamp inputs, 2 mono line inputs
- 4 Stereo line inputs
- PRO DSP FX onboard with 16 presets
- Stereo recording and playback via USB port
- 2 single control compressors
- Balanced main output +28 dB (Stereo XLR + TRS)
- 1 aux/FX (post)
- Sturdy metal chassis
- External universal power supply
- Designed and engineered in Italy
Auxiliary Sends
- FX POST: 1
Compressors
- RCF COMPRESSORS: n° 2 Single Control compressors on channels 1&2
Electrical Specifications
- POWER CONSUMPTION (W): 18 W
- VOLTAGE REQUIREMENTS: 100 V - 240 V
- THD+N, 20DB GAIN, 0DBU OUT (% A-WEIGHTED): <0,02
- POWER SUPPLY: External
- FREQUENCY RESPONSE: 20 Hz ÷ 20 kHz
EQ
- DESCRIPTION: High:+/-15 dB @ 10 kHz Shelving Mid:+/-15 dB @ 1,250 kHz Bell Low:+/-15 dB @ 100 Hz Shelving
- INPUT CHANNELS EQ: 2 Shelving / 1 Generic
Inputs
- GAIN RANGE: 0 dB ÷ -50 dB
- MIC INPUTS IMPEDANCE (KOHM): 14 kohm
- LINE INPUT IMPEDANCE (KOHM): 21 kohm
- MIC: 4
- STEREO LINE: 4
- STEREO LINE INPUT IMPEDANCE: 15 kohm
- GAIN SELECTION: 20 dB ÷ -30 dB
- LINE: 2
- LOW CUT: 80 Hz
- PHANTOM POWER +48V: Yes
- STEREO LINE GAIN SELECTION: 20 dB ÷ -30 dB
Internal Effects
- SEND EFFECTS: 1
Other Features
- FOOTSWITCH: Yes
Outputs
- AUX OUTPUT: 1
- FX SEND: 1
- PHONES: 1
- CONTROL ROOM: Yes
- MAIN MIX: 1
Outputs Specifications
- AUX OUT LEVEL (DBU): 28 dBu
- PHONES OUT IMPEDANCE (OHM): 150 ohm
- MAIN OUT LEVEL (DBU): 28 dBu
Physical Specifications
- CABINET/CASE MATERIAL: Metal
- COLOR: Black
USB Audio
- PLAY TRK: 2
- SUPPORTED SAMPLE RATE (KHZ): 44.1, 48.0
- REC TRK: 2
- TYPE: B
