PC

• 32 & 64 bits VST, *AAX for Windows Vista / Windows 7/ Windows 8/ **Windows 10
  *AAX for Pro Tools 12 or higher
  ** check first if your music host program is compatible with Windows 10
  Note: Minimal 1000pixel high screen resolution is needed for RP-EQ.

Mac

• 32 & 64 bits AU, VST and AAX, for OSX 10.6 or higher
  Note: Minimal 1000pixel high screen resolution is needed for RP-EQ.

Presets & Banks

• Several banks with presets, selectable in the upper screen section

Current Presets A /B

• A Preset in RP-EQ has two slots, A and B, to store two variations of the Preset. The A
• and B variations are useful to compare different versions while you are editing. The
• current, live, settings can be recalled at any time via the Current button

Volume

• Volume control with in the uppers section the 'on/off' option for 'volume correction' if volume goes over 0dB.
  Bypass button to hear the difference between the 'original' signal and 'RP-EQ' signal.

Spectogram

• The RP-EQ spectrogram displays the input and output signal as an FFT Spectrogram, a 30 band (1/3 octave) Bar Spectrogram or a 30
• band (1/3 octave) Single line Spectrogram. The icons on the left hand side of the Spectrogram display switch the display mode between FFT Spectrogram, Bar
• Spectrogram and the Single Line Spectrogram.
  Controls for 'Hold' and 'Release' of the peak lines in Bar mode. Control of 'Release' in the Single Line mode.
  Display mode of: Left, Right, Stereo or Mid/Side
  Additional 'gain' boost control.

EQ

• 8 band EQ which can work in normal mode or Mid/Side mode.
  In Mid/Side mode, the Bands 1-4 are for the 'Mid' signal and Bands 5-8 for the 'Side' signal.
  Graphic control panel and lower control panel with additional setting options for view , solo or lock a single band.

Saturation

• The Saturation section applies a warming effect to the sound, based on the effect of saturated analogue tape recordings.

AIR

• The Air section represents an additional EQ band, which works as a booster of very high frequencies with a wide bandwidth.
  Its effect is perceived as giving the audio a bit more breathing space or Air.

Filter

• A typical application of this filter section is to use the HP filter with a setting of 75 Hz to
• filter out any rumble or otherwise uncontrolled low-end material. The slope of the
• filters is selectable between 12 dB and 24 dB per octave and each filter comes in two
• filter types.
• A LP filter is a classic ingredient of any synthesizer set-up and we have added one in
• RP-EQ to enhance the creative application of equalisation. In combination with the XY
• pad, the Filter section is the place to start for dynamic and rhythmic filter effects.

Stereo/Mono Split Filter

• The Mono / Stereo Split Filter is able to divide the audio signal in a mono and stereo part
• based on a frequency. Typically, low frequencies do not contain much spatial information
• and are perceived as mono signals. Spatial placement in a stereo image is provided by the
• higher frequencies. The Split Filter is a great tool for contemporary music in a mix-bus
• configuration or for mastering.
• The signal post the Split Filter consists of two parts that can be processed separately: a
• lower frequency mono component and a higher frequency stereo component.

XY section

• The XY Screen works as two programmable LFOs. Movement in each direction directly controls the value of one or more RP-EQ parameters.
• XY basics – Live / Record / Replay
• In Live mode you move the blue dot manually across the XY pad (use the mouse to click
• and drag). The position of the mouse and your dragging skills determine the X and Y
• value. You can also record movements on the XY pad as paths. Switch XY to Rec mod and draw
• a path. For as long as you keep the mouse button pressed, RP–EQ will capture all
• movements as a path in its memory. After recording, the path is ready for playback. Switch to Replay mode, and play a note.
• You will see the XY indicator move across the screen according to previously recorded
• path. The path is saved as part of the Preset, and is ready to go when you recall the
• Preset.
• Instead of playing a note to trigger the path playback, the path can also be made to run
• freely, or triggered manually by clicking the button adjacent to the mode Switch.

System Requirements

• PC:32 & 64 bits VST, *AAX for Windows Vista / Windows 7/ Windows 8/ **Windows 10
  *AAX for Pro Tools 12 or higher
  ** check first if your music host program is compatible with Windows 10
  Note: Minimal 1000pixel high screen resolution is needed for RP-EQ.
• Mac:32 & 64 bits AU, VST and AAX, for OSX 10.6 or higher
  Note: Minimal 1000pixel high screen resolution is needed for RP-EQ.
• For products with serial / license system with activation, after you have regsiter your original serial / license, you can then request a 2nd serial for your 2nd computer/laptop.
