The MX310 MorMics - three channel microphone mixer. Although having many uses, this little mixer was originally designed for people that need to plug 2 or 3 more mics into a mic input. The MX310 is a 3 channel microphone mixer with balanced XLR inputs, phantom power, and XLR Mic/Line output. It has a stereo 1/8" (3.5mm) Auxiliary input for connection to any stereo line-level source such as an AM/FM tuner, CD player etc. A 3.5mm stereo output jack is provided for connection to a computer, ear buds, or other monitoring.
The new MX310 is a 3 channel mono microphone mixer. It has individually switchable phantom power for each channel and individualy switchable low cut filters for each channel. The MX310 also features a 3.5mm (1/8”) headphone output jack for monitoring. The MX310 is built in an all metal chassis and weighs 1 pound. Overall dimension are 5.25” X 3.75” X 1.5”. Bottom mounts are provided for permanent installations. The MX310 ships with an included 12 VDC external power supply. The output XLR of the MX310 is switchable for mic or line level output to make the MX310 match up to almost any appliction.
SPECIFICATIONS
Input Impedance: 600 Ohms
Output Impedance: 600 Ohms
Voltage Gain: 50 dB Line/10 dB Mic
Maximum Supply Voltage: 16 VDC
THD: .05% typical
Bandwidth: 20Hz - 20 kHz
Size: 5.25" x 3.75" x 1.5"
Weight: 1 lb.
Included: PS27 external power supply
| Product Name | Rolls MX310 3 Channel Mixer |
|---|---|
| Brand | Rolls |
| MPN | MX310 |
| UPC | 675889031003 |
| Shipping Option | Free Shipping on orders over $94.72 |
Rolls MX310 3 Channel Mixer
Details
The MX310 MorMics - three channel microphone mixer. Although having many uses, this little mixer was originally designed for people that need to plug 2 or 3 more mics into a mic input. The MX310 is a 3 channel microphone mixer with balanced XLR inputs, phantom power, and XLR Mic/Line output. It has a stereo 1/8" (3.5mm) Auxiliary input for connection to any stereo line-level source such as an AM/FM tuner, CD player etc. A 3.5mm stereo output jack is provided for connection to a computer, ear buds, or other monitoring.
The new MX310 is a 3 channel mono microphone mixer. It has individually switchable phantom power for each channel and individualy switchable low cut filters for each channel. The MX310 also features a 3.5mm (1/8”) headphone output jack for monitoring. The MX310 is built in an all metal chassis and weighs 1 pound. Overall dimension are 5.25” X 3.75” X 1.5”. Bottom mounts are provided for permanent installations. The MX310 ships with an included 12 VDC external power supply. The output XLR of the MX310 is switchable for mic or line level output to make the MX310 match up to almost any appliction.
SPECIFICATIONS
Input Impedance: 600 Ohms
Output Impedance: 600 Ohms
Voltage Gain: 50 dB Line/10 dB Mic
Maximum Supply Voltage: 16 VDC
THD: .05% typical
Bandwidth: 20Hz - 20 kHz
Size: 5.25" x 3.75" x 1.5"
Weight: 1 lb.
Included: PS27 external power supply
| Product Name | Rolls MX310 3 Channel Mixer |
|---|---|
| Brand | Rolls |
| MPN | MX310 |
| UPC | 675889031003 |
| Shipping Option | Free Shipping on orders over $94.72 |
