Rosendahl Nanosyncs HD Audio Clock & Video Sync Engine
Rosendahl Nanosyncs HD Audio Clock & Video Sync Engine
Regular price
$2,100.00
Regular price
Sale price
$2,100.00
Unit price
per
+ Free Shipping
![Blink Image](https://cdn.shopify.com/s/files/1/0750/9049/3723/files/blink-2020-sq-scaled.png?v=1695807695")
On order with the manufacturer!
Couldn't load pickup availability
- Details
- Reviews
With the introduction of high definition video standards, synchronisation of digital audio and video signals is becoming an even more exacting and complex task than it has been already.
The new Nanosyncs HD Multi Standard Sync Engine is an intricate electronic gearbox which locks PAL, NTSC or slow PAL, progressive or interlaced HD Trilevelsyncs and digital audio reference signals together in any required combination.
The improved DDS audio clock synthesiser combined with a new, ultra high frequency analog PLL design results in lowest clock jitter and minimal phase drift. Word clock jitter is < 8 ps RMS within the audio spectrum (20 Hz 20 kHz). Jittery, interrupted or lost input signals do not affect the stability of the video and audio reference outputs. The unlock and relock procedures are processed smoothly and ensure that all output signals deliver stable reference signals in all operation conditions. A Nanosyncs HD Multi Standard Sync Engine inserted in your synchronisation chain guarantees continuous, steady sync signals.
Six video outputs can be individually routed to output SD standard video sync or the HD Trilevelsync reference signal.
The internal SD and HD video generators can be genlocked to external standard definition video syncs as well as to HD Trilevelsync signals with framerates at 24, 48, 25, 50, 30, 60 Hz including the respective -0.1 % pull down values. The generated output standards are selected independent of the incoming video reference format which allows genlocking different video standards together.
All audio clocks can be resolved to the video section as well as to external word clock or free running LTC time code signals.
A midi device class compliant USB port serves to feed a digital audio workstation with MTC and forms together with the locked audio clock signals a complete DAW synchronisation solution.
The integrated LTC generator can be controlled locally or via MMC / MTC from a host computer to provide a video phase locked time code output.
The firmware of the unit can be updated using the USB port to implement upcoming standards in the new domain of high definition video and audio.
| Product Name | Rosendahl Nanosyncs HD Audio Clock & Video Sync Engine |
|---|---|
| Brand | Rosendahl |
| Condition | New |
| MPN | NANOSYNCS-HD |
| UPC | 4530027121267 |
| Shipping Option | Free Shipping to the Continental U.S. |
Rosendahl Nanosyncs HD Audio Clock & Video Sync Engine
Details
With the introduction of high definition video standards, synchronisation of digital audio and video signals is becoming an even more exacting and complex task than it has been already.
The new Nanosyncs HD Multi Standard Sync Engine is an intricate electronic gearbox which locks PAL, NTSC or slow PAL, progressive or interlaced HD Trilevelsyncs and digital audio reference signals together in any required combination.
The improved DDS audio clock synthesiser combined with a new, ultra high frequency analog PLL design results in lowest clock jitter and minimal phase drift. Word clock jitter is < 8 ps RMS within the audio spectrum (20 Hz 20 kHz). Jittery, interrupted or lost input signals do not affect the stability of the video and audio reference outputs. The unlock and relock procedures are processed smoothly and ensure that all output signals deliver stable reference signals in all operation conditions. A Nanosyncs HD Multi Standard Sync Engine inserted in your synchronisation chain guarantees continuous, steady sync signals.
Six video outputs can be individually routed to output SD standard video sync or the HD Trilevelsync reference signal.
The internal SD and HD video generators can be genlocked to external standard definition video syncs as well as to HD Trilevelsync signals with framerates at 24, 48, 25, 50, 30, 60 Hz including the respective -0.1 % pull down values. The generated output standards are selected independent of the incoming video reference format which allows genlocking different video standards together.
All audio clocks can be resolved to the video section as well as to external word clock or free running LTC time code signals.
A midi device class compliant USB port serves to feed a digital audio workstation with MTC and forms together with the locked audio clock signals a complete DAW synchronisation solution.
The integrated LTC generator can be controlled locally or via MMC / MTC from a host computer to provide a video phase locked time code output.
The firmware of the unit can be updated using the USB port to implement upcoming standards in the new domain of high definition video and audio.
| Product Name | Rosendahl Nanosyncs HD Audio Clock & Video Sync Engine |
|---|---|
| Brand | Rosendahl |
| Condition | New |
| MPN | NANOSYNCS-HD |
| UPC | 4530027121267 |
| Shipping Option | Free Shipping to the Continental U.S. |
