Sennheiser XSW 1-825-A Vocal System - Frequency A

Sennheiser XSW 1-825-A Vocal System - Frequency A

On order with the manufacturer!

View full details
  • Details
  • Features
  • Tech Specs
  • Reviews

XS WIRELESS 1 has been designed for first-time and casual wireless users who appreciate simplicity, fast set-up, and no complications. With intuitive icon-based controls and one-touch synchronization, XS WIRELESS 1 is wireless the easy way.

They developed XS Wireless 1 for those who want to concentrate on their talent, their message, their passion — and not their microphone equipment. Just switch it on and its automatic frequency management does the rest. You can operate up to ten wireless connections simultaneously. No matter whether you’re in a band, a theater or at a seminar: XS Wireless 1 makes you free to do your thing.

XS Wireless 1 delivers acclaimed Sennheiser quality. Microphones with feedback protection and high-grade components yield an open, forceful sound. The receiver comes in an updated version that is designed to be easy to use. No lengthy set up — just go! These microphones and transmitters are proven classics — the result of decades of German engineering.

On stage, you have to put up with a lot of things — so does your equipment. XS Wireless 1 is built to last: Transmitters and microphones are sweat-resistant and withstand even the toughest stress in everyday on-stage use.

More Information
Product Name Sennheiser XSW 1-825-A Vocal System - Frequency A
Brand Sennheiser
Condition New
MPN 507108
UPC 615104278615
Shipping Option Free Shipping on orders over $94.72
  • Integrated antennas
  • Up to 10 compatible channels
  • Antenna-switching diversity reception
  • Automatic frequency management and synchronization via remote channel for easy setup
  • Selectable UHF frequencies within a large bandwidth
  • Easiest handling
  • Reliable transmission
  • Excellent live sound
System
Modulation: Wideband FM
Frequency Range: A - 548 to 572 MHz
Switching Bandwith: Up to 24 MHz
Signal to Noise Ration: â‰¥ 103 dBA
Total Harmonic Distortion: â‰¤ 0.9%
Temperature Range: 32 to 104 Â° F (operation) & -4 to 158 Â° F (storage)
Transmitter Synchronization: 2.4 GHz, Low Power (onyl active during synchronization)


Receiver
Principle: Double superheterodyne
Diversity: Antenna switching diversity via internal antennas
Sensitivity: < 3 μV at 52 dBA RMS S/N (at peak deviation)
Frequency Response: 50 Hz to 16 kHz (-3 dB)
Max Output Voltage: At Peak Deviation, 1 kHz AF
1/4" (6.3mm) Jack Socket (unbalanced): +6 dBu
XLR Socket (balanced): +12 dBu
Adjustment Range: Audion - 45 dB, adjustble to 5-dB steps
Power Supply: 12 VDC nominal/300 mA
Squelch: Adjustable from 3 dB Î¼V to 28 dB μV (combined with pilot tone)
Line/Mic Level: 20 dB, switchable
Material of Construction: ABS Housing
Dimensions (WxHxD): 7.9 x 1.7 x 5.0” (200 x 42 x 127mm)
Weight: 12 oz (340g)



Microphone
Outout Power: 10 mW
Frequency Response: 801 Hz to 14 kHz
Power Supply: 2 x AA batteries, 1.5v
Operating Time: Approximately 10 hrs
Microphone Type: Dynamic
Polar Pattern: Cardiod
Input Sensitivity: Capsule - 1.5 mV/Pa
Adjustment Range: Transmitter Sensitivity - 0 tp -30 dB, adjustable in 10 dB steps
Material of Construction: Rugged ABS housing
Dimensions (L x Diam): 10 x 2.0” (260 x 50mm)
Weight: 8.6 oz (245g)

Sennheiser XSW 1-825-A Vocal System - Frequency A

Details

XS WIRELESS 1 has been designed for first-time and casual wireless users who appreciate simplicity, fast set-up, and no complications. With intuitive icon-based controls and one-touch synchronization, XS WIRELESS 1 is wireless the easy way.

They developed XS Wireless 1 for those who want to concentrate on their talent, their message, their passion — and not their microphone equipment. Just switch it on and its automatic frequency management does the rest. You can operate up to ten wireless connections simultaneously. No matter whether you’re in a band, a theater or at a seminar: XS Wireless 1 makes you free to do your thing.

XS Wireless 1 delivers acclaimed Sennheiser quality. Microphones with feedback protection and high-grade components yield an open, forceful sound. The receiver comes in an updated version that is designed to be easy to use. No lengthy set up — just go! These microphones and transmitters are proven classics — the result of decades of German engineering.

On stage, you have to put up with a lot of things — so does your equipment. XS Wireless 1 is built to last: Transmitters and microphones are sweat-resistant and withstand even the toughest stress in everyday on-stage use.

More Information
Product Name Sennheiser XSW 1-825-A Vocal System - Frequency A
Brand Sennheiser
Condition New
MPN 507108
UPC 615104278615
Shipping Option Free Shipping on orders over $94.72
Features
  • Integrated antennas
  • Up to 10 compatible channels
  • Antenna-switching diversity reception
  • Automatic frequency management and synchronization via remote channel for easy setup
  • Selectable UHF frequencies within a large bandwidth
  • Easiest handling
  • Reliable transmission
  • Excellent live sound
Tech Specs
System
Modulation: Wideband FM
Frequency Range: A - 548 to 572 MHz
Switching Bandwith: Up to 24 MHz
Signal to Noise Ration: â‰¥ 103 dBA
Total Harmonic Distortion: â‰¤ 0.9%
Temperature Range: 32 to 104 Â° F (operation) & -4 to 158 Â° F (storage)
Transmitter Synchronization: 2.4 GHz, Low Power (onyl active during synchronization)


Receiver
Principle: Double superheterodyne
Diversity: Antenna switching diversity via internal antennas
Sensitivity: < 3 μV at 52 dBA RMS S/N (at peak deviation)
Frequency Response: 50 Hz to 16 kHz (-3 dB)
Max Output Voltage: At Peak Deviation, 1 kHz AF
1/4" (6.3mm) Jack Socket (unbalanced): +6 dBu
XLR Socket (balanced): +12 dBu
Adjustment Range: Audion - 45 dB, adjustble to 5-dB steps
Power Supply: 12 VDC nominal/300 mA
Squelch: Adjustable from 3 dB Î¼V to 28 dB μV (combined with pilot tone)
Line/Mic Level: 20 dB, switchable
Material of Construction: ABS Housing
Dimensions (WxHxD): 7.9 x 1.7 x 5.0” (200 x 42 x 127mm)
Weight: 12 oz (340g)



Microphone
Outout Power: 10 mW
Frequency Response: 801 Hz to 14 kHz
Power Supply: 2 x AA batteries, 1.5v
Operating Time: Approximately 10 hrs
Microphone Type: Dynamic
Polar Pattern: Cardiod
Input Sensitivity: Capsule - 1.5 mV/Pa
Adjustment Range: Transmitter Sensitivity - 0 tp -30 dB, adjustable in 10 dB steps
Material of Construction: Rugged ABS housing
Dimensions (L x Diam): 10 x 2.0” (260 x 50mm)
Weight: 8.6 oz (245g)
