The DR-680MKII is a portable multi-channel recorder that allows simultaneous recording up to 8 tracks at 96kHz/24-bit, coming equipped with 6 mic/line inputs and digital input channels.
Equipped with a TASCAM-developed high-sound quality HDDA (High Definition Discrete Architecture) microphone amplifier, the DR-680MKII has improved the sound quality of its op-amp and condensers through extensive listening tests.
The DR-680MKII allows high-sound quality multi-channel recording using multiple microphones at various settings such as drama and documentary productions, on-field recording, SE recording, and live concert recordings.
| Product Name | Tascam DR-680MKII Portable Multichannel Recorder |
|---|---|
| Brand | Tascam |
| Condition | New |
| MPN | DR-680MKII |
| UPC | 043774025466 |
| Shipping Option | Free Shipping on orders over $94.72 |
What's in the Box?
- Tascam DR-680MKII Portable Multichannel Recorder
- AC Adaptor
- USB Cable
- Shoulder Strap
- SD/SDHC/SDXC cards used as recording/playback media
- 6 balanced mic/line inputs (1-4: XLR/TRS combo jacks, 5-6: TRS jacks)
- 6 unbalanced outputs (RCA pin jacks)
- COAXIAL digital input and output (S/PDIF, AES/EBU)
- Recording/playback formats: BWF, WAV, MP3
- With BWF format, recording starting times can be stored in files
- 8-track recording at 96kHz/24-bit (BWF, WAV)
- 6 mic/line inputs and stereo mix recording or 6 mic/line input and digital stereo recording
- Record MP3 files at 96, 128, 192 and 320 kbps
- Record 4-channel MP3 files
- From 4 mic/line inputs (XLR/TRS combo jacks) or 2 mic/line inputs and digital stereo inputs
- 2-track recording at 24-bit/192kHz (BWF, WAV)
- From 2 mic/line inputs or digital stereo inputs
- Digital inputs and outputs support double speed 96 kHz and quad speed 192 kHz
- Sampling frequencies
- 44.1, 48, 96, 192 kHz (BWF, WAV) 44.1, 48 kHz (MP3)
- Quantization bit depth: 16/24-bit (BWF, WAV)
- 6 channels of TASCAM HDDA mic preamps for high audio quality with 48V phantom power
- Limiter and low-cut filter available on each mic/line input
- Built-in stereo monitoring mixer for headphone mix and/or recording
- Dual-recording function allows two files to be recorded simultaneously at different levels
- GANG function allows the input gain of multiple channels to be operated simultaneously
- Pre-recording function allows the capture of audio two seconds before recording is started
- Automatic-recording function can start and stop recording automatically in response to the input signal level (−48, −24, −12 or −6 dB)
- Even when multiple tracks are used, all recordings made at the same time can be managed as a single take/file
- Track incrementation allows a recording to be split by creating a new file at the desired point without interrupting recording
- Up to 1000 takes and 5000 files can be recorded on a single card
- Mark function can be used to move to specific points (up to 99 marks per take)
- Wheel can be used to change the playback position
- Repeat playback function
- Panel lock function to prevent misoperation
- Cascade function allows transport control of multiple DR-680MKII units using a master unit
- File name format can be set to use a user-defined word or the date
- High-speed transfer of files to a computer using USB 2.0
- 128×64-dot matrix display with backlight
- Built-in mono speaker with 500mW output
- Headphone output and level control (50mW+50mW/ 32ohm)
- Powered by 8 AA batteries or the included AC adapter
- USB cable and shoulder strap included
- Folding stand convenient for tabletop use
- CS-DR680 carrying case (sold separately)
Tascam DR-680MKII Portable Multichannel Recorder
Details
The DR-680MKII is a portable multi-channel recorder that allows simultaneous recording up to 8 tracks at 96kHz/24-bit, coming equipped with 6 mic/line inputs and digital input channels.
Equipped with a TASCAM-developed high-sound quality HDDA (High Definition Discrete Architecture) microphone amplifier, the DR-680MKII has improved the sound quality of its op-amp and condensers through extensive listening tests.
The DR-680MKII allows high-sound quality multi-channel recording using multiple microphones at various settings such as drama and documentary productions, on-field recording, SE recording, and live concert recordings.
| Product Name | Tascam DR-680MKII Portable Multichannel Recorder |
|---|---|
| Brand | Tascam |
| Condition | New |
| MPN | DR-680MKII |
| UPC | 043774025466 |
What's in the Box?
- Tascam DR-680MKII Portable Multichannel Recorder
- AC Adaptor
- USB Cable
- Shoulder Strap
Features
- SD/SDHC/SDXC cards used as recording/playback media
- 6 balanced mic/line inputs (1-4: XLR/TRS combo jacks, 5-6: TRS jacks)
- 6 unbalanced outputs (RCA pin jacks)
- COAXIAL digital input and output (S/PDIF, AES/EBU)
- Recording/playback formats: BWF, WAV, MP3
- With BWF format, recording starting times can be stored in files
- 8-track recording at 96kHz/24-bit (BWF, WAV)
- 6 mic/line inputs and stereo mix recording or 6 mic/line input and digital stereo recording
- Record MP3 files at 96, 128, 192 and 320 kbps
- Record 4-channel MP3 files
- From 4 mic/line inputs (XLR/TRS combo jacks) or 2 mic/line inputs and digital stereo inputs
- 2-track recording at 24-bit/192kHz (BWF, WAV)
- From 2 mic/line inputs or digital stereo inputs
- Digital inputs and outputs support double speed 96 kHz and quad speed 192 kHz
- Sampling frequencies
- 44.1, 48, 96, 192 kHz (BWF, WAV) 44.1, 48 kHz (MP3)
- Quantization bit depth: 16/24-bit (BWF, WAV)
- 6 channels of TASCAM HDDA mic preamps for high audio quality with 48V phantom power
- Limiter and low-cut filter available on each mic/line input
- Built-in stereo monitoring mixer for headphone mix and/or recording
- Dual-recording function allows two files to be recorded simultaneously at different levels
- GANG function allows the input gain of multiple channels to be operated simultaneously
- Pre-recording function allows the capture of audio two seconds before recording is started
- Automatic-recording function can start and stop recording automatically in response to the input signal level (−48, −24, −12 or −6 dB)
- Even when multiple tracks are used, all recordings made at the same time can be managed as a single take/file
- Track incrementation allows a recording to be split by creating a new file at the desired point without interrupting recording
- Up to 1000 takes and 5000 files can be recorded on a single card
- Mark function can be used to move to specific points (up to 99 marks per take)
- Wheel can be used to change the playback position
- Repeat playback function
- Panel lock function to prevent misoperation
- Cascade function allows transport control of multiple DR-680MKII units using a master unit
- File name format can be set to use a user-defined word or the date
- High-speed transfer of files to a computer using USB 2.0
- 128×64-dot matrix display with backlight
- Built-in mono speaker with 500mW output
- Headphone output and level control (50mW+50mW/ 32ohm)
- Powered by 8 AA batteries or the included AC adapter
- USB cable and shoulder strap included
- Folding stand convenient for tabletop use
- CS-DR680 carrying case (sold separately)
