Audio interface functions

• Support for high-resolution recording formats up to 24-bit/96kHz
• MFi certified and direct connection with iOS devices supported
• Supports Windows (ASIO/WDM) and Mac (Core Audio)
• USB 2.0 computer connection
• Compliant with USB audio 2.0
• Bus power operation supported when connected to a computer
• Support for multiple power sources (TASCAM PS-P520E AC adapter, TASCAM BP-6AA external battery, Apple AC adapter, mobile battery with microUSB output)
• Operation confirmed with major DAW software (Sonar, ProTools, Cubase, Live, Studio One, GarageBand and Logic Pro)

Hardware functions

• 2 Ultra-HDDA (High Definition Discrete Architecture) mic preamps
• Balanced XLR/TRS input jacks that can provide +48V phantom power
• Supports direct guitar input
• Input level specifications boast a 57dB range that supports dynamic mic input
• Zero-latency direct monitoring function
• 2 balanced analog TRS output jacks suitable for connection to powered monitors
• Headphone output mini jack
• Separate controls for line and headphone output volumes
• MIDI input and output enable connection with keyboards and other MIDI devices

Software functions

• Direct monitoring MONO/STEREO switching
• LINE OUT output signal selection (Monitor/Computer)
• Input mute function can eliminate noise from unused channels

Other functions

• Solid aluminum body
• Guards that protect knobs during transportation
• License included to remove restrictions from Steinberg Cubasis LE demo version
• Steinberg Cubase LE 8 license card included
• Product compliant with RoHS
