Tube Tech MEC-1A Tube Recording Channel / Channel Strip.
The MEC-1A encompasses the all tube based designs of the MP 1A Microphone Preamplifier, EQ 1A Equalizer and CL 1B Compressor in a powerful, two-unit recording package.
View full details
- Details
- Reviews
Tube Tech MEC-1A Tube Recording Channel / Channel Strip
The MEC-1A encompasses the all tube based designs of the MP 1A Microphone Preamplifier, EQ 1A Equalizer and CL 1B Compressor in a powerful, two-unit recording package – designed and hand crafted to deliver the warmth of vintage quality recordings with unrivaled accuracy, purity and realism
The TUBE-TECH MEC 1A Recording Channel is a one channel recording unit, featuring a microphone preamplifier equalizer and compressor. At the heart of the shelving and bell filters you will find a tube operational amplifier.
The MEC 1A is all tube based except for the power supply. Input and Output have fully floating transformers. All DC voltages are stabilized, except the anode voltage for the output stage.
Tube based "three-in-one" recording solution
Microphone Preamplifier
+20 dB to +70 dB Gain
Phantom Power (+48 V)
Phase Reverse
-20 dB pad
Lowcut filter
High-impedance DI-input (>1 Mohm) for direct connection of guitar, bass or keyboard
Equalizer
Three bands
6 Low shelving frequency choices
6 High shelving frequency choices
Bell type Mid section with 12 switchable frequencies
Variable Q
Separate in/out switch
Compressor
Optical gain reduction element
Linkable for stereo applications
Variable Attack and Release parameters
Ratio 1,5:1 to 10:1
Separate in/out switch
General
Master Output Gain (off to +10 dB)
Clickless swap relay (Equalizer <-> Compressor)
VU-Meter showing output or compression
Frequency response @ -3dB: 5 Hz to 60 kHz
Low Noise: < - 85 dBu @ 10 dB gain
Gold-plated switches
Conductive plastic potentiometers
Fully regulated power supply with toroidal transformer
| Product Name | Tube Tech MEC-1A Tube Recording-Channel / Channel Strip |
|---|---|
| Brand | Tubetech |
| Condition | New |
| MPN | MEC1A |
| UPC | 889406081215 |
| Shipping Option | Free Shipping to the Continental U.S. |
