TS-18SW700/8A
Powerful PA speaker systems call for Turbosound drivers, which are designed to bring out the best audio performance no matter the genre or application. The 18” TS-18SW700/8A low frequency driver provides tight and punchy bass performance and handles up to 2,800 Watts of peak output (700 Watts RMS), with a frequency range that extends from 35 Hz to 2 kHz. The die-cast aluminium frame is extremely rigid and light in weight, making it ideal for use as a replacement driver – or for deployment in custom-engineered multi-way PA and subwoofer enclosures.
| Product Name | Turbosound TS-18SW700/8A 18" Low-Frequency Loudspeaker |
|---|---|
| Brand | Turbosound |
| Condition | New |
| MPN | TS-18SW700/8A |
| UPC | 4033653230827 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Turbosound TS-18SW700/8A 18" Low-Frequency Loudspeaker
- 18" high-power woofer for PA applications
- Continuous Power: 700 Watts RMS
- Maximum Power: 2,800 Watts
- Impedance: 8 Ohms
- Frequency Range: 35 Hz - 2 kHz
- SPL: 96 dB (1 W / 1 m)
- Rigid aluminum die-cast frame
- Mounting Hole Diameter: 442 mm (17.4")
- Shipment Weight: 16.5 kg (36.3 lbs) and Net Weight: 12.8 kg (28.2 lbs)
- Overall Diameter: 460 mm (18.11")
| Loudspeaker Diameter | 18" / 460 mm |
| Impedance | 8 Ohms |
| Continuous Power Rating | 700 W |
| Peak Power Rating | 2800 W |
| Sensitivity | 96 dB (±2.5 dB, 1 W / 1 m) |
| Frequency Range | Fo ~3 kHz (-10 dB) |
| Magnet Size | 8.7" / 220.0 mm |
| Voice Coil Diameter | 4" / 100.2 mm |
| Bobbin Material | Glass Black Fiber |
| Wire Type | Copper wire |
| Winding Height | 1.1" / 27.0 mm |
| Layers | 2 |
| Cone Body | Paper |
| Cone Surround | Cloth |
| Item Part Number | H77-00002-31675 |
| Thiele & Small Parameters | |
| Resonance Frequency (Fs) | 35 Hz |
| DC Resistance (Re) | 5.2 Ohms |
| Mechanical Q Factor (Qms) | 25.9 |
| Electrical Q Factor (Qes) | 0.44 |
| Total Q Factor (Qts) | 0.43 |
| Mechanical Moving Mass (Mms) | 185 g |
| Mechanical Compliance (Cms) | 0.11 mm/N |
| Force Factor (Bl) | 22 |
| Equivalent Acoustic Volume (Vas) | 250 I |
| Maximum Linear Displacement (Xmax) | 7.5 mm |
| Diaphragm Area (Sd) | 1288 sq cm |
| Voice Coil Inductance at 1 kHz (Le) | 1.03 mH |
| Physical | |
| Dimensions | 18" / 457.2 mm |
| Weight | 28.2 lb / 12.8 kg |
Turbosound TS-18SW700/8A 18" Low-Frequency Loudspeaker
TS-18SW700/8A
Powerful PA speaker systems call for Turbosound drivers, which are designed to bring out the best audio performance no matter the genre or application. The 18” TS-18SW700/8A low frequency driver provides tight and punchy bass performance and handles up to 2,800 Watts of peak output (700 Watts RMS), with a frequency range that extends from 35 Hz to 2 kHz. The die-cast aluminium frame is extremely rigid and light in weight, making it ideal for use as a replacement driver – or for deployment in custom-engineered multi-way PA and subwoofer enclosures.
| Product Name | Turbosound TS-18SW700/8A 18" Low-Frequency Loudspeaker |
|---|---|
| Brand | Turbosound |
| Condition | New |
| MPN | TS-18SW700/8A |
| UPC | 4033653230827 |
What's in the Box?
- Turbosound TS-18SW700/8A 18" Low-Frequency Loudspeaker
- 18" high-power woofer for PA applications
- Continuous Power: 700 Watts RMS
- Maximum Power: 2,800 Watts
- Impedance: 8 Ohms
- Frequency Range: 35 Hz - 2 kHz
- SPL: 96 dB (1 W / 1 m)
- Rigid aluminum die-cast frame
- Mounting Hole Diameter: 442 mm (17.4")
- Shipment Weight: 16.5 kg (36.3 lbs) and Net Weight: 12.8 kg (28.2 lbs)
- Overall Diameter: 460 mm (18.11")
| Loudspeaker Diameter | 18" / 460 mm |
| Impedance | 8 Ohms |
| Continuous Power Rating | 700 W |
| Peak Power Rating | 2800 W |
| Sensitivity | 96 dB (±2.5 dB, 1 W / 1 m) |
| Frequency Range | Fo ~3 kHz (-10 dB) |
| Magnet Size | 8.7" / 220.0 mm |
| Voice Coil Diameter | 4" / 100.2 mm |
| Bobbin Material | Glass Black Fiber |
| Wire Type | Copper wire |
| Winding Height | 1.1" / 27.0 mm |
| Layers | 2 |
| Cone Body | Paper |
| Cone Surround | Cloth |
| Item Part Number | H77-00002-31675 |
| Thiele & Small Parameters | |
| Resonance Frequency (Fs) | 35 Hz |
| DC Resistance (Re) | 5.2 Ohms |
| Mechanical Q Factor (Qms) | 25.9 |
| Electrical Q Factor (Qes) | 0.44 |
| Total Q Factor (Qts) | 0.43 |
| Mechanical Moving Mass (Mms) | 185 g |
| Mechanical Compliance (Cms) | 0.11 mm/N |
| Force Factor (Bl) | 22 |
| Equivalent Acoustic Volume (Vas) | 250 I |
| Maximum Linear Displacement (Xmax) | 7.5 mm |
| Diaphragm Area (Sd) | 1288 sq cm |
| Voice Coil Inductance at 1 kHz (Le) | 1.03 mH |
| Physical | |
| Dimensions | 18" / 457.2 mm |
| Weight | 28.2 lb / 12.8 kg |
