The first fully integrated live mixing console by Waves
64 stereo channels. 44 buses. 16 Waves Signature Preamps. Industry-leading sound & processing. Now in a classic console form factor.
Maximum Power. Compact Form.
eMotion LV1 Classic builds upon the industry-proven quality of the Waves LV1 mixer engine, and delivers its advantages in the preferred console workflow of live sound engineers worldwide.
With a pristine-sounding mixer engine, quick-access UI, and the industry’s deepest integration of state-of-the-art processing, LV1 Classic packs more live mixing power into a compact console than ever before.
- 64 stereo channels / 44 stereo buses
- Double-precision 32-bit float mix engine (sample rate 44.1–96 kHz)
- 16 original-design Waves Signature Preamps
- Quick-access UI with 21.5” touch screen & 17 100mm motorized faders
- Onboard processing: 16 industry-favorite Waves processors included
- The industry’s most powerful processing upgrades
- Premium stagebox expansions with IONIC stageboxes
- Easy scalabilty: Easily add I/O and DSP, network multiple consoles
- Maximum portability: Compact & lightweight at just 38 lbs.
| Product Name | Waves eMotion LV1 Classic Live Mixing Console |
|---|---|
| Brand | Waves |
| MPN | USW379-700C-391 |
| UPC | 702781703919 |
What's in the Box?
- Waves eMotion LV1 Classic Live Mixing Console
- 64 mono/stereo input channels
- 44 mono/stereo buses: 8 groups, 24 auxes, 8 matrices, 3 master, cue
- Double Precision 32-bit floating point mix engine (44.1–96 kHz)
- Latency as low as 0.8 ms
- 21.5” multi-touch screen with 1000 Nit brightness
- 16+1 motorized 100 mm Alps faders
- 16+1 precision encoders, with mini-displays including per-channel LCD metering
- Select/Mute/Solo keys per channel
- 16 layers with utility keys and tempo pad
- 16+2 user-customizable shortcut keys
- 16 Waves Signature Preamps with mic/line inputs
- 12 line outputs, 2 AES3 outputs, AES3 SRC input
- Internal ultra-low-latency Waves SoundGrid DSP engine handles processing
- Add more I/O: Up to 14 SoundGrid-compatible devices, including Dante and MADI convertors
- Add up to 3 processing servers and 4 backup servers
- 4 SoundGrid switch ports: 2 Ethercon + 2 Rj45
- 8-slot rack hosts 8 plugins per input channel + all mix channels
- Plugins included with the console:
- F6 Dynamic EQ
- Waves Tune-Real Time
- eMo Q4 EQ
- eMo D5 Dynamics
- eMo F4 Filter
- GEQ 30-band EQ
- X-FDBK Feedback Eliminator
- PSE (Primary Source Expander) Mic Bleed Reduction
- Renaissance Compressor
- Renaissance Bass
- Doubler
- H-Delay
- Renaissance Reverb
- TrueVerb
- Magma Tube Channel Strip
- GTR3
- 160 additional award-winning Waves plugins available as upgrades
- Immersive in-ear mixing available as software upgrade (eMo IEM)
- Dugan auto-mixing available as software upgrade
- Custom options for mixing layout
- Intuitive control over each channel’s parameters
- Patch system-wide connections
- Custom colors per channel
- Unicode multi-language support
- Up to 1000 scenes with Recall Safe and Scope Filters
- 8 Mute groups and 16 Link DCAs with Spill function
- Digital preamp control with local V-Gain tracking for sharing
- Multiple outputs per channel with delay alignment controls
- Record 16 tracks locally to USB / 128 tracks to remote computers
- Stereo playback from USB
- Remote control apps for mobile & tablet, for both FOH and stage
- Size: 22” (560 mm) x 15.8” (402 mm) x 22.1” (561 mm)
- Weight: 38 lbs. (17.2 kg)
Waves eMotion LV1 Classic Live Mixing Console
Details
The first fully integrated live mixing console by Waves
64 stereo channels. 44 buses. 16 Waves Signature Preamps. Industry-leading sound & processing. Now in a classic console form factor.
Maximum Power. Compact Form.
eMotion LV1 Classic builds upon the industry-proven quality of the Waves LV1 mixer engine, and delivers its advantages in the preferred console workflow of live sound engineers worldwide.
With a pristine-sounding mixer engine, quick-access UI, and the industry’s deepest integration of state-of-the-art processing, LV1 Classic packs more live mixing power into a compact console than ever before.
- 64 stereo channels / 44 stereo buses
- Double-precision 32-bit float mix engine (sample rate 44.1–96 kHz)
- 16 original-design Waves Signature Preamps
- Quick-access UI with 21.5” touch screen & 17 100mm motorized faders
- Onboard processing: 16 industry-favorite Waves processors included
- The industry’s most powerful processing upgrades
- Premium stagebox expansions with IONIC stageboxes
- Easy scalabilty: Easily add I/O and DSP, network multiple consoles
- Maximum portability: Compact & lightweight at just 38 lbs.
| Product Name | Waves eMotion LV1 Classic Live Mixing Console |
|---|---|
| Brand | Waves |
| MPN | USW379-700C-391 |
| UPC | 702781703919 |
What's in the Box?
Waves eMotion LV1 Classic Live Mixing Console
Features
- 64 mono/stereo input channels
- 44 mono/stereo buses: 8 groups, 24 auxes, 8 matrices, 3 master, cue
- Double Precision 32-bit floating point mix engine (44.1–96 kHz)
- Latency as low as 0.8 ms
- 21.5” multi-touch screen with 1000 Nit brightness
- 16+1 motorized 100 mm Alps faders
- 16+1 precision encoders, with mini-displays including per-channel LCD metering
- Select/Mute/Solo keys per channel
- 16 layers with utility keys and tempo pad
- 16+2 user-customizable shortcut keys
- 16 Waves Signature Preamps with mic/line inputs
- 12 line outputs, 2 AES3 outputs, AES3 SRC input
- Internal ultra-low-latency Waves SoundGrid DSP engine handles processing
- Add more I/O: Up to 14 SoundGrid-compatible devices, including Dante and MADI convertors
- Add up to 3 processing servers and 4 backup servers
- 4 SoundGrid switch ports: 2 Ethercon + 2 Rj45
- 8-slot rack hosts 8 plugins per input channel + all mix channels
- Plugins included with the console:
- F6 Dynamic EQ
- Waves Tune-Real Time
- eMo Q4 EQ
- eMo D5 Dynamics
- eMo F4 Filter
- GEQ 30-band EQ
- X-FDBK Feedback Eliminator
- PSE (Primary Source Expander) Mic Bleed Reduction
- Renaissance Compressor
- Renaissance Bass
- Doubler
- H-Delay
- Renaissance Reverb
- TrueVerb
- Magma Tube Channel Strip
- GTR3
- 160 additional award-winning Waves plugins available as upgrades
- Immersive in-ear mixing available as software upgrade (eMo IEM)
- Dugan auto-mixing available as software upgrade
- Custom options for mixing layout
- Intuitive control over each channel’s parameters
- Patch system-wide connections
- Custom colors per channel
- Unicode multi-language support
- Up to 1000 scenes with Recall Safe and Scope Filters
- 8 Mute groups and 16 Link DCAs with Spill function
- Digital preamp control with local V-Gain tracking for sharing
- Multiple outputs per channel with delay alignment controls
- Record 16 tracks locally to USB / 128 tracks to remote computers
- Stereo playback from USB
- Remote control apps for mobile & tablet, for both FOH and stage
- Size: 22” (560 mm) x 15.8” (402 mm) x 22.1” (561 mm)
- Weight: 38 lbs. (17.2 kg)
