Why you need the Yamaha CBR12 12” 2-Way Passive Loudspeaker
For small- to mid-sized venues, the Yamaha CBR12 passive loudspeaker packs a punch. And it packs that punch at any volume level, thanks to Yamaha's combination of a highly-sensitive LF driver and an HF-protection circuit. The sensitive woofer puts out impressive bass tone at lower volume levels. If you crank up the levels to really drive your system, the HF-protection circuit is ready to prevent tweeter damage if the input levels become excessive. So whether you're setting up in a club, in a school or at church, you can expect consistent, clear sound from the Yamaha CBR12 passive loudspeaker.
Features
- Speaker configuration
- Active/passive: Passive
- Type: 2-Way full range
- LF driver: 12"
- MF driver: Not applicable
- HF driver: 1.4"
- Power amp (active)
- Amplifier type: Not applicable
- Wattage: Not applicable
- Mixer/preamp: Not applicable
- Power capacity (passive)
- 8 Ohms program/peak: 350W / 700W
- 4 Ohms program/peak: Info not available
- Included power amp: No
- Audio
- Frequency response: 48Hz - 20kHz
- Coverage pattern: 90 x 60
- Max SPL: 123 dB
- Enclosure
- Construction: Plastic
- Width: 14.8"
- Height: 23.7"
- Depth: 13.7"
- Weight: 30.6 lb.
- Inputs
- XLR: Not applicable
- TRS: 1
- TS: Not applicable
- RCA: Not applicable
- SPEAKON: 1
- Output/thru
- XLR: Not applicable
- TRS: Not applicable
- RCA: Not applicable
- SPEAKON: Not applicable
| Product Name | Yamaha CBR12 12" 2-Way Passive Loudspeaker |
|---|---|
| Brand | Yamaha |
| Condition | New |
| MPN | cbr12 |
| UPC | 086792995502 |
| Shipping Option | Free Shipping to the Continental U.S. |
Speaker configuration
- Active/passive: Passive
- Type: 2-Way full range
- LF driver: 12"
- MF driver: Not applicable
- HF driver: 1.4"
- Power amp (active)
- Amplifier type: Not applicable
- Wattage: Not applicable
- Mixer/preamp: Not applicable
- Power capacity (passive)
- 8 Ohms program/peak: 350W / 700W
- 4 Ohms program/peak: Info not available
- Included power amp: No
Audio
- Frequency response: 48Hz - 20kHz
- Coverage pattern: 90 x 60
- Max SPL: 123 dB
Enclosure
- Construction: Plastic
- Width: 14.8"
- Height: 23.7"
- Depth: 13.7"
- Weight: 30.6 lb.
Inputs
- XLR: Not applicable
- TRS: 1
- TS: Not applicable
- RCA: Not applicable
- SPEAKON: 1
- Output/thru
- XLR: Not applicable
- TRS: Not applicable
- RCA: Not applicable
- SPEAKON: Not applicable
Yamaha CBR12 12" 2-Way Passive Loudspeaker
Details
Why you need the Yamaha CBR12 12” 2-Way Passive Loudspeaker
For small- to mid-sized venues, the Yamaha CBR12 passive loudspeaker packs a punch. And it packs that punch at any volume level, thanks to Yamaha's combination of a highly-sensitive LF driver and an HF-protection circuit. The sensitive woofer puts out impressive bass tone at lower volume levels. If you crank up the levels to really drive your system, the HF-protection circuit is ready to prevent tweeter damage if the input levels become excessive. So whether you're setting up in a club, in a school or at church, you can expect consistent, clear sound from the Yamaha CBR12 passive loudspeaker.
Features
- Speaker configuration
- Active/passive: Passive
- Type: 2-Way full range
- LF driver: 12"
- MF driver: Not applicable
- HF driver: 1.4"
- Power amp (active)
- Amplifier type: Not applicable
- Wattage: Not applicable
- Mixer/preamp: Not applicable
- Power capacity (passive)
- 8 Ohms program/peak: 350W / 700W
- 4 Ohms program/peak: Info not available
- Included power amp: No
- Audio
- Frequency response: 48Hz - 20kHz
- Coverage pattern: 90 x 60
- Max SPL: 123 dB
- Enclosure
- Construction: Plastic
- Width: 14.8"
- Height: 23.7"
- Depth: 13.7"
- Weight: 30.6 lb.
- Inputs
- XLR: Not applicable
- TRS: 1
- TS: Not applicable
- RCA: Not applicable
- SPEAKON: 1
- Output/thru
- XLR: Not applicable
- TRS: Not applicable
- RCA: Not applicable
- SPEAKON: Not applicable
| Product Name | Yamaha CBR12 12" 2-Way Passive Loudspeaker |
|---|---|
| Brand | Yamaha |
| Condition | New |
| MPN | cbr12 |
| UPC | 086792995502 |
| Shipping Option | Free Shipping to the Continental U.S. |
