Why you need the Yamaha HS8IW Studio Monitor Mounting Points and Screws, White:
2-way bass-reflex bi-amplified nearfield studio monitor with 8" cone woofer and 1" dome tweeter. Mounting points on 4 surfaces are available.
Features:
- 2-way bass-reflex bi-amplified nearfield studio monitor with 8" cone woofer and 1" dome tweeter
- 38Hz - 30kHz (-10dB), 47Hz - 24kHz (-3dB) frequency response
- 75W LF plus 45W HF bi-amp system for high-performance 120W power amplification
- ROOM CONTROL and HIGH TRIM response controls
- XLR and TRS phone jack inputs accept balanced or unbalanced signals
- Mounting points on 4 surfaces
- Packaging single
| Product Name | Yamaha HS8IW Studio Monitor Mounting Points and Screws, White |
|---|---|
| Brand | Yamaha |
| Condition | New |
| MPN | HS8IW |
| UPC | 889025107471 |
| Shipping Option | Free Shipping on orders over $94.72 |
- Speaker type: 2-way bi-amp powered studio monitor
- Frequency response (-10dB): 38Hz - 30kHz
- Frequency response (-3dB): 47Hz - 24kHz
- Components
- LF: 8†cone
- HF: 1†dome
- Crossover: 2kHz
- Output power: 120W (LF:75W, HF:45W)
- Input sensitivity: -10 dBu/10k ohms
- I/O connectors: XLR3-31 type (balanced), PHONE (balanced)
- Indicators: Power ON (White LED)
- Power consumption: 60W
- Shape: Bass-reflex type
- Cabinet material: MDF
- Flying and mounting hardware: Four surfaces x 2 x M8 (120 mm pitch)
- Dimensions: W 250mm (9-13/16â€), H 390mm (15-3/8â€), D 334mm (13-1/8")
- Net weight: 10.7 kg (23.6 lbs.)
- Accessories: Owner's Manual, Power cord, Screws for installing brackets x 2
- Options: Baton bracket BBS251, Ceiling bracket BCS251, Wall bracket BWS251, Wall / ceiling bracket BWS50
- Packaging: Single
- Others: LEVEL control (+4dB/center click), EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz)
Yamaha HS8IW Studio Monitor Mounting Points and Screws, White
Details
Why you need the Yamaha HS8IW Studio Monitor Mounting Points and Screws, White:
2-way bass-reflex bi-amplified nearfield studio monitor with 8" cone woofer and 1" dome tweeter. Mounting points on 4 surfaces are available.
Features:
- 2-way bass-reflex bi-amplified nearfield studio monitor with 8" cone woofer and 1" dome tweeter
- 38Hz - 30kHz (-10dB), 47Hz - 24kHz (-3dB) frequency response
- 75W LF plus 45W HF bi-amp system for high-performance 120W power amplification
- ROOM CONTROL and HIGH TRIM response controls
- XLR and TRS phone jack inputs accept balanced or unbalanced signals
- Mounting points on 4 surfaces
- Packaging single
| Product Name | Yamaha HS8IW Studio Monitor Mounting Points and Screws, White |
|---|---|
| Brand | Yamaha |
| Condition | New |
| MPN | HS8IW |
| UPC | 889025107471 |
| Shipping Option | Free Shipping on orders over $94.72 |
Tech Specs
- Speaker type: 2-way bi-amp powered studio monitor
- Frequency response (-10dB): 38Hz - 30kHz
- Frequency response (-3dB): 47Hz - 24kHz
- Components
- LF: 8†cone
- HF: 1†dome
- Crossover: 2kHz
- Output power: 120W (LF:75W, HF:45W)
- Input sensitivity: -10 dBu/10k ohms
- I/O connectors: XLR3-31 type (balanced), PHONE (balanced)
- Indicators: Power ON (White LED)
- Power consumption: 60W
- Shape: Bass-reflex type
- Cabinet material: MDF
- Flying and mounting hardware: Four surfaces x 2 x M8 (120 mm pitch)
- Dimensions: W 250mm (9-13/16â€), H 390mm (15-3/8â€), D 334mm (13-1/8")
- Net weight: 10.7 kg (23.6 lbs.)
- Accessories: Owner's Manual, Power cord, Screws for installing brackets x 2
- Options: Baton bracket BBS251, Ceiling bracket BCS251, Wall bracket BWS251, Wall / ceiling bracket BWS50
- Packaging: Single
- Others: LEVEL control (+4dB/center click), EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz)
